Rick Ferrucci 17 #1 Posted October 2 Hello Everybody, I would like to replace the flywheel debris screen on my GT14. Here's some of the problems I'm running into. The part # 47-755-22-S is no longer available. I've checked eBay, Isavetractors, and Kohler engines, only to get the same answer. So some of the parts available on eBay look almost exactly the same, part# 25-162-01-S but I can't tell by a picture. My screen is exactly 8.5" wide, but sellers haven't told me how wide their screen is. Also, the screen I have is plastic, I would prefer to have one made of metal. My engine is a K321S, 14hp, 8 1/2" across the screen, four bolts to the flywheel. Does anyone else with maybe a newer engine or even a different displacement, have a screen somewhat similar? Is there a cross-reference for parts like this? Thanks for your response. Rick Share this post Link to post Share on other sites
WHX?? 48,813 #2 Posted October 2 And the screen shot is for ??? Rick?? Oh your looking for a screen shot of your flywheel screen?? Have you posted a ad in wanted? 2 Share this post Link to post Share on other sites
ebinmaine 67,391 #3 Posted October 3 10 hours ago, Rick Ferrucci said: My screen is exactly 8.5" wide, but sellers haven't told me how wide their screen is. Also, the screen I have is plastic, I would prefer to have one made of metal. My engine is a K321S, 14hp, 8 1/2" across the screen, four bolts to the flywheel. Does anyone else with maybe a newer engine or even a different displacement, have a screen somewhat similar? I have a core engine that's from the 70s or 80s from a different brand. I'll see what the measurements are there. 1 Share this post Link to post Share on other sites
953 nut 55,156 #4 Posted October 3 11 hours ago, Rick Ferrucci said: So some of the parts available on eBay look almost exactly the same, part# 25-162-01-S but I can't tell by a picture. My screen is exactly 8.5" wide, but sellers haven't told me how wide their screen is. You do know that you can ask the seller a question through , don't you? The plastic screen you have is NOT correct for your GT-14 but if it works then stick with it. Share this post Link to post Share on other sites
ebinmaine 67,391 #5 Posted October 3 9 hours ago, ebinmaine said: I have a core engine that's from the 70s or 80s from a different brand. I'll see what the measurements are there. Mine was not usable. Share this post Link to post Share on other sites
wallfish 16,994 #6 Posted October 3 For $13 ish plus shipping you can just make one out of aluminum for less than $20 https://www.onlinemetals.com/en/buy/aluminum/0-063-thick-x-0-125-hole-x-0-1875-stagger-aluminum-perforated-sheet-3003-h14-round-hole/pid/13494 1 2 1 Share this post Link to post Share on other sites
kpinnc 11,981 #7 Posted October 4 They aren’t cheap, but can usually be found on eBay. Just search “Kohler screen”. The 10-16 (K241, 301, 321, and 341) horsepower screens are all the same size. 1 Share this post Link to post Share on other sites
wallfish 16,994 #8 Posted October 5 This steel one might be better 1/4" holes https://www.onlinemetals.com/en/buy/carbon-steel/0-06-thick-x-0-25-hole-x-0-3125-stagger-carbon-steel-perforated-sheet-a36-round-hole/pid/13512 1 Share this post Link to post Share on other sites
WHX?? 48,813 #9 Posted October 5 22 hours ago, kpinnc said: They aren’t cheap, You must be cheap KP ... I'm seein 20 clams... resonable I think. 1 Share this post Link to post Share on other sites
kpinnc 11,981 #10 Posted October 5 (edited) 15 minutes ago, WHX?? said: You must be cheap KP Well, for what it is… Stamped piece of perforated metal… Non-Platinum! But yeah I’m cheap. Wife calls me Colonel Klink. Amongst other things! Edited October 5 by kpinnc 2 Share this post Link to post Share on other sites
WHX?? 48,813 #11 Posted October 5 7 minutes ago, kpinnc said: Wife calls me Colonel Klink. Pfsst ... My wife says I'm so tight she can't shove a pin up my @$$ with a jack hammer... 3 Share this post Link to post Share on other sites
Handy Don 12,202 #12 Posted October 5 8 minutes ago, WHX?? said: Pfsst ... My wife says I'm so tight she can't shove a pin up my @$$ with a jack hammer... WAY !! 1 Share this post Link to post Share on other sites
WHX?? 48,813 #13 Posted October 5 5 minutes ago, Handy Don said: WAY !! KP's fault or better yet EB's ... I like KP. ... 3 Share this post Link to post Share on other sites
kpinnc 11,981 #14 Posted October 5 22 minutes ago, Handy Don said: WAY !! But still funny, right? 17 minutes ago, WHX?? said: KP's fault or better yet EB's ... I like KP. ... In the spirit of wives, money, and flywheel screens- I don’t mind. I’m used to stuff being my fault! 3 Share this post Link to post Share on other sites
SylvanLakeWH 25,524 #15 Posted October 5 9 hours ago, WHX?? said: Pfsst ... My wife says I'm so tight she can't shove a pin up my @$$ with a jack hammer... Forum rules... gonna need pics... 8 Share this post Link to post Share on other sites
Rick Ferrucci 17 #16 Posted October 11 This past weekend, I went to the Zagray Farm Museum, Fall Show, in Colchester Ct. The show is getting bigger every year. In the vendors show, I saw a lot of used flywheel screens in person. Screens that I saw a picture of online, (and hoped they'd work for my engine) I saw there was no way they'd fit. If you like to see antique tractors, antique engines, antique construction equipment. (and don't mind a lot of walking) You might like the show. Share this post Link to post Share on other sites
953 nut 55,156 #17 Posted October 11 1 hour ago, Rick Ferrucci said: I went to the Zagray Farm Museum, Fall Show, in Colchester Ct. The show is getting bigger every Share this post Link to post Share on other sites
Rick Ferrucci 17 #18 Posted October 12 Pictures?!! I knew I forgot something . . . 1 Share this post Link to post Share on other sites
