C my new tractor

[Retired Wrencher 5,454]

1 minute ago, Oldskool said:

Thanks. I thought I would never find one up in my neck of the woods.. It's going to be a fun little project.

Well I think they all are. I like those big blocks. Was always on my list but never bought one.I am almost done with two this year already. But being retired helps.

[ebinmaine 67,459]

6 minutes ago, Oldskool said:

At some point I may have to get inside that transmission. What is the best way to free up the cross pin? Drill a small hole on the case seam and use penetrant?



Small hole is not a bad idea.



Heat. Patience. Repeat.

[Blasterdad 2,692]

2 minutes ago, Oldskool said:

At some point I may have to get inside that transmission. What is the best way to free up the cross pin? Drill a small hole on the case seam and use penetrant?



I wouldn't drill a hole in the seam, maybe on the left side in the middle as a last resort,  try penatrant & working it first.

Nice Brinly hitch.!

Just noticed the front tires are on backwards too, something for the to do list.

[953 nut 55,205]

54 minutes ago, Oldskool said:

At some point I may have to get inside that transmission. What is the best way to free up the cross pin? Drill a small hole on the case seam and use penetrant?

I would suggest several 1/8" holes with a 1/4" top portion drilled half way down to act as a reservoir for penetrating oil of your choice.



[ebinmaine 67,459]

It would be a very good idea to get the set screws out of those hubs and start dropping penetrating oil in there as well.

[johnnymag3 2,520]

And you will want to correct the incorrect belt routing on the mule drive....





I love my C 160......They are beasts.



John

[Oldskool 6,644]

4 hours ago, Blasterdad said:



I wouldn't drill a hole in the seam, maybe on the left side in the middle as a last resort,  try penatrant & working it first.

Nice Brinly hitch.!

Just noticed the front tires are on backwards too, something for the to do list.

I'll try that. I didn't even notice the tires past my giddiness

[Oldskool 6,644]

3 hours ago, johnnymag3 said:

And you will want to correct the incorrect belt routing on the mule drive....





I love my C 160......They are beasts.



John

Good to know. That pulley is froze up tight as well

[ebinmaine 67,459]

3 hours ago, Oldskool said:

Good to know. That pulley is froze up tight as well

Lemme know if that don't free up.

[ebinmaine 67,459]

7 hours ago, Blasterdad said:

front tires are on backwards

Good eye there.

[Oldskool 6,644]

9 hours ago, Oldskool said:

At some point I may have to get inside that transmission. What is the best way to free up the cross pin? Drill a small hole on the case seam and use penetrant?

Is the hitch pin mild or hardened steel?

[Oldskool 6,644]

Someone left these nifty little trailer balls bolted in the front end.

Must of had small trailers?

[Oldskool 6,644]

Well I think these tierods have tied their last rods.

[Sailman 1,291]

Great find! Having a C-160 Hydro and a 416-8 with Kohler engines I can say you will enjoy that machine! It'll do anything you need it to do. Good luck with getting it back "on the road".

[Oldskool 6,644]

It's now a roller. Thank to an unknown WH it now has some air under it.

[953 nut 55,205]

2 hours ago, Oldskool said:

Is the hitch pin mild or hardened steel?

It is a mild steel pin. If you have a large drill press and a long enough set of drill bits you could drill the pin out. I have made it a practice to cut the pin off flush with the transmission and remove the hitch/lift parts prior to attempting to drive the pin out. I then drill a shallow 1/2" hole to hold the punch in place so you don't have to center it with each hammer blow. Lowell @wheelhorseman sells new hitch pins at a reasonable price so it isn't  worth trying to save one unless it cones out easily.

[Oldskool 6,644]

26 minutes ago, 953 nut said:

 Lowell @wheelhorseman sells new hitch pins at a reasonable price so it isn't  worth trying to save one unless it cones out easily.

I'm hoping to find out soon how hard/easy it will be

[Oldskool 6,644]

So how many Horse owners can say they had to scrap the underwear out of the engine before they could whirl it over?

[23 Reo 229]

With the underwear you have a very special Horse.

[Oldskool 6,644]

Just how long does it take a pair of Haines breifs to disintegrate?

I wod say it's been that long since it may have ran.

[ebinmaine 67,459]

1 hour ago, Oldskool said:

long does it take a pair of Haines breifs to disintegrate?

About as long as it would take a small sloth to ride a unicycle backwards and right side down on a flat tire  3.7 nautical miles around the outside of the back 40 hectares ... Give or take 25 years and a pickle and pimento sandwich.

[Oldskool 6,644]

Thanks to @ebinmaine Eric I have some used tierods. Gonna tighten them up and install. At least I'll be able to steer it around.

[SylvanLakeWH 25,550]

2 hours ago, Oldskool said:

So how many Horse owners can say they had to scrap the underwear out of the engine before they could whirl it over?



That's kinda personal...



1 hour ago, 23 Reo said:

With the underwear you have a very special Horse.



So's that...



1 hour ago, Oldskool said:

Just how long does it take a pair of Haines breifs to disintegrate?

I wod say it's been that long since it may have ran.



And that...



15 minutes ago, ebinmaine said:

About as long as it would take a small sloth to ride a unicycle backwards and right side down on a flat tire  3.7 nautical miles around the outside of the back 40 hectares ... Give or take 25 years and a pickle and pimento sandwich.



And well... @ebinmaine... really??? underwear, pickles, sloths and pimento's...?



Oh man...



Where's @Pullstart's latest injury when you need it???

[Pullstart 62,843]

If it wasn’t mentioned about that pin, try grabbing it with a pipe wrench and some heat.  Spinning it will break it free much easier than trying to drive it!

[Horse Newbie 7,069]

On 4/10/2023 at 8:38 PM, Oldskool said:

This just got air lifted, well lowered,  into my yard.

Traded my basket case Panzer T205 for it.

I'm thinking I made out ok.

@ebinmaine I can now join the C series crew lol.

The trans is free and shifts fine. The engine turns by hand,no carb.

The clutch spins,attach o magic pulley is froze. Tierods are rusted away. Just a quick chance over.

I got yelled at for securing my C-160 with clothes line…
