Parts Diagram for D-160

[yspecv 11]

I just acquired a D160 that's in need of assembly. Can someone shoot me a link to the parts diagrams? I searched and found the op manual, but no diagrams. Any help is appreciated!

[The Freightliner Guy 1,331]

Hello and welcome to the forum I wish you good luck with your project and it appears you really need a diagram @gwest_ca probably will give you a link for you



Kollin

Edited October 2, 2022 by The Freightliner Guy

[yspecv 11]

1 minute ago, The Freightliner Guy said:

Hello and welcome to the forum I wish you good luck with your project and it appears you really need a diagram @gwest_ca probably will give you a link for you



Kollin

Yes, it's quite the project. The gentlemen who owned it needed it out of the way. I saved it from the scrap yard, so hopefully I can get her back together.

[gwest_ca-(File Mod) 11,096]

A search for D-160 brings up 94 results on 4 pages

https://www.wheelhorseforum.com/search/?q=d-160&quick=1&type=downloads_file



This could be narrowed down if we had a model number

[yspecv 11]

4 minutes ago, gwest_ca said:

A search for D-160 brings up 94 results on 4 pages

https://www.wheelhorseforum.com/search/?q=d-160&quick=1&type=downloads_file



This could be narrowed down if we had a model number

Thank you. I am not sure of the model number. Where is the data plate on the D's? As you can see, it's kinda tough to find info in the pile. I would like to think that most parts breakdowns should be similar. At least to get me going.

[1995 520H+96+97 937]

[gwest_ca-(File Mod) 11,096]

Kohler engine used in 1974-1975

The rest used Onan engines.

[yspecv 11]

3 minutes ago, gwest_ca said:

Kohler engine used in 1974-1975

The rest used Onan engines.

Got ya. This one has the Onan, so it must be a later model. Ill dig through the panels and see if I can find a data plate. But the info you gave so far will get me started. Thanks!

[BuffaloD200 43]

Did you ever finish this rebuild?

[yspecv 11]

11 minutes ago, BuffaloD200 said:

Did you ever finish this rebuild?

No, unfortunately. After digging through all the boxes and sorting everything, there were to many parts missing to make it worth while. I ended up passing along all the parts to other enthusiasts. Some parts were shipped and others were picked up locally. Only cost I asked for was to cover shipping.
