We are so fortunate that Trina has once again pulled together our 2025 RedSquare Calendar. Thank you Trina for your efforts, you do amazing work!

Operator manual #810209R1 16 pages Dated 5/80 Same manual for 1980 model 06-42ST01 and 1981-1982 model 06-42ST02 IPL from Toro Master Parts Viewer 5 pages 259.60KB 1-stage Includes PSB's #230 #356 #377 #431 Fits C-Series tractors Drive belt 9750 (5L x 69" or 5/8" x 69") Snowthrower 1979 42in model 96-42ST01 1979 serial numbers that have shown up for the 96-42ST01 00826x - Build date 1978 8162 June 11 Sunday 008419 - Build date 1978 8165 June 14 Wednesday 008449 008729 - Build date 1978 8167 June 16 Friday 009075 - Build date 1978 8171 June 20 Tuesday 009180 - Build date 1978 8171 June 20 Tuesday 009234 - Build date 1978 8172 June 21 Wednesday - Located in Sweden 009268 - Build date 1978 8172 June 21 Wednesday 009274 - Build date 1978 8172 June 21 Wednesday - Located in Norway 009662 010351 - Build date 1978 8179 June 28 Wednesday 010783 - Build date 1978 8184 July 03 Monday 011338 011492 - Build date 1978 8188 July 07 Friday 011558 011876 019002 019147 019384 019553 020150 020224 020231 020272 020341 020772

Operator manual #324-325 IPL Wiring 16 pages 2.07MB Change to tow valve 1 page 187KB Wiring Color pdf 1 page 309KB Long frame 45-1/2" wheelbase Tractor drive belt 7927 and no longer available from Toro - (4L x 78.0" or 1/2" x 78") Starter/generator belt Kohler 10hp, 12hp - 235262 (7345 Gates .410" x 35.09" 36 degree) (25-7345 Napa .410" x 35.09" 36 degree) Wheel Horse 1593 (3L x 34.4") - nla (Gates replacement 6735 3/8" x 35" 38 degree) Lube chart SS 1967 model 1077 - Not listed at Toro. Used Kohler K241S-46333d Uses the 5054 hydro transmission identified at Toro as 3100077 1967 serial numbers that have shown up for the 1077 277830 278083 291339 291603 291676 291895 291998 329545 ------------------------------------------------------------------------------ Tractor drive belt 7927 and no longer available from Toro - (4L x 78.0" or 1/2" x 78") Starter/generator belt Kohler 10hp, 12hp - 235262 (7345 Gates .410" x 35.09" 36 degree) (25-7345 Napa .410" x 35.09" 36 degree) Wheel Horse 1593 (3L x 34.4") - nla (Gates replacement 6735 3/8" x 35" 38 degree) Details & Attachments 4 pages 120.08KB 1967 model 1277 - Uses the 5054 hydro transmission identified at Toro as 3100077 1967 serial numbers that have shown up for the 1277 273283 302095 302308 302373 302403 322563 322607 322729 322869 322882 329586 363188

IPL #3321-160 8 pages 256.66KB Fits 260-Series tractors Replaces earlier model 78260 106078 blade replaced by 106637 3-blade set (3/4" round hole) Mower Rotary 1998 48in SD model 78261 Serial 8900001-8999999 Mower Rotary 1999 48in SD model 78261 Serial 9900001-9999999 May be the same as New Holland deck Serial T5L0441 Component 9861904

Operator manual #810680R1 Wiring 28 pages 3.67MB Wiring Color pdf 1 page 482KB Lube chart SS Details & Attachments 3 pages 122.34KB 1990 312-H model 31-12KE01 1990 serial numbers that have shown up for the 31-12KE01 0010377 0010378 0010419 0010598 0010828 - Build date 1989 9303 October 30 Monday 0011495 0011505 - Build date 1990 0032 February 01 Thursday 0011755 0013028 0013093 - Build date 1990 0128 May 08 Tuesday 0013468 Original operator manual #810680R1 Original IPL #810726R1 Links For Kohler operator manual see For Kohler service manual see For Eaton hydro transmission service manual see For hydraulic service manual see For hydraulic lift service manual see

Service manual 69 pages 16.46MB Formerly #A-1391 and 803402 Hydrogear and Piston-Piston 1965 - 1982 (4 parts) Part 1 - 34 pages 4.85MB Pages 1 to 31 Page 18 was a blank page for notes - removed to save space Part 2 - 7 pages 3.1MB Pages 32 to 38 Part 3 - 6 pages 2.6MB Pages 39 to 44 Part 4 - 19 pages 3.29MB Pages 45 to 63 Hydrogear or Hydro-gear overhaul by daveoman 1966 17 pages 3.3MB Piston-piston overhaul by daveoman 1966 20 pages 2.6MB Sundstrand 90-1136 used on 1973 10hp Automatic model 1-0475 1973 12hp Automatic model 1-0465 1973 14hp Automatic model 1-0435 1974 B-100 Automatic model 1-0510 1974 C-120 Automatic model 1-0485 1974 C-120 Automatic model 1-0490 1974 C-120 Automatic model 1-0495 1975 B-100 Automatic model 1-0511 1975 C-120 Automatic model 1-0491 1976 C-120 Automatic model 61-12KS01 1976 C-120 Automatic model 61-12KS02 1976 C-120 Automatic model 61-12KS03 1976 C-120 Automatic model 61-12KS04 1977 C-120 Automatic model 71-12KS01 1977 C-120 Automatic model 71-12KS02 Sundstrand 90-1137 used on 1973 18hp Automatic model 1-0600 1973 18hp Automatic model 1-0601 1973 18hp Automatic model 1-0610 1973 18hp Automatic model 1-0620 1974 D-160 Automatic model 1-0650 1974 D-180 Automatic model 1-0611 (D-180 axles 101893 reported to be 16-1/2" long) 1974 D-200 Automatic model 1-0630 1975 D-160 Automatic model 1-0651 1975 D-180 Automatic model 1-0612 1975 D-200 Automatic model 1-0631 1976 D-160 Automatic model 61-16OS01 1976 D-160 Automatic model 61-16OS02 1976 D-200 Automatic model 61-20KS01 1976 D-200 Automatic model 61-20KS02 1977 D-160 Automatic model 71-16OS01 1977 D-200 Automatic model 71-20KS01 Sundstrand 90-1140 used on 1974 C-160 Automatic model 1-0480 1975 C-160 Automatic model 1-0481 1976 C-160 Automatic model 61-16KS01 1976 C-160 Automatic model 61-16KS02 1976 C-160 Automatic model 61-16KS03 1976 C-160 Automatic model 61-16KS04 1977 C-160 Automatic model 71-16KS01 1977 C-160 Automatic model 71-16KS02 Sundstrand 90-1172 used on 1978 C-121 Automatic model 81-12KS01 1979 C-121 Automatic model 91-12KS01 1979 C-121 Automatic model 91-12KS91 - Guess Sundstrand 90-1173 used on 1978 C-141 Automatic model 81-14KS01 1978 C-161 Automatic model 81-16KS01 1978 C-161 Twin Automatic model 81-16BS01 1978 D-160 Automatic model 81-16OS01 - Guess 1978 D-200 Automatic model 81-20KS01 - Guess 1979 C-141 Automatic model 91-14KS01 1979 C-161 Automatic model 91-16KS01 1979 C-161 Automatic model 91-16KS91 - Guess 1979 C-161 Twin Automatic model 91-16BS01 1979 C-161 Twin Automatic model 91-16BS02 1979 D-160 Automatic model 91-16OS01 - Guess 1979 D-160 Automatic model 91-16OS02 - Not listed @ Toro and may be an invalid model number - Guess 1979 D-200 Automatic model 91-20KS01 - Guess 1979 D-200 Automatic model 91-20KS02 - Guess 1980 C-125 Automatic model 01-12KS01 1980 C-145 Automatic model 01-14KS01 1980 C-165 Automatic model 01-16KS01 1980 C-165 Automatic model 01-16KS91 - Guess 1980 C-175 Twin Automatic model 01-17KS02 1980 D-160 Automatic model 01-16OS01 - Guess 1980 D-200 Automatic model 01-20KS00 - Guess 1981 D-160 Automatic model 01-16OS01 - Not listed @ Toro - Guess 1981 D-200 Automatic model 01-20KS00 - Guess Sundstrand 90-2046 Hydro-gear or Hydrogear used on 1968 Charger 9 model 1-7931 1968 Charger 9 model 1-7932 1968 Charger 12 model 1-7231 1968 Electro 12 model 1-7235 1969 Charger 10 model 1-7041 1969 Charger 12 model 1-7241 1969 Electro 12 model 1-7245 1970 Charger 12 model 1-7251 1970 Charger 12 model 1-7252 1970 Charger 12 model 1-7253 1970 Electro 12 model 1-7255 1971 Bronco 14 model 1-0420 1971 Bronco 14 model 1-0421 1971 Charger 12 model 1-0400 1972 Bronco 14 model 1-0422 1972 Bronco 14 model 1-0423 1972 Charger 10 model 1-0410 1972 Charger 12 model 1-0401 1972 Charger 12 model 1-0402 1973 10hp Automatic model 1-0470 1973 12hp Automatic model 1-0460 1973 14hp Automatic model 1-0430 1973 16hp Automatic model 1-0440 (7052 spring is 1-5/16" long, 5/16" OD with .0645" wire diameter) Sundstrand 90-2062 Hydro-gear or Hydrogear used on 1969 GT-14 model 1-7441 1970 GT-14 model 1-7451 1970 GT-14 model 1-7452 1970 GT-14 model 1-7453 1971 GT-14 model 1-0500 1971 GT-14 model 1-0501 1972 GT-14 model 1-0502 1972 GT-14 model 1-0503 1973 GT-14 model 1-0502-8 - Listed in attachment interchange - Not listed at Toro Sundstrand 3100077 Hydro-gear or Hydrogear used on 1965 model 875 1965 model 1075 1966 model 876 1966 model 1076 - Not listed @ Toro 1966 model 1276 1967 model 877 1967 model 1077 - Not listed @ Toro 1967 model 1277

Briggs & Stratton service manual 270962 Service manual Section 01 General info 21 pages 627KB Service manual Section 02 Ignition 16 pages 741KB Service manual Section 03 Carburetion 71 pages 2.3MB Service manual Section 04 Engine controls 32 pages 1.9MB Service manual Section 05 Governors 31 pages 1MB Service manual Section 06 Compression 19 pages 500KB Service manual Section 07A Rewind starters 21 pages 1005KB Service manual Section 07B Electric starters 43 pages 1.4MB Service manual Section 07C Alternators 25 pages 1.2MB Service manual Section 08 Lubrication 9 pages 424KB Service manual Section 09 Piston Ring Rod 9 pages 497KB Service manual Section 10 Crankshafts Cam gears Gear reduction 28 pages 858KB Service manual Section 11 Cylinders Bearings 14 pages 480KB Service manual Section 12 Counter balance 7 pages 424KB This 270962 SM covers the following series of B&S engines 90100-Series 90700-Series including engine model 90702-900613B 1986-1987 3.5hp 21" walking mower model 04-35BR01 91200, 91700, 92200, 92400, 93200, 93400, 96900, 97300, 98900, 9A400, 9B900, 9D900-Series 100200-Series including engine model 100252-0435 1972 4hp Pathfinder snowthrower model 4-1040 100700, 100900, 10A900, 10B900, 10C900, 10T800-Series 110700, 111700, 111900, 112200, 112700, 113900-Series 114700-Series including engine model 114702-901196A 1986-1987 4hp 21" walking mower model 04-40BR01 121700, 121800, 122700, 122800, 122K00, 123700, 123800, 123K00, 124700, 124800, 126700, 126800, 127700, 127800, 128700, 128800, 129700, 129800-Series 12A800, 12B700, 12B800, 12C700, 12C800, 12D800, 12E700, 12E800, 12F700, 12F800, 12G700, 12G800, 12H700, 12H800, 12J700, 12J800, 12N800, 12P800, 12R800, 12S700, 12S800, 12T700-Series 130200, 130700, 131200, 132200, 132400, 132900, 133200, 133400, 133700, 134200, 134400, 135200, 135700, 136200, 137200-Series 170400, 170700, 171400, 176400-Series 190400-Series including engine model 190434-0638-01 1971 800 Automatic model 1-0450 - Uses 190434-0638-01 in PSB #301e - (109434-0825-01 incorrect ? @ Toro) 1971 800 Special model 1-0150 - - - Uses 190434-0638-01 in PSB #301e - (109434-0825-01 incorrect @ Toro) - [0825-01 found in 800 Special] 1972 800 Automatic model 1-0451 - Uses 190434-0638-01 in PSB #301e - (109434-0825-01 incorrect ? @ Toro) 190400-Series including engine model 190434-0825-01 1974 A-90 Special model 2-4300 - - Uses 190434-0825-01 in PSB #301e - (109434-0638-01 incorrect ? @ Toro) 190700-Series including engine model 190702-2176-01 1985 108-R Rear engine rider model 33-08X301 1986 108-R Rear engine rider model 33-08X303 190700-Series including engine model 190707-2154-01 1987 108-4 Rear engine rider model 33-08B401 190700-Series including engine model 190707-2167-01 1985 A-85 5-Speed RER model 33-08BP01 190700-Series including engine model 190707-2175-01 1985 108-3 Rear engine rider model 33-08B301 1986 108-3 Rear engine rider model 33-08B303 1986 108-3e Rear engine rider model B3-08B303 190700-Series including engine model 190707-2176-01 1985 108-3e Rear engine rider model B3-08B302 1987 108-3 Rear engine rider model 33-08B304 1987 108-3e Rear engine rider model B3-08B391 191700-Series including engine model 191702-2133-01 1983 8-32 Toro Rear engine rider model 56138 1984 8-32 Toro Rear engine rider model 56138 1985 8-32 Toro Rear engine rider model 56138 191700-Series including engine model 191702-2160-01 1986 8-32 Toro Rear engine rider model 56138 1987 8-32 Toro Rear engine rider model 56138 191700-Series including engine model 191702-2531-01 1988 8-32 Toro Rear engine rider model 56138 191700-Series including engine model 191702-5129 1976 A-70 5-Speed model 63-08BP01 191700-Series including engine model 191702-5648-01 1980 A-81 5-Speed Rear engine rider model 03-08XP01 191700-Series including engine model 191707-0121-1 1992 8-25 Toro Rear engine rider model 56132 1992 8-25 Toro Rear engine rider model 56133 1992 8-32 Toro Rear engine rider model 56185 1993 8-25 Toro Rear engine rider model 70040 1993 8-25 Toro Rear engine rider model 70060 191700-Series including engine model 191707-0685 1976 A-90 4-Speed model 62-08BP01 1977 A-90 4-Speed model 72-08BP01 191700-Series including engine model 191707-1136-01 1978 B-81 4-Speed model 82-08BP01 1979 B-81 6-Speed model 92-08BF01 1980 B-82 3-Speed model 02-08BP01 1981 B-82 3-Speed model 02-08BP02 191700-Series including engine model 191707-1136-02 1982 B85 5-Speed model 02-08BX01 191700-Series including engine model 191707-1160-01 1981 B-82 3-Speed model 02-08BP03 191700-Series including engine model 191707-1160-02 1982 LT-832 3-Speed model A2-083201 1983 Early LT-832 3-Speed model A2-083202 191700-Series including engine model 191707-2132-01 1983 8-32 Toro Rear engine rider model 56145 1985 8-32 Toro Rear engine rider model 56145 191700-Series including engine model 191707-2138-01 1983 Late LT-832 3-Speed model A2-083202 191700-Series including engine model 191707-2153-01 1985 208-3 model 22-08B301 1986 208-3 model 22-08B302 191700-Series including engine model 191707-2161-01 1986 8-32 Rear engine rider model 56145 1987 8-32 Rear engine rider model 56145 1988 8-32 Rear engine rider model 56145 1989 8-32 Rear engine rider model 56145 191700-Series including engine model 191707-2175-01 1987 208-5 model 32-08B501 1988 208-4 model 32-08B402 191700-Series including engine model 191707-5639-01 1979 A-81 5-Speed RER model 93-08BP01 1979 A-81 5-Speed RER model 93-08BP02 191700-Series including engine model 191707-5639-02 1983 RR-832 5-Speed RER model A3-083201 191700-Series including engine model 191707-5648-01 1979 A-81 5-Speed RER model 93-08XP02 191700-Series including engine model 191707-5663-01 1980 A-81 5-Speed RER model 03-08BP01 1981 A-81 5-Speed RER model 03-08BP02 1982 A-81 5-Speed RER model 23-08BP01 191700-Series including engine model 191707-5821-01 1983 A-81 5-Speed RER model 03-08BP03 1983 A-81 5-Speed RER model 23-08BP02 1983 A-81 5-Speed RER model 23-08BX01 1983 A-81 5-Speed RER model 23-08XP01 1984 A-81 5-Speed RER model 23-08BP03 191700-Series including engine model 191707-6021-01 1990 8-32 Rear engine rider model 56145 1991 8-25 Rear engine rider model 56132 1991 8-25 Rear engine rider model 56133 1991 8-32 Rear engine rider model 56185 192400-Series 193700-Series including engine model 193707-0148-01 1986 108-5 Rear engine rider model 33-08B502 1987 108-5 Rear engine rider model 33-08B503 1988 108-5 Rear engine rider model 33-08B5024 193700-Series including engine model 193707-0152-01 1986 8-32 Rear engine rider model 56150 1987 8-32 Rear engine rider model 56150 1988 8-32 Rear engine rider model 56150 193700-Series including engine model 193707-0307-01 1989 8-32 Rear engine rider model 56150 193700-Series including engine model 193707-0314-01 1989 208-4 model 42-08B401 208-4SB 194400-Series 194700-Series including engine model 194707-2132-01 1984 8-32 Rear engine rider model 56145 195400-Series 195700-Series including engine model 195707-0121-01 1993 8-25 Toro Rear engine rider model 70042 1994 8-25 Toro Rear engine rider model 70040 1994 8-25 Toro Rear engine rider model 70060 1995 8-25 Toro Rear engine rider model 70040 1995 8-25 Toro Rear engine rider model 70060 1996 8-25 Toro Rear engine rider model 70040 1996 8-25 Toro Rear engine rider model 70060 1997 8-25 Toro Rear engine rider model 70040 1997 8-25 Toro Rear engine rider model 70060 1998 8-25 Toro Rear engine rider model 70040 195700-Series including engine model 195707-0421-E1 1998 8-25 Toro Rear engine rider model 70041 1999 8-25 Toro Rear engine rider model 70044 1999 8-25 Toro Rear engine rider model 70122 2000 8-25 Toro Rear engine rider model 70044 2000 8-25 Toro Rear engine rider model 70122 2001 8-25 Toro Rear engine rider model 70044 2001 8-25 Toro Rear engine rider model 70122 2002 8-25 Toro Rear engine rider model 70044 196400, 196700, 197400, 198700-Series 220400, 220700, 21400, 222400, 226400, 233400, 243400, 250400-Series 252400-Series including engine model 252417-0198-01 1979 C-111 8-Speed model 91-11B801 1980 1100 Special model 01-11B803 (8-Speed) 252400-Series including engine model 252417-0245-01 1981 GT-2500 model 01-11B804 (8-Speed) 1982 SB-371 3-Speed model 02-11BH01 1982 SB-421 8-Speed model 01-11BH01 252400-Series including engine model 252417-0259-01 1982 GT-1142 8-Speed model A1-114201 252400-Series including engine model 252417-0664-01 1983 GT-1142 8-Speed model A1-114202 1984 GT-1100 8-Speed model A1-11B801 252700-Series including engine model 252707-0151-01 1978 B-111 4-Speed model 82-11BP01 1979 B-111 4-Speed model 92-11BP01 1979 B-111 6-Speed model 92-11BF01 252700-Series including engine model 252707-0188-01 1979 A-111 5-Speed RER model 93-11BP01 252700-Series including engine model 252707-0206-01 1980 B-112 3-Speed model 02-11BX01 1981 B-112 3-Speed model 02-11BX02 252700-Series including engine model 252707-0207-01 1980 A-111 5-Speed RER model 03-11BP01 1981 A-111 5-Speed RER model 03-11BP02 1982 A-111 5-Speed RER model 23-11BP01 1982 A-111 5-Speed RER model 23-11BX01 252700-Series including engine model 252707-0209-01 1980 B-115 5-Speed model 02-11BP02 1981 B-115 5-Speed model 02-11BP03 1981 B-115 5-Speed model 02-11BP04 1982 B-115 5-Speed model 02-11BP05 1982 B-115 Auto model 02-11BE01 252700-Series including engine model 252707-0222-01 1981 B-112 3-Speed model 02-11BX03 252700-Series including engine model 252707-0222-02 1982 LT-1137 5-Speed model A2-113701 252700-Series including engine model 252707-0621-01 1987 211-3 model 32-11B301 252700-Series including engine model 252707-0624-01 1987 211-4 model 32-11B401 1988 211-4 model 32-11B402 1989 211-4 model 32-11B403 252700-Series including engine model 252707-0648-01 1983 A-111 5-Speed model 23-11BP02 1984 A-111 5-Speed model 23-11BP03 252700-Series including engine model 252707-0657-01 1983 LT-1136 3-Speed model D2-113601 1983 LT-1136 3-Speed model D2-113701 (Possibly a model LT-1137) 1984 B-1136 3-Speed model B2-11BX91 1984 LT-1100 3-Speed model A2-11BX01 1985 211-3 model 22-11B301 1985 211-3e model B2-11B301 252700-Series including engine model 252707-0682-01 1985 A-115 5-Speed model 33-11BP01 252700-Series including engine model 252707-0682-02 1987 111-5 RER model 33-11B503 1987 11-5e RER model B3-11B591 253400-Series 253700-Series including engine model 253707-0131-01 1983 B-115 5-Speed model 12-11BP01 1983 B-115 Auto model 12-11BE01 1984 B-115 5-Speed model 12-11BP02 253700-Series including engine model 253707-0158-01 1984 LT-1100 5-Speed model A2-11BP01 1985 211-5 model 22-11B501 1985 211-A model 22-11BE01 1986 211-5 model 22-11B502 1987 211-5e model B2-11B591 253700-Series including engine model 253707-0158-03 1987 211-5 model 32-11B501 253700-Series including engine model 253707-0170-01 1985 111-5 RER model 33-11B501 1986 111-5 RER model 33-11B502 1986 111-5e RER model B3-11B502 1987 111-6 RER model 33-11B601 253700-Series including engine model 253707-0222-01 1987 211-5 model 32-11BX01 1988 211-5 model 32-11BX02 253700-Series including engine model 253707-0253-01 1988 111-6 RER model 33-11B602 253700-Series including engine model 253707-0406-01 1989 211-5 model 42-11B501 - 211-5SB 253700-Series including engine model 253707-0657-01 1986 211-3 model 22-11B302 1987 211-3e model B2-11B392 254400, 254700, 255400, 255700, 256400-Series 256700-Series including engine model 256707-0117-01 1989 110-4e RER model E3-10B401 1990 110-4e RER model R3-10B401 1991 110-4e RER model R3-10B402 1990 112-6e RER model R3-12K601 - (B&S wrong @ Toro - Has Kawasaki engine) 256700-Series including engine model 256707-0119-01 1990 210-5 model 32-10B501 1990 210-H model 32-10BE01 256700-Series including engine model 256707-0120-01 1991 110-4e RER model R3-10B403 256700-Series including engine model 256707-0126-01 1991 210-5 model 32-10B502 1991 210-H model 32-10BE02 257400-Series 257700-Series including engine model 257707-0123-01 1992 210-5 model 32-10B503 1992 210-h model 32-10BE03 257700-Series including engine model 257707-0127-01 1992 110-4e model R3-10B404 1993 110-4e model R3-10B404 258700, 259700-Series 280700-Series 281700-Series including engine model 281707-0190-01 1989 212-5 model 32-12B501 1989 212-H model 32-12BE01 281700-Series including engine model 281707-0217-02 1990 212-5e model R2-12B501 281700-Series including engine model 281707-0219-01 1990 112-6e model R3-12B601 281700-Series including engine model 281707-0226-02 1991 212-5 model 32-12B5A2 1991 212-5 model 32-12B5A3 1991 212-H model 32-12BEA2 1991 212-H model 32-12BEA3 282700, 283700 Series 284700-Series including engine model 284707-1148-E1 2002 12-32XL model 71199 285700-Series 286700-Series including engine model 286707-0116-01 1991 212-5SBe model S2-12B502 286700-Series including engine model 286707-0118-01 1991 112-6e RER model R3-12B602 286700-Series including engine model 286707-0128-01 1992 112-6e RER model R3-12B602 286700, 288700, 289700, 325400, 326400-Series 28A700, 28B700, 28C700, 28D700, 28M700, 28R700, 28T700-Series

Detailed wiring from the Demystification Guide #492-4509 Revised 5 pages 1.7MB Color pdf Pages p7-33 to p7-37 Pto switch wiring photo 1 page 211KB Magneto ignition and 15 amp stator Low oil switch 1987 312-8 model 21-12K804 1987 312-A model 21-12KE03

Operator manual #810306R1 or 810306 R1 7 pages 1.29MB Illustrated parts list removed from Work Horse tractor ipl #810286R1 7 pages 7.8MB Illustrated parts list from Toro Master Parts Viewer 7 pages 388.11KB This IPL includes the 48" deck so be careful selecting part numbers. Drive belt 102742 replaced by 94-2501 (1/2" x 103") Drive belt with front mower carrier and single cylinder engine 109956 (1/2" x 102") Drive belt with front mower carrier and twin cylinder engine 102742 replaced by 94-2501 (1/2" x 103") Spindle belt 6738 (1/2" x 86") Mower spindle assemblies could be L, M, V or Z For V see service bulletin 207B 106077 replaced by 106636 3-blade set (3/4" round hole) Mower Rotary 1981 42in SD model 05-42MS02 - fits C-Series and GT-2500 tractors 1981 serial numbers that have shown up for the 05-42MS02 036011 038387 - Build date 1981 11xx 041637 - Could also be 1982 or 1983 043140 - Could also be 1982 or 1983 Mower Rotary 1982 42in SD model 05-42MS02 - fits C-Series, GT-1642 and GT-1848 tractors 1982 serial numbers that have shown up for the 05-42MS02 33225 - Build date 1981 x256 September 13 Sunday - Model year a guess 39008 - Build date 1982 2048 February 17 Wednesday Mower Rotary 1983 42in SD model 05-42MS02 - fits C-Series, GT-1142, GT-1642 and GT-1848 tractors 1983 serial numbers that have shown up for the 05-42MS02 42472 - Build date 1982 2355 December 21 Tuesday

You will notice the Chicago Rawhide / SKF seal spec sheets show a WastWatcher seal. That seal may be easier to find as they have determined it is a part number that will replace many seals with the same dimensions except for width and have characteristics that meet or exceed the seal it replaces. A link to the SKF interchange http://www2.chicago-rawhide.com/popup_parts_lookup_457012.htm Toro / Wheel Horse part numbers are first on each line Seal 47-8030 Use 703333 -- Replaced by Chicago Rawhide / SKF 6105 Seal 56-2820 replaces 56-3270 & 112604 Eaton 1100 input shaft Seal 56-3130 may be -- replaced by Chicago Rawhide / SKF 7465 (Eaton part number ER92999 replaced by SKF / Chicago Rawhide 7465) [Eaton 1100 selector shaft seal] Seal 56-3270 replaced by 56-2820 Eaton 1100 input shaft Seal 83-2830 replaces 1234 -- Replaced by Chicago Rawhide / SKF 7627 Seal 83-2840 replaces 1257, 100573 -- Available only from Toro - This seal mounts over the axle tube - See photo at the top Seal 93-9807 replaces 112822 -- May be Chicago Rawhide / SKF 12407 Seal 253-44 replaces 1117, 108357, 700413, 707984 -- Replaced by Chicago Rawhide / SKF 7443 Seal 1011 -- Replaced by Chicago Rawhide / SKF 9859 Seal 1117 replaced by 253-44 -- Replaced by Chicago Rawhide / SKF 7443 Seal 1213 replaced by 100443 -- Replaced by Chicago Rawhide / SKF 11050 or National 340835 Seal 1232 replaced by 100863, See 114677, 9240 -- Replaced by Chicago Rawhide / SKF 9815 Seal 1234 replaced by 83-2830 -- Replaced by Chicago Rawhide / SKF 7627 or National 471643 Seal 1257 replaced by 83-2840 -- Available only from Toro - This seal mounts over the axle tube - See photo at the top Seal 1303 replaced by 100441 -- Replaced by Chicago Rawhide / SKF 7410 Seal 1447 replaced by 5959 -- Replaced by Chicago Rawhide / SKF 4911 Seal 1461 replaced by 100442 -- Replaced by Chicago Rawhide / SKF 6105 Seal 1482 replaced by 103118 -- Replaced by Chicago Rawhide / SKF 12330 Seal 3373 -- Replaced by Chicago Rawhide / SKF 10035 or National 204005 Seal 5958 replaced by 100607 -- Replaced by Chicago Rawhide / SKF 9878 Seal 5959 replaces 1447 -- Replaced by Chicago Rawhide / SKF 4911 Seal 6449 -- Replaced by Chicago Rawhide / SKF 11124 (Original 6449 is 1/2" wide) Seal 6663 -- Replaced by Chicago Rawhide / SKF 14810 Seal 7877 -- Replaced by Chicago Rawhide / SKF 7475 (Federal Mogul 480821 = CR 7474 , Original seal 9008000-7501 = CR 7443) Seal 7963 -- Replaced by Chicago Rawhide / SKF 6904 Seal 9230 replaced by 703333 -- Replaced by Chicago Rawhide / SKF 6105 Seal 9240 May be same as 1232, 100863 and 114677 -- Replaced by Chicago Rawhide / SKF 9815 a guess. Used on tiller with 5571 bushing Seal 100441 replaces 1303 -- Replaced by Chicago Rawhide / SKF 7410 Seal 100442 replaces 1461 -- Replaced by Chicago Rawhide / SKF 6105 (CR 11050 to replace 100442 @ SKF is wrong) Seal 100443 replaces 1213 -- Replaced by Chicago Rawhide / SKF 11050 or National 340835 Seal 100573 replaced by 83-2840 -- Available only from Toro - This seal mounts over the axle tube - See photo at the top Seal 100607 replaces 5958 -- Replaced by Chicago Rawhide / SKF 9878 Seal 100608 -- Replaced by Chicago Rawhide / SKF 6904 Seal 100863 Replaces 1232, 114677, 9240 -- Replaced by Chicago Rawhide / SKF 9815 a guess. Seal 103103 -- Replaced by Chicago Rawhide / SKF 8620 Seal 103118 replaces 1482 -- Replaced by Chicago Rawhide / SKF 12330 Seal 103269 or 103277 -- Replaced by Chicago Rawhide / SKF 10740 (National 471762 seal for 5-0900 deck thinner than originals) Seal 103461 -- Replaced by Chicago Rawhide / SKF 6763 Seal 106075 -- Replaced by Chicago Rawhide / SKF 9907 (Mower spindle original had double-lip) Seal 108357 replaced by 253-44 -- Replaced by Chicago Rawhide / SKF 7443 Seal 112604 replaced by 56-2820 Eaton 1100 input shaft Seal 112658 may be -- replaced by Chicago Rawhide / SKF 7465 (Eaton part number ER92999 replaced by SKF / Chicago Rawhide 7465) [Eaton 1100 selector shaft seal] Seal 112822 replaced by 93-9807 -- May be Chicago Rawhide / SKF 12407 Seal 114677 replaced by 100863 -- Replaced by Chicago Rawhide / SKF 9815 a guess. Seal 700413 replaced by 253-44 -- Replaced by Chicago Rawhide / SKF 7443 Seal 703333 replaces 9230 & 47-8030 -- Replaced by Chicago Rawhide / SKF 6105 Seal 707984 replaced by 253-44 -- Replaced by Chicago Rawhide / SKF 7443 Seal MW10390 -- Replaced by Chicago Rawhide / SKF 9878 Motorwheel? Used in snowthrower auger drive Seal MW10459 - 3/4" shaft Used in snowthrower auger drive
