The 2018 RedSquare Wheel Horse calendar.

Thank you to Terry (T-Mo) for putting together our 2017 RedSquare Calendar. This is free and not to be sold.

Here is the 2016 RedSquare Calendar courtesy of Jason Schahl & Steve Hilleshiem

Replacement for: Transmission Gear Uni-Drive 1958-1982 SM HR #A-1392.pdf This is a 600 DPI scan of a very good copy of this manual. From what I can tell the content is identical to the file that includes the following on the rear cover "0482 Revision P/N 492-4004". Front cover changed only with the price going from 2.00 to 3.50. I have gone through it page by page and came to this conclusion. I have never seen an original of the aforementioned version, but I have seen two different scans of it. The words on the photos are very difficult to read on those scans. This scan is much improved in quality compared to those. And since the content appears identical (other than front and rear covers) I am uploading it for your pleasure. There are a few pages I had to scan several times to get a really good version Additional notes 6/16/2020 - after spending considerable time comparing the two, side by side, I have found a few pages of the 0482 revision that are different than this file. They are as follows: 1) Page 12. Point number 5 is missing. See service bulletin 23 for the missing info. 2) Pages 32 and 51. Does not have the "Note" mentioning that service bulletin 252 covers conversion from limited slip to 8-pinion differential. 3) Page 50. Does not have "Note" referring to service bulletins 174 and 273 discussing differential bolt changes. I would advise that all users of this manual should be aware of the information in service bulletins 55, 60, 76, 80, 252, 273, 369, 394a and 425. There are a few other service bulletins on trnasmission, but they seem to be either superseded or the information is covered in this manual. I am also very curious if owners of an original copy of the 0482 version can read the captions within photos. It is quite clear that the ortho-film exposures on that version were darker, and I suspect that even on an original, that some photo captions may be hard to read. On the earlier version the text it a bit harder to read because of the shorter exposure, but it is certainly readable, and there's no doubt this version is more useful. It is clear that the book was type set once, and that the changes are a matter of pasting in the comments and re-shooting the negatives. Edits were a LOT more work back then. Enough work in fact, that Wheel Horse increased the price from $2 to $3.50 after they made these changes! I am pleased to see folks are downloading this! My next project is to find a good original of the Sundstrand manual so I can

Thank you all, this was fun. So many great photos to choose from. Enjoy! Trina

Service manual K91 K141 K161 K181 K241 K301 K321 K341 137 pages 6.35MB Good copy The following engines have the spark advance camshaft K141, Suffix prior to “C” K161, Suffix prior to “J” K181, Suffix prior to “D” K241, Suffix prior to “D” 1985 312-8 model 21-12K801 has a 3 amp charging system. 1986 414-8 model 31-14K801 has battery ignition

1 page from Demystification Guide #492-4509 Image rotated to place the start terminal at the top 1 page 123KB How to troubleshoot 111216 switch replaced by 103990 5-terminal 3-position key switch for battery ignition This switch requires a starter solenoid ---------------------------------------------------------------------------------------- Tractor Switch Ignition Battery ignition with electric start 103990 (Threads 5/8"-32) 5-terminal 3-position (B-R-A-I-S) Used 1974-1985 Replaces 111216 5-terminal 3-position 103990 5-terminal 3-position available 06/08 $15.61 from RCPW ---------------------------------------------------------------------------------------- Tractor Switch Ignition Battery ignition with electric start 111216 (Threads 5/8"-32) 5-terminal 3-position (B-R-I-A-S) Used 1986 and 1988-1997 111216 5-terminal 3-position replaced by 103990 --------------------------------------------------------------------------------------- Napa and Prime-Line replacement switch 7-01892 (9/16" mounting stem) Stens replacement switch 430-512 (9/16" mounting stem) Rotary replacement switch 31-1931 (9/16" mounting stem) Napa and Prime-Line 5-terminal connector body that uses Packard female spade terminals 7-016034 (With terminals and wire leads 7-01910) Stens 5-terminal connector body that uses Packard female spade terminals 430-206 (With terminals and wire leads 430-223) Rotary 5-terminal connector body with terminals and wire leads 31-6662 Bare 5-wire female plastic connector is Kohler 48 155 01 (This also used on the Kohler engine to tractor connector.) Tractor harness male connector is Toro 112185 and illustrated with the low oil switch. 82-12o502* - Correct 82 -12o502 - Not correct 82-12o502 - Suspicious and not checked or determined yet 103990 Battery ignition switch used on 1974 models 1-0140*, 1-0145*, 1-0353*, 1-0354*, 1-0356*, 1-0380*, 1 -0385, 1-0390*, 1-0480*, 1-0485*, 1-0490*, 1 -0495, 1-0510*, 1-0611*, 1-0630*, 1-0650* ***** 1974 C-120 8-Speed model 1-0353 - Listed in PSB #301E for 1973-74. Suspect 1973 12hp 8-Speed is wrong ? - Most likely a 1974 model using a 3 key-position switch - 1974 on Belgium list 1974 C-120 8-Speed model 1-0354 - Listed in PSB #301E for 1973-74. Suspect 1973 12hp 8-Speed is wrong ? - Most likely a 1974 model using a 3 key-position switch - 1974 on Belgium list 1975 models 1-0141*, 1 -0357, 1 -0375, 1-0381*, 1-0391*, 1-0395*, 1-0396*, 1-0481*, 1-0491*, 1-0511*, 1-0612*, 1-0631*, 1-0651* ***** 1976 models 61 -07K801, 61 -07K802, 61-08K801*, 61-08K802*, 61-08K803*, 61-08K804*, 61-10K801*, 61-10K802*, 61-10K803*, 61-10K804*, 61-12K801*, 61-12K802*, 61-12K803*, 61-12K804*, 61-12KS01*, 61-12KS02*, 61-12KS03*, 61-12KS04*, 61-16K801*, 61-16K802*, 61-16K803*, 61-16K804*, 61-16KS01*, 61-16KS02*, 61-16KS03*, 61-16KS04*, 61-16OS01*, 61-16OS02*, 61-20KS01*, 61-20KS02* ***** 1977 models 71 -07K801, 71-08K801*, 71-10K801*, 71-12K801*, 71-12KS01*, 71-12KS02*, 71-16K801*, 71-16K802*, 71-16KS01*, 71-16KS02*, 71-16OS01*, 71-20KS01* ***** 1978 models 81-08K801*, 81-10K801*, 81-12K801*, 81-12KS01*, 81-14K801*, 81-14KS01*, 81-16B801*, 81-16BS01*, 81-16K801*, 81-16KS01*, 81-16OS01*, 81-20KS01* ***** 1979 models 91-08K801*, 91-08K802*, 91-10K801*, 91-10K802*, 91-11B801*, 91-12K801*, 91-12K802*, 91-12KS01*, 91-14K801*, 91-14K802*, 91-14KS01*, 91-16B801*, 91-16B802*, 91-16BS01*, 91-16BS02*, 91-16K801*, 91-16KS01*, 91-16OS01*, 91-20KS01*, 91-20KS02* ***** 1980 models 01-08K801*, 01-10K801*, 01-11B803*, 01-12K801*, 01-12KE01*, 01-12KS01*, 01-14E801*, 01-14K801*, 01-14KE01*, 01-14KS01*, 01-16K801*, 01-16KE01*, 01-16KS01*, 01-16OS01*, 01-17K801*, 01-17K802*, 01-17KE01*, 01-17KS02*, 01-20KS00*, 02-08BP01*, 02-11BP02*, 02-11BX01*, 02-16BP01* ***** 1981 models 01-08K802*, 01-10K802*, 01-11B804*, 01-12K802*, 01-12KE02*, 01-14E801*, 01-14K802*, 01-14KE02*, 01-16K802*, 01-16KE02*, 01-17K802*, 01-17KE01*, 01-20KS00*, 02-08BP02*, 02-08BP03*, 02-11BP03*, 02-11BP04*, 02-11BX02*, 02-11BX03*, 02-16BP02*, 02-16BP03* ***** 1982 models 01-08K803*, 01-10K803*, 01-11BH01*, 01-12K803*, 01-14E801*, 01-14KE03*, 01-16KH01*, 01-17K803*, 01-17KE02*, 01-19KE01*, 02-11BH01* ***** 1983 models 01-14E801*, 01-14KE04*, 01-17KE03*, 11-08K801, 11-10K801, 11-12K801*, 11-17K801* ***** 1984 models 01-19KE02*, 11-10K802*, 11-12K802*, 11-14KE01*, 11-16K801*, 11-17KE01* ***** 1985 models 21-10K801*, 21-12K801*, 21-14K801*, 21-14KE01*, 31-16K801*, 31-17K801*, 31-17KE01* ***** 111216 Battery ignition switch used on 1986 models 21 - 08K801, 21 - 08K802, 21-10K802*, 21-10K803*, 21-12K802*, 21-12K803*, 21-12KE01*, 21-12KE02*, 31-14K801*, 31-16K802*, 31-17K802*, 31-17KE02*, 31 - 20KE01, B1-12R801*, C1-12R801* ***** 1987 111216 switch not used in 1987 1988 models 31-16OE01*, 31-18OE01*, 31-20OE01*, B1-16O801*, C1-20OE01*, E1 -12K801, E1-18OE01*, Z1-24OE01* ***** 1989 models 21 -10K806, 21 -12K806, 31 -14K804, 31-16O801*, 31-18OE02*, 31-20OE02*, B1-16O802*, C1-20OE02*, E1 -12K802, E1-18OE02*, Z1-24OE02* ***** 1990 models 31 -10K801, 31 -12K801, 31 -12KE01, 31-16O802*, 41-16OE01*, 41-20O801*, 41-20OE01*, R1 -12K801, R1 -12K802, R1-16O801*, R1-16O802*, R1-18OE01*, R1-18OE02*, Z1-24OE03* ***** 1991 models 31 -10K802, 31 -12K802, 31-16O803*, 32-10B502*, 32-10BE02*, 32-12B5A3*, 32-12BEA3*, 32 -12O502, 32 -12OE02, 41-20OE02*, 51 -12KE01, 51-16OE01*, R1-20OE01*, S2-12B502*, Z1-24OE04* ***** ------------------------------------------------------------------- 103990 Battery ignition switch used on 1992 models 41-20OE03*, R1-20OE02* ***** 111216 Battery ignition switch used on 1992 models 31 -10K803, 31 -12K804, 31-16O804*, 32-10B503*, 32-10BE03*, 32 -12O503, 32-12OE03*, 51 -12KE02, 51-16OE02*, R1 -12K804, R1-16O804*, Z1-24OE05* ***** --------------------------------------------------------------------------------------------------------------------- 103990 Battery ignition switch used on 1993 models 73501*, 73520e* ***** 111216 Battery ignition switch used on 1993 models 7 3380, 7 3400, 73420*, 73421*, 73440*, 74140* ***** --------------------------------------------------------------------------------------------------------------------- 103990 Battery ignition switch used on 1994 models 73520*, 74140* ***** 111216 Battery ignition switch used on 1994 models 7 3380, 7 3400, 7 3401, 73420*, 73421*, 73440*, 73501* ***** --------------------------------------------------------------------------------------------------------------------- 103990 Battery ignition switch used on 1995 models 73520e, 74140*Z ***** 111216 Battery ignition switch used on 1995 models 7 3400, 7 3401 x 3, 73420* x 3, 73421* x 2, 73440* x 2, 73501* x 4, 73520e* ***** --------------------------------------------------------------------------------------------------------------------- 1996 models 7 3400, 7 3401, 73420*, 73421*, 73423*, 73501*, 73502*, 73521*e ***** 1997 models 73422*, 73423*, 73441*e, 73502*, 73521*e *****

You will notice the Chicago Rawhide / SKF seal spec sheets show a WastWatcher seal. That seal may be easier to find as they have determined it is a part number that will replace many seals with the same dimensions except for width and have characteristics that meet or exceed the seal it replaces. A link to the SKF interchange http://www2.chicago-rawhide.com/popup_parts_lookup_457012.htm Toro / Wheel Horse part numbers are first on each line Seal 47-8030 Use 703333 -- Replaced by Chicago Rawhide / SKF 6105 Seal 56-2820 replaces 56-3270 & 112604 Eaton 1100 input shaft Seal 56-3130 may be -- replaced by Chicago Rawhide / SKF 7465 (Eaton part number ER92999 replaced by SKF / Chicago Rawhide 7465) [Eaton 1100 selector shaft seal] Seal 56-3270 replaced by 56-2820 Eaton 1100 input shaft Seal 83-2830 replaces 1234 -- Replaced by Chicago Rawhide / SKF 7627 Seal 83-2840 replaces 1257, 100573 -- Available only from Toro - This seal mounts over the axle tube - See photo at the top Seal 93-9807 replaces 112822 -- May be Chicago Rawhide / SKF 12407 Seal 253-44 replaces 1117, 108357, 700413, 707984 -- Replaced by Chicago Rawhide / SKF 7443 Seal 1011 -- Replaced by Chicago Rawhide / SKF 9859 Seal 1117 replaced by 253-44 -- Replaced by Chicago Rawhide / SKF 7443 Seal 1213 replaced by 100443 -- Replaced by Chicago Rawhide / SKF 11050 or National 340835 Seal 1232 replaced by 100863, See 114677, 9240 -- Replaced by Chicago Rawhide / SKF 9815 Seal 1234 replaced by 83-2830 -- Replaced by Chicago Rawhide / SKF 7627 or National 471643 Seal 1257 replaced by 83-2840 -- Available only from Toro - This seal mounts over the axle tube - See photo at the top Seal 1303 replaced by 100441 -- Replaced by Chicago Rawhide / SKF 7410 Seal 1447 replaced by 5959 -- Replaced by Chicago Rawhide / SKF 4911 Seal 1461 replaced by 100442 -- Replaced by Chicago Rawhide / SKF 6105 Seal 1482 replaced by 103118 -- Replaced by Chicago Rawhide / SKF 12330 Seal 3373 -- Replaced by Chicago Rawhide / SKF 10035 or National 204005 Seal 5958 replaced by 100607 -- Replaced by Chicago Rawhide / SKF 9878 Seal 5959 replaces 1447 -- Replaced by Chicago Rawhide / SKF 4911 Seal 6449 -- Replaced by Chicago Rawhide / SKF 11124 (Original 6449 is 1/2" wide) Seal 6663 -- Replaced by Chicago Rawhide / SKF 14810 Seal 7877 -- Replaced by Chicago Rawhide / SKF 7475 (Federal Mogul 480821 = CR 7474 , Original seal 9008000-7501 = CR 7443) Seal 7963 -- Replaced by Chicago Rawhide / SKF 6904 Seal 9230 replaced by 703333 -- Replaced by Chicago Rawhide / SKF 6105 Seal 9240 May be same as 1232, 100863 and 114677 -- Replaced by Chicago Rawhide / SKF 9815 a guess. Used on tiller with 5571 bushing Seal 100441 replaces 1303 -- Replaced by Chicago Rawhide / SKF 7410 Seal 100442 replaces 1461 -- Replaced by Chicago Rawhide / SKF 6105 (CR 11050 to replace 100442 @ SKF is wrong) Seal 100443 replaces 1213 -- Replaced by Chicago Rawhide / SKF 11050 or National 340835 Seal 100573 replaced by 83-2840 -- Available only from Toro - This seal mounts over the axle tube - See photo at the top Seal 100607 replaces 5958 -- Replaced by Chicago Rawhide / SKF 9878 Seal 100608 -- Replaced by Chicago Rawhide / SKF 6904 Seal 100863 Replaces 1232, 114677, 9240 -- Replaced by Chicago Rawhide / SKF 9815 a guess. Seal 103103 -- Replaced by Chicago Rawhide / SKF 8620 Seal 103118 replaces 1482 -- Replaced by Chicago Rawhide / SKF 12330 Seal 103269 or 103277 -- Replaced by Chicago Rawhide / SKF 10740 (National 471762 seal for 5-0900 deck thinner than originals) Seal 103461 -- Replaced by Chicago Rawhide / SKF 6763 Seal 106075 -- Replaced by Chicago Rawhide / SKF 9907 (Mower spindle original had double-lip) Seal 108357 replaced by 253-44 -- Replaced by Chicago Rawhide / SKF 7443 Seal 112604 replaced by 56-2820 Eaton 1100 input shaft Seal 112658 may be -- replaced by Chicago Rawhide / SKF 7465 (Eaton part number ER92999 replaced by SKF / Chicago Rawhide 7465) [Eaton 1100 selector shaft seal] Seal 112822 replaced by 93-9807 -- May be Chicago Rawhide / SKF 12407 Seal 114677 replaced by 100863 -- Replaced by Chicago Rawhide / SKF 9815 a guess. Seal 700413 replaced by 253-44 -- Replaced by Chicago Rawhide / SKF 7443 Seal 703333 replaces 9230 & 47-8030 -- Replaced by Chicago Rawhide / SKF 6105 Seal 707984 replaced by 253-44 -- Replaced by Chicago Rawhide / SKF 7443 Seal MW10390 -- Replaced by Chicago Rawhide / SKF 9878 Motorwheel? Used in snowthrower auger drive Seal MW10459 - 3/4" shaft Used in snowthrower auger drive

Toro Service manual 55 pages 3.09MB Revised 1/95 Also used #810697R1 manual number Listed in 1989 518-H TIPL as #965-0762 JD Onan service manual 224 pages 3.04MB Onan P216G-I/10538A used in 1988 516-H model 31-16OE01 Onan P216G-I/10691B used in 1988 316-8 model B1-16O801 1989 316-8e model B1-16O802 1990 316-8e model R1-16O801 Onan P216G-I/10779B used in 1989 416-8 model 31-16O801 Onan P216G-I/10975D used in 1996 416-H model 73421 Serial 6900001-6999999 Onan P216G-I/10976C used in 1990 416-8 model 31-16O802 1990 416-H model 41-16OE01 1990 316-8e model R1-16O802 1991 416-8 model 31-16O803 Serial 1000001-1999999 1991 416-8e model R1-16O803 Serial 1000001-1999999 - No record at Toro - This is possibly a 316-8e - Engine may be wrong 1991 416-H model 51-16OE01 Serial 1000001-1999999 1992 416-8 model 31-16O804 Serial 2000001-2999999 1992 416-H model 51-16OE02 Serial 2000001-2999999 Onan P216G-I/10976D used in 1992 316-8e model R1-16O804 Serial 2000001-2999999 - (This may be a 416-8e) 1993 416-8 model 73420 Serial 3900001-3999999 1993 416-8e model 73440 Serial 3900001-3999999 1993 416-H model 73421 Serial 3900001-3999999 1994 416-8 model 73420 Serial 4900001-4999999 1994 416-8e model 73440 Serial 4900001-4999999 1994 416-H model 73421 Serial 4900001-4999999 1995 416-8 model 73420 Serial 5900001-5000614 - Mid-year change 1995 416-8e model 73440 Serial 5900001-5900222 - Mid-year change 1995 416-H model 73421 Serial 5900001-5901046 - Mid-year change Onan P216G-I/10976G used in 1995 416-8 model 73420 Serial 5900615-5999999 - Mid-year change 1995 416-8e model 73440 Serial 5900223-5999999 - Mid-year change 1995 416-H model 73421 Serial 5901047-5999999 - Mid-year change 1996 416-8 model 73420 Serial 6900001-6999999 1996 416-8 model 73422 Serial 6900001-6999999 1996 416-8e model 73441 Serial 69000001-69999999 1996 416-H model 73423 Serial 6900001-6999999 1997 416-8 model 73422 Serial 7900001-7999999 1997 416-8 model 73441 Serial 7900001-7999999 1997 416-H model 73423 Serial 7900001-7999999 Onan P218G-I/10539A used in 1988 518-H model 31-18OE01 - Mid-year change 1988 518-HE model E1-18OE01 1989 518-He model E1-18OE02 1990 518-He model R1-18OE01 1990 518-He model R1-18OE02 Onan P218G-I/10539B used in 1989 518-H model 31-18OE02 - Mid-year change Onan P220G-I/10540A used in 1988 520-H model 31-20OE01 Onan P220G-I/10540B used in 1989 520-H model 31-20OE02 Onan P220G-I/10541A used in 1988 520-HC model C1-20OE01 Onan P220G-I/10873A used in 1989 520-HC model C1-20OE02 Onan P220G-I/10955C used in 1991 520-H model 41-20OE02 Serial 1000001-1999999 1992 520-H model 41-20OE03 Serial 2000001-2999999 Onan P220G-I/10955D used in 1992 520-He model R1-20OE02 Serial 2000001-2999999 1993 520-H model 73501 Serial 39000001-39999999 1993 520-He model 73520 Serial 39000001-39999999 1994 520-H model 73501 Serial 49000001-49999999 1994 520-H model 73520 Serial 4900001-4999999 1995 520-H model 73501 Serial 59000001-59999999 1995 520-He model 73520 Serial 5900001-5900177 - Mid-year change Onan P220G-I/10955G used in 1995 520-He model 73520 Serial 5900178-5999999 - Mid-year change 1996 520-H model 73501 Serial 69000001-69999999 1996 520-H model 73502 Serial 6900001-6999999 1996 520-He model 73521 Serial 6900001-6999999 1997 520-H model 73502 Serial 7900001-7999999 1997 520-H model 73521 Serial 7900001-7999999 Onan P220G-I/10956C used in (This may be a typo for Onan P220G-I/10955C) 1990 520-8 model 41-20O801 1990 520-H model 41-20OE01

Operator manual Illustrated parts list 6 pages 3.73MB Illustrated parts list #A-7136 Includes PSB #023 #052 #058 #060 #080 10 pages 938.48KB Engines used according to Toro Clinton B1290-1107 Kohler K91-31307A Kohler K91-31388A Electric start kit Electric starter kit model EC-35 for Clinton engine - Listed for 1958 and 1959 Electric starter kit model EK-35 for Kohler engine - Listed for 1958 and 1959 6-12 tire chains model TC-12 - Listed for 1958 and 1959 Seat cushion Foam rubber with imitation leather cover model FC-24 - Listed for 1958 and 1959 Transmission drive belt 1567 - (4L x 29" or 1/2" x 29") Details & Attachments 2 pages 107.33KB 1958 model RJ-58 1958 serial numbers that have shown up for the RJ-58 Early models used Kohler K90T-27107D equipped with a Schnacke recoil unit with a backup rope starter contained under the recoil assembly and an oil bath air filter. 00005 00251 01099 - No casting date on trans. Leather gearshift boot, large, round rear wheel hubs, "slab" hitch, replacement engine 01188 - Has round rear wheel hubs 01516 01768 01789 - No casting date on trans. Leather gearshift boot, 3-ear triangular rear wheel hubs, "slab" hitch, Clinton engine with Schnacke recoil 01797 01871 02525 03177 03501 - Located in UK 03796 - Kohler K90T-27107D with serial 364044 equipped with a Schnacke recoil unit with a backup rope starter contained under the recoil assembly and an oil bath air filter. 04883 04885 05000 05619 05714 05798 06528 - May be 16528 06749 06771 07633 07649 - Transmission J12-8 October 12, 1958 07725 08440 08612 09284 09337 - Hard to read 10163 11432 11628 - # 3521 spline gear with 10 splines changed to 11 splines in 5003 and 5010 transmissions at serial # 11628 PSB #023 11916 12221 - B3-9 trans casting date - Kohler K91 engine with Schnacke recoil 12291 14473 14713 16097 16528 - May be 06528 166x6 16868 - F4-9 trans casting date - Kohler K91 engine with Fairbanks recoil, solid pan seat without holes 18348 June 2023 18500 and lower Late 1958 units came with a Kohler K-91T-31307A equipped with a Schnacke recoil unit with a backup rope starter contained under the recoil assembly and an oil bath air filter. ------------------------------------------------------------------------------------------------------------------ Details & Attachments 2 pages 106.94KB 1959 model RJ-59 1959 serial numbers that have shown up for the RJ-59 Early 1959 units came with a Kohler K-91T-31307A equipped with a Schnacke recoil unit with a backup rope starter contained under the recoil assembly and an oil bath air filter. 18501 and up - Possible 1100 units built 20078 - Located in UK 203xx 21033 292xx 21900 - 1960 Suburban 400 began production at serial #21900 somewhere around Aug-Oct 1959. Late model RJ-59 tractors with a Kohler would have a K-91T-31388A with the Fairbanks recoil starter and paper air filter element. The 31388A was also used on the 1960 Suburban 400. K91T-31388A Serial 425251 found on RJ-59

Service manual 69 pages 16.46MB Formerly #A-1391 and 803402 Hydrogear and Piston-Piston 1965 - 1982 (4 parts) Part 1 - 34 pages 4.85MB Pages 1 to 31 Page 18 was a blank page for notes - removed to save space Part 2 - 7 pages 3.1MB Pages 32 to 38 Part 3 - 6 pages 2.6MB Pages 39 to 44 Part 4 - 19 pages 3.29MB Pages 45 to 63 Hydrogear or Hydro-gear overhaul by daveoman 1966 17 pages 3.3MB Piston-piston overhaul by daveoman 1966 20 pages 2.6MB Sundstrand 90-1136 used on 1973 10hp Automatic model 1-0475 1973 12hp Automatic model 1-0465 1973 14hp Automatic model 1-0435 1974 B-100 Automatic model 1-0510 1974 C-120 Automatic model 1-0485 1974 C-120 Automatic model 1-0490 1974 C-120 Automatic model 1-0495 1975 B-100 Automatic model 1-0511 1975 C-120 Automatic model 1-0491 1976 C-120 Automatic model 61-12KS01 1976 C-120 Automatic model 61-12KS02 1976 C-120 Automatic model 61-12KS03 1976 C-120 Automatic model 61-12KS04 1977 C-120 Automatic model 71-12KS01 1977 C-120 Automatic model 71-12KS02 Sundstrand 90-1137 used on 1973 18hp Automatic model 1-0600 1973 18hp Automatic model 1-0601 1973 18hp Automatic model 1-0610 1973 18hp Automatic model 1-0620 1974 D-160 Automatic model 1-0650 1974 D-180 Automatic model 1-0611 (D-180 axles 101893 reported to be 16-1/2" long) 1974 D-200 Automatic model 1-0630 1975 D-160 Automatic model 1-0651 1975 D-180 Automatic model 1-0612 1975 D-200 Automatic model 1-0631 1976 D-160 Automatic model 61-16OS01 1976 D-160 Automatic model 61-16OS02 1976 D-200 Automatic model 61-20KS01 1976 D-200 Automatic model 61-20KS02 1977 D-160 Automatic model 71-16OS01 1977 D-200 Automatic model 71-20KS01 Sundstrand 90-1140 used on 1974 C-160 Automatic model 1-0480 1975 C-160 Automatic model 1-0481 1976 C-160 Automatic model 61-16KS01 1976 C-160 Automatic model 61-16KS02 1976 C-160 Automatic model 61-16KS03 1976 C-160 Automatic model 61-16KS04 1977 C-160 Automatic model 71-16KS01 1977 C-160 Automatic model 71-16KS02 Sundstrand 90-1172 used on 1978 C-121 Automatic model 81-12KS01 1979 C-121 Automatic model 91-12KS01 1979 C-121 Automatic model 91-12KS91 - Guess Sundstrand 90-1173 used on 1978 C-141 Automatic model 81-14KS01 1978 C-161 Automatic model 81-16KS01 1978 C-161 Twin Automatic model 81-16BS01 1978 D-160 Automatic model 81-16OS01 - Guess 1978 D-200 Automatic model 81-20KS01 - Guess 1979 C-141 Automatic model 91-14KS01 1979 C-161 Automatic model 91-16KS01 1979 C-161 Automatic model 91-16KS91 - Guess 1979 C-161 Twin Automatic model 91-16BS01 1979 C-161 Twin Automatic model 91-16BS02 1979 D-160 Automatic model 91-16OS01 - Guess 1979 D-160 Automatic model 91-16OS02 - Not listed @ Toro and may be an invalid model number - Guess 1979 D-200 Automatic model 91-20KS01 - Guess 1979 D-200 Automatic model 91-20KS02 - Guess 1980 C-125 Automatic model 01-12KS01 1980 C-145 Automatic model 01-14KS01 1980 C-165 Automatic model 01-16KS01 1980 C-165 Automatic model 01-16KS91 - Guess 1980 C-175 Twin Automatic model 01-17KS02 1980 D-160 Automatic model 01-16OS01 - Guess 1980 D-200 Automatic model 01-20KS00 - Guess 1981 D-160 Automatic model 01-16OS01 - Not listed @ Toro - Guess 1981 D-200 Automatic model 01-20KS00 - Guess Sundstrand 90-2046 Hydro-gear or Hydrogear used on 1968 Charger 9 model 1-7931 1968 Charger 9 model 1-7932 1968 Charger 12 model 1-7231 1968 Electro 12 model 1-7235 1969 Charger 10 model 1-7041 1969 Charger 12 model 1-7241 1969 Electro 12 model 1-7245 1970 Charger 12 model 1-7251 1970 Charger 12 model 1-7252 1970 Charger 12 model 1-7253 1970 Electro 12 model 1-7255 1971 Bronco 14 model 1-0420 1971 Bronco 14 model 1-0421 1971 Charger 12 model 1-0400 1972 Bronco 14 model 1-0422 1972 Bronco 14 model 1-0423 1972 Charger 10 model 1-0410 1972 Charger 12 model 1-0401 1972 Charger 12 model 1-0402 1973 10hp Automatic model 1-0470 1973 12hp Automatic model 1-0460 1973 14hp Automatic model 1-0430 1973 16hp Automatic model 1-0440 (7052 spring is 1-5/16" long, 5/16" OD with .0645" wire diameter) Sundstrand 90-2062 Hydro-gear or Hydrogear used on 1969 GT-14 model 1-7441 1970 GT-14 model 1-7451 1970 GT-14 model 1-7452 1970 GT-14 model 1-7453 1971 GT-14 model 1-0500 1971 GT-14 model 1-0501 1972 GT-14 model 1-0502 1972 GT-14 model 1-0503 1973 GT-14 model 1-0502-8 - Listed in attachment interchange - Not listed at Toro Sundstrand 3100077 Hydro-gear or Hydrogear used on 1965 model 875 1965 model 1075 1966 model 876 1966 model 1076 - Not listed @ Toro 1966 model 1276 1967 model 877 1967 model 1077 - Not listed @ Toro 1967 model 1277

35 pages 453.25KB Dated February 1997 Click on a model line in the index and it will take you to a single page showing all the spindle assemblies used on that model over the years. This may be publication #810415R2 replaced by 492-0393.

Small Engine Spark Plug Catalog from Champion. Great Technical info towards the end of the catalog about reading plugs and removal/installation as well as application charts for many small engines. For those that just want a Champion Spark Plug Decoder chart, just download the image instead of the catalog.

We are so fortunate that Trina has once again pulled together our 2025 RedSquare Calendar. Thank you Trina for your efforts, you do amazing work!

Operator manual #810209R1 16 pages Dated 5/80 Same manual for 1980 model 06-42ST01 and 1981-1982 model 06-42ST02 IPL from Toro Master Parts Viewer 5 pages 259.60KB 1-stage Includes PSB's #230 #356 #377 #431 Fits C-Series tractors Drive belt 9750 (5L x 69" or 5/8" x 69") Snowthrower 1979 42in model 96-42ST01 1979 serial numbers that have shown up for the 96-42ST01 00826x - Build date 1978 8162 June 11 Sunday 008419 - Build date 1978 8165 June 14 Wednesday 008449 008729 - Build date 1978 8167 June 16 Friday 009075 - Build date 1978 8171 June 20 Tuesday 009180 - Build date 1978 8171 June 20 Tuesday 009234 - Build date 1978 8172 June 21 Wednesday - Located in Sweden 009268 - Build date 1978 8172 June 21 Wednesday 009274 - Build date 1978 8172 June 21 Wednesday - Located in Norway 009662 010351 - Build date 1978 8179 June 28 Wednesday 010783 - Build date 1978 8184 July 03 Monday 011338 011492 - Build date 1978 8188 July 07 Friday 011558 011876 019002 019147 019384 019553 020150 020224 020231 020272 020341 020772

The 1985 will have a solid hood top and the 1986 will have a louvered hood top. Tractor weight 739 lbs. Lube chart SS Details & Attachments 3 pages 118.67KB Louvers in the hood.in 1986 Transmission drive belt 108501 - (HB/5L x 81.50" or 5/8" x 81.5") 1986 417-A Twin Automatic model 31-17KE02 1986 serial numbers that have shown up for the 31-17KE02 15060 15301 Link

Operator manual Illustrated parts list Wiring 12 pages 1.88MB Dated 1/10/61 Another scan of the above with figure 3 for the 701 missing 11 pages 1.64MB Model 401 Kohler spec number in details page is wrong - k91-41437A should be K91-31388A 551 Wiring revised pdf 1 page 288KB 701 Wiring revised pdf 1 page 340KB ID plates and serial numbers by CasualObserver 1961 Suburban - early used the top section of the 1960 plate, cut off and screwed to the hood stand. 1961 Suburban - later used a decal on the right frame rail ahead of the foot peg. Tractor drive belt for 401 and 551 #1569 - (4L x 28.95" or 1/2" x 28.95") Tractor drive belt for 701 #1576 replaced by 9691 - 1/2" x 70" ----------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Starter/Generator belt Original Wheel Horse 1583 nla Used on 6, 7, 8hp Kohler Starter generator {3Lx33" in belt charts is 3/8" x 33" but some applications use a shorter belt. Belt should have raw rubber sides for grip.} 3V315 Gates .38"x31.5" 3V315 Napa .38"x31.5" Kohler #231446 shown in the Kohler parts list Gates replacement 7330 - .410" x 33.58" with 36 degree angle. Replacement is notched with raw rubber sides Kohler #231605 Starter generator belt Replaces 232613 [.41"x32.08" 36 degree] PSB #061 Should use raw rubber edge belt for grip 7315 Gates .41"x32.08" 36 degree 25-7315 Napa .41"x32.08" 36 degree Small Block Kohler Napa # 25-7320 .41" wide x 32.5" long Side angle 36 degrees Cross section HC41 --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Ignition switch with 3 terminals for 550 is 3656 and nla. See PSB #069 Not documented - 1961 CBR-327 front mounted sickle bar mower for the 701 1 page of part number corrections 30.15KB Model 701 only model to use braces on the rear fenders because the tool box was short. 701 used Kohler K161S-28522E. Toro have the engine used as K161S-28622E as used on the 702 3 photos 463KB supplied by CasualObserver for dimensions. Brace not in the parts list. Lube chart SS Details & Attachments 2 pages 103.48KB 1961 model 401 1961 serial numbers that have shown up for the 401 42646 - Reported to be the first 401 42908 43062 43082 43380 43437 43755 43787 43810 43867 43950 43963 43975 44034 44506 44641 48188 49361 49925 49982 50023 50053 50181 50217 50930 - May be a 551 or 701 53101 53166 53217 56299 56547 56660 56806 - May be a 551 56870 56936 - May be a 551 57103 - May be a 551 60304 60315 60419 60436 60610 60695 60719 -------------------------------------------------------------------- 551 frame is 6" wide Details and attachments 2 pages 103.99KB 1961 model 551 1961 serial numbers that have shown up for the 551 41724 - May be a 701, misread or typo 46309 46412 46574 46630 46863 46891 46906 47115 49694 50930 - May be a 401 or 701 51705 52220 52596 53812 53882 53890 56806 - May be a 401 56936 - May be a 401 57103 - May be a 401 57322 58532 59014 59148 59745 [M] ---------------------------------------------------------------------- Details and attachments 3 pages 117.93KB 1961 model 701 1961 serial numbers that have shown up for the 701 41724 - May be a 551, misread or typo 45709 47457 47479 47676 47754 47770 47793 47969 48085 48110 48210 48226 48232 48234 48237 48289 48317 48358 48393 48411 48441 48584 48596 48684 48695 48723 48732 48736 48773 48812 48832 - Model a guess 48852 48862 48911 48939 48927 48967 48982 49022 49026 - Now decaled a 702 49116 49118 49122 50930 - May be a 401 or 551 51222 51337 51407 51434 51588 51630 51688 51691 51858 - Kohler K161S 51887 51908 51952 51967 52014 54100 54140 54157 54209 54276 54395 54480 54530 54545 54609 - Model and year a guess 54666 54695 54735 54817 54836 54867 54872 55082 55894 55895 55907 55939 55968 55978 56000 56015 56108 56141 56142 56193 56991 57012 57014 57078 57165 57222 57662 57673 57707 57720 57782 57797 57811 57834 57854 57888 58037 58048 58246 58351 58364 59247 59279 59309 59366 59382 59385 - Located in the UK 59479 59480 59520 59960 59963 59969 [M] To see the above in consecutive order go to

Operator manual #324-325 IPL Wiring 16 pages 2.07MB Change to tow valve 1 page 187KB Wiring Color pdf 1 page 309KB Long frame 45-1/2" wheelbase Tractor drive belt 7927 and no longer available from Toro - (4L x 78.0" or 1/2" x 78") Starter/generator belt Kohler 10hp, 12hp - 235262 (7345 Gates .410" x 35.09" 36 degree) (25-7345 Napa .410" x 35.09" 36 degree) Wheel Horse 1593 (3L x 34.4") - nla (Gates replacement 6735 3/8" x 35" 38 degree) Lube chart SS 1967 model 1077 - Not listed at Toro. Used Kohler K241S-46333d Uses the 5054 hydro transmission identified at Toro as 3100077 1967 serial numbers that have shown up for the 1077 277830 278083 291339 291603 291676 291895 291998 329545 ------------------------------------------------------------------------------ Tractor drive belt 7927 and no longer available from Toro - (4L x 78.0" or 1/2" x 78") Starter/generator belt Kohler 10hp, 12hp - 235262 (7345 Gates .410" x 35.09" 36 degree) (25-7345 Napa .410" x 35.09" 36 degree) Wheel Horse 1593 (3L x 34.4") - nla (Gates replacement 6735 3/8" x 35" 38 degree) Details & Attachments 4 pages 120.08KB 1967 model 1277 - Uses the 5054 hydro transmission identified at Toro as 3100077 1967 serial numbers that have shown up for the 1277 273283 302095 302308 302373 302403 322563 322607 322729 322869 322882 329586 363188

Operator manual #877 IPL Wiring 16 pages 2.90MB Wiring Color pdf 1 page 298KB Change to tow valve 1 page 187KB Tractor drive belt 6146 replaced by 8005 and both no longer available from Toro - (4L x 72" or 1/2" x 72") Starter/Generator belt Original Wheel Horse 1583 nla Used on 6, 7, 8hp Kohler Starter generator {3Lx33" in belt charts is 3/8" x 33" but some applications use a shorter belt. Belt should have raw rubber sides for grip.} 3V315 Gates .38"x31.5" 3V315 Napa .38"x31.5" Kohler #231605 Starter generator belt Replaces 232613 [.41"x32.08" 36 degree] PSB #061 Should use raw edge belt 7315 Gates .41"x32.08" 36 degree 25-7315 Napa .41"x32.08" 36 degree Small Block Kohler Napa # 25-7320 .41" wide x 32.5" long Side angle 36 degrees Cross section HC41 Lube chart SS Details & Attachments 3 pages 116.01KB 1967 model 877- Uses the 5052 hydro transmission identified at Toro as 3100077 1967 serial numbers that have shown up for the 877 278823 278986 279069 279313 314097

Fits long frame tractors Front-End Loader Manual #810092R1 14 pages 3.5MB Pump drive belt Gates 6827 (1/2" x 27") 1974 model 97-40FL01 1975 model 97-40FL01 1976 model 97-40FL01 1977 model 97-40FL01 1978 model 97-40FL01 1979 model 97-40FL01 1979 serial numbers that have shown up for the 97-40FL01 005022 - Build date 1978 8342 December 08 Friday 005177 - Build date 1979 954 February 23 Friday 005193 - Build date 1979 954 February 23 Friday 005194 - Build date 1979 954 February 23 Friday Fel DNA 1974-1979 model 97-40FL01 replaced by 1980-1984 model 07-40FL01

Operator manual #803420 IPL 14 pages 673.66KB Revised 11/74 Fits 1975 B-100 and C-Series tractors plus prior comparable 8-speed and automatic models Includes PSB's #180A #184 #T010 #T91-P 14 Drive belt # 1599 (HA x 139.00in 1/2" x 139") If used on later twin-cylinder models use belt # 103635 which has been replaced by # 110265 (1/2" x 141.00") Tiller 1975 36in model 7-1252 1975 serial numbers that have shown up for the 7-1252 076156 081918 093582 093638 099043 099388 111392 111787 134453 145272 145583 145617 145813 146014 154781 154952 155151 189506

Operator manual #1-7245 IPL Wiring 16 pages 2.16MB - 1-7245 16 pages 1.88MB - 1-7245-P Dated 6/20/68 Wiring Color pdf 1 page 374KB 1-7245-P - Ammeter drawn in at the ignition switch Terminals on 8362 magneto ignition switch may not be identified 1 page 126KB 5955 Sundstrand hydro pump gasket nla - 102759 gasket should work Tractor drive belt # 7478 replaces # 4535 - (HB/5L x 84.22" or 5/8" x 84.22") PSB #084 #102 #104 #126 #127 #128 #134 #437B #12 20 pages 507.72KB Lube chart SS Details & Attachments 3 pages 115.75KB 1969 Electro 12 model 1-7245 - Uses Kohler K301S-47147c with breakerless magneto ignition 1969 serial numbers that have shown up for the 1-7245 521731 521757 542737 542883 542888 567538 587106 588402 598471 615059

Operator manual #A-5090 IPL Wiring 12 pages 2.01MB Wiring Color pdf 1 page 296KB Tractor drive belt for 857 #9691 - 1/2" x 70" Gates 6870 Napa 4L700W Starter/Generator belt Original Wheel Horse 1583 nla Used on 6, 7, 8hp Kohler Starter generator {3Lx33" in belt charts is 3/8" x 33" but some applications use a shorter belt. Belt should have raw rubber sides for grip.} 3V315 Gates .38"x31.5" 3V315 Napa .38"x31.5" Kohler #231605 Starter generator belt Replaces 232613 [.41"x32.08" 36 degree] PSB #061 Should use raw rubber edge belt for grip 7315 Gates .41"x32.08" 36 degree 25-7315 Napa .41"x32.08" 36 degree Small Block Kohler Napa # 25-7320 .41" wide x 32.5" long Side angle 36 degrees Cross section HC41 Original ignition switch 4988 replaced by 7263 No decal on belt guard. Indentation was dropped on 4993 guard in 1967 Last line of the parts list is missing Item 139 - 920127-4 Lockwasher 9/16 Item 186 - 6998 Decal Grille Lube chart SS Details & Attachments 3 pages 114.91KB 1967 model 857 1967 serial numbers that have shown up for the 857 266108 266307 266388 266526 266622 266896 266949 284035 284158 290859 290869 29116x 291215 306554 306723 306820 307114 307220 307426 307477 325035 325050 325396 325402 333992 336561 - Located in UK 336677 336700 336833 336998 372790 372875

Operator manual IPL 4 pages 442.03KB 4 pages 675KB Ride-Away Jr RJ-25 RJ-35 Late RJ-35 models used Kohler K90T-27107D equipped with a Schnacke recoil unit with a backup rope starter contained under the recoil assembly and an oil bath air filter. One found with K90T-27107D serial 336163 in the UK 1st Tractor drive belt (RJ-35 with 6", 6-1/2", 7" jackshaft pulley) - WH 1564 nla {4Lx18.9" or 1/2" x 19"} - Found on belt sleeve 1st Tractor drive belt (RJ-35 with 6", 6-1/2", 7" jackshaft pulley) - WH 1556 nla {4Lx20" or 1/2" x 20"} - Found in manual 2nd Tractor drive belt (RJ-35 with 6" jackshaft pulley) ------WH 1566 nla {4Lx35" or 1/2" x 35"} Use with 1556 belt - Found on belt sleeve 2nd Tractor drive belt (RJ-35 with 6-1/2" jackshaft pulley) - WH 1553 nla {4L/Ax36" or 1/2" x 36"} Use with 1556 belt 2nd Tractor drive belt (RJ-35 with 7" jackshaft pulley) ------ WH 1552 nla {4Lx37" or 1/2" x 37"} Used with 1556 belt From February 1, 1956 price list Brake Attachment model BA-35 for the riding tractors

Thank you to Trina who once again killed it for our 2024 RedSquare Calendar

Operator manual #3316-426 12 pages 4.60MB IPL #3317-537 8 pages 144.93KB Fits 300 400 500-Series tractors Drive belt 116332 (HB x 64.50" or 5/8" x 64.5") Belt tension spring 117545 nla. Approx 14-1/2" long Coil at one end approx 10-1/2" - 10-3/4" long (///////////////------) Coil diameter approx 7/8" OD Wire diameter approx .100" Snowthrower 1995 44in model 79361 Serial 5900001-5999999 1995 serial numbers that have shown up for the 79361 5900105 5900151 5900244 5900335 5900443 5900550 5900791 5900818 5901040 5901227 5901318 5901428 5901523 5901593 5901831

Parts list only with PSB #338B corrections 6 pages 1.35MB Wiring for 1056 should be the same Revised pdf 1 page 304KB Long frame tractor Transmission drive belt 1586 replaced by 9714 (HA x 76" or 1/2" x 76") Starter/generator belt Kohler 10hp, 12hp - 235262 (7345 Gates .410" x 35.09" 36 degree) (25-7345 Napa .410" x 35.09" 36 degree) Wheel Horse 1593 (3L x 34.4") - nla (Gates replacement 6735 3/8" x 35" 38 degree) Uses Kohler K241S-462198 (This should be K241S-46219a) with 1" crankshaft, starter/generator and battery ignition Same as 1056 except for engine and pto. 3 pint oil capacity (PT-6 is wrong Should be PT-7) pto as standard equipment, Uses 6936 engine pulley for 1" crankshaft PT-6 fits 1-1/8" crankshaft Ignition switch 4988 3-terminal 3-position replaced by 7263 Lube chart SS - Not in chart but same as 1055 model Details & Attachments 4 pages 118.10KB 1966 model 1046 1966 serial numbers that have shown up for the 1046 261312 261326 261340 261356 261373 261380 261387 261398 261402 261403 261428 261490 261522 261523 261524 261567 261568

Operator manual Illustrated parts list 8 pages 847.19KB Illustrated parts list #A-7136 12 pages 981.18KB Serial number 1960 Suburban - Stamped into the metal throttle/choke plate just under the upper screw. (CasualObserver) Tractor drive belt for 400 and 550 #1569 - (4L x 28.95" or 1/2" x 28.95") Wheel Horse # 1014 clutch pedal spring replaced by 83-2730 4.500" between hooks, .070" wire, .520" coil OD, .380 coil ID, 3.570" coil length, 52 + 2 half coils Ignition switch with 3 terminals for 550 is 3656 and nla. See PSB #069 According to operator manual optional starter is activated by push button. Magneto ignition controlled by throttle control. Lube chart SS Details and attachments 2 pages 05.19KB 1960 model 400 1960 serial numbers that have shown up for the 400 21900 - 1960 Suburban 400 began production at serial #21900 somewhere around Aug-Oct 1959.- CasualObserver 22221 22502 22872 22928 22991 - Model a guess 23343 23374 23443 23719 23920 - Kohler K91 with 110v electric starter 2428x 24434 - Kohler K91 with Fairbanks recoil 24500 24750 - First 550 built 24910 - May be a 550 25078 25285 25921 - May be a 550 26286 26495 - May be a 550 26637 - May be a 550 26737 - May be a 550 27385 27405 27419 27632 28057 28166 29023 29060 30253 30929 - May be a 550 30931 or 40931 - May be a 550 401 or 551 32506 - May be a 550 33007 33022 33190 33445 33536 - May be a 550 34016 34233 34478 36064 37875 38062 38718 - May be a 550 40241 - May be a 550 41524 42383 --------------------------------------------------------------------- Details and attachments 2 pages 104.70KB 1960 model 550 1960 serial numbers that have shown up for the 550 24750 - First 550 built 24910 - May be a 400 25921 - May be a 400 26026 26171 - Lauson engine with electric start - solid pan seat without holes 26495 - May be a 400 26637 - May be a 400 26737 - May be a 400 27956 28676 28886 29255 30929 - May be a 400 30931 or 40931 - May be a 400 401 or 551 31170 31276 32259 32352 32506 - May be a 400 33536 - May be a 400 35952 36536 38718 - May be a 400 39442 40241 - May be a 400 41345

Transmission Hydro Filter Transmission Hydro Filters Filter Hydro The preferred transmission filter for all models is a Wix 51410 or Napa 1410 because it does not have a by-pass valve Wheel Horse 5990 (1965-1973) replaced by Wix 51307 Wheel Horse 102819 (1973-1982) replaced by Wix 51521 Wheel Horse 108335 (1980-1991 ) replaced by Wix 51410 Wheel Horse 79-5270 (1992 - on) replaced by Wix 51521 1965 model 875 - 5990 filter replaced by 79-5270 1965 model 1075 - 5990 filter replaced by 79-5270 1966 model 876 - 5990 filter replaced by 79-5270 1966 model 1076 - 5990 filter replaced by 79-5270 1966 model 1276 - 5990 filter replaced by 79-5270 1967 model 877 - 5990 filter replaced by 79-5270 1967 model 1077 - 5990 filter replaced by 79-5270 1967 model 1277 - 5990 filter replaced by 79-5270 1968 Charger 9 model 1-7931 - 5990 filter replaced by 79-5270 1968 Charger 9 model 1-7932 - 5990 filter replaced by 79-5270 1968 Charger 12 model 1-7231 - 5990 filter replaced by 79-5270 1968 Electro 12 model 1-7235 - 5990 filter replaced by 79-5270 1969 Charger 10 model 1-7041 - 5990 filter replaced by 79-5270 1969 Charger 12 model 1-7241 - 5990 filter replaced by 79-5270 1969 Charger V7 model 1-7741 - No filter 1969 Charger V8 model 1-7841 - No filter 1969 Electro 12 model 1-7245 - 5990 filter replaced by 79-5270 1969 GT-14 model 1-7441 - 5990 filter replaced by 79-5270 1970 Charger 12 model 1-7251 - 5990 filter replaced by 79-5270 1970 Charger 12 model 1-7252 - 5990 filter replaced by 79-5270 1970 Charger 12 model 1-7253 - 5990 filter replaced by 79-5270 1970 Charger V7 model 1-7751 - No filter 1970 Charger V8 model 1-7851 - No filter 1970 Electro 12 model 1-7255 - 5990 filter replaced by 79-5270 1970 GT-14 model 1-7451 - 5990 filter replaced by 79-5270 1970 GT-14 model 1-7452 - 5990 filter replaced by 79-5270 1970 GT-14 model 1-7453 - 5990 filter replaced by 79-5270 1971 800 Automatic model 1-0450 - (1-0450-6) - No filter 1971 Bronco 14 model 1-0420 - (1-0420-6) - 5990 filter replaced by 79-5270 1971 Bronco 14 model 1-0421 - (1-0421-6) - 5990 filter replaced by 79-5270 1971 Charger 12 model 1-0400 - (1-0400-6) - 5990 filter replaced by 79-5270 1971 GT-14 model 1-0500 - (1-0500-6) - 5990 filter replaced by 79-5270 1971 GT-14 model 1-0501 - (1-0501-6) - 5990 filter replaced by 79-5270 1972 800 Automatic model 1-0451 - (1-0451-7) - No filter 1972 Bronco 14 model 1-0422 - (1-0422-7) - 5990 filter replaced by 79-5270 1972 Bronco 14 model 1-0423 - (1-0423-7) - 5990 filter replaced by 79-5270 1972 Charger 10 model 1-0410 - (1-0401-7) - 5990 filter replaced by 79-5270 1972 Charger 12 model 1-0401 - (1-0401-7) - 5990 filter replaced by 79-5270 1972 Charger 12 model 1-0402 - (1-0402-7) - 5990 filter replaced by 79-5270 1972 GT-14 model 1-0502 - (1-0502-7) - 5990 filter replaced by 79-5270 1972 GT-14 model 1-0503 - (1-0503-7) - 5990 filter replaced by 79-5270 1973 10hp Automatic model 1-0470 - (1-0470-8) - 102819 filter replaced by 79-5270 1973 10hp Automatic model 1-0475 - (1-0475-8) - 102819 filter replaced by 79-5270 1973 12hp Automatic model 1-0460 - (1-0460-8) - 102819 filter replaced by 79-5270 1973 12hp Automatic model 1-0465 - (1-0465-8) - 102819 filter replaced by 79-5270 1973 14hp Automatic model 1-0430 - (1-0430-8) - 102819 filter replaced by 79-5270 1973 14hp Automatic model 1-0435 - (1-0435-8) - 102819 filter replaced by 79-5270 1973 16hp Automatic model 1-0440 - (1-0440-8) - 102819 filter replaced by 79-5270 1973 18hp Automatic model 1-0600 - (1-0600-8) - 102819 filter replaced by 79-5270 1973 18hp Automatic model 1-0601 - (1-0601-8) - 102819 filter replaced by 79-5270 1973 18hp Automatic model 1-0610 - (1-0610-8) - 102819 filter replaced by 79-5270 1973 18hp Automatic model 1-0620 - (1-0620-8) - 102819 filter replaced by 79-5270 1973 GT-14 Automatic model 1-0502 -(1-0502-8) - 5990 filter replaced by 79-5270 1974 B-100 Automatic model 1-0510 - (1-0510-9) - 102819 filter replaced by 79-5270 1974 C-120 Automatic model 1-0485 - (1-0485-9) - 102819 filter replaced by 79-5270 1974 C-120 Automatic model 1-0490 - (1-0490-9) - 102819 filter replaced by 79-5270 1974 C-120 Automatic model 1-0495 - (1-0495-9) - 102819 filter replaced by 79-5270 1974 C-160 Automatic model 1-0480 - (1-0480-9) - 102819 filter replaced by 79-5270 1974 D-160 Automatic model 1-0650 - (1-0650-9) - 102819 filter replaced by 79-5270 1974 D-180 Automatic model 1-0611 - (1-0611-9) - 102819 filter replaced by 79-5270 1974 D-200 Automatic model 1-0630 - (1-0630-9) - 102819 filter replaced by 79-5270 1975 B-100 Automatic model 1-0511 - 102819 filter replaced by 79-5270 1975 C-120 Automatic model 1-0491 - 102819 filter replaced by 79-5270 1975 C-160 Automatic model 1-0481 - 102819 filter replaced by 79-5270 1975 D-160 Automatic model 1-0651 - 102819 filter replaced by 79-5270 1975 D-180 Automatic model 1-0612 - 102819 filter replaced by 79-5270 1975 D-200 Automatic model 1-0631 - 102819 filter replaced by 79-5270 1976 C-120 Automatic model 61-12KS01 - 102819 filter replaced by 79-5270 1976 C-120 Automatic model 61-12KS02 - 102819 filter replaced by 79-5270 1976 C-120 Automatic model 61-12KS03 - 102819 filter replaced by 79-5270 1976 C-120 Automatic model 61-12KS04 - 102819 filter replaced by 79-5270 1976 C-160 Automatic model 61-16KS01 - 102819 filter replaced by 79-5270 1976 C-160 Automatic model 61-16KS02 - 102819 filter replaced by 79-5270 1976 C-160 Automatic model 61-16KS03 - 102819 filter replaced by 79-5270 1976 C-160 Automatic model 61-16KS04 - 102819 filter replaced by 79-5270 1976 D-160 Automatic model 61-16OS01 - 102819 filter replaced by 79-5270 1976 D-160 Automatic model 61-16OS02 - 102819 filter replaced by 79-5270 1976 D-200 Automatic model 61-20KS01 - 102819 filter replaced by 79-5270 1976 D-200 Automatic model 61-20KS02 - 102819 filter replaced by 79-5270 1977 C-120 Automatic model 71-12KS01 - 102819 filter replaced by 79-5270 1977 C-120 Automatic model 71-12KS02 - 102819 filter replaced by 79-5270 1977 C-160 Automatic model 71-16KS01 - 102819 filter replaced by 79-5270 1977 C-160 Automatic model 71-16KS02 - 102819 filter replaced by 79-5270 1977 D-160 Automatic model 71-16OS01 - 102819 filter replaced by 79-5270 1977 D-200 Automatic model 71-20KS01 - 102819 filter replaced by 79-5270 1978 C-121 Automatic model 81-12KS01 - 102819 filter replaced by 79-5270 1978 C-141 Automatic model 81-14KS01 - 102819 filter replaced by 79-5270 1978 C-161 Automatic model 81-16KS01 - 102819 filter replaced by 79-5270 1978 C-161 Twin Automatic model 81-16BS01 - 102819 filter replaced by 79-5270 1978 D-160 Automatic model 81-16OS01 - 102819 filter replaced by 79-5270 1978 D-200 Automatic model 81-20KS01 - 102819 filter replaced by 79-5270 1979 C-121 Automatic model 91-12KS01 - 102819 filter replaced by 79-5270 1979 C-121 Automatic model 91-12KS91 - 102819 filter replaced by 79-5270 1979 C-141 Automatic model 91-14KS01 - 102819 filter replaced by 79-5270 1979 C-161 Automatic model 91-16KS01 - 102819 filter replaced by 79-5270 1979 C-161 Automatic model 91-16KS91 - 102819 filter replaced by 79-5270 1979 C-161 Twin Automatic model 91-16BS01 - 102819 filter replaced by 79-5270 1979 C-161 Twin Automatic model 91-16BS02 - 102819 filter replaced by 79-5270 1979 C-171 A model that was not built 1979 D-160 Automatic model 91-16OS01 - 102819 filter replaced by 79-5270 1979 D-160 Automatic model 91-16OS02 - 102819 filter replaced by 79-5270 1979 D-200 Automatic model 91-20KS01 - 102819 filter replaced by 79-5270 1979 D-200 Automatic model 91-20KS02 - 102819 filter replaced by 79-5270 1980 C-125 Automatic model 01-12KE01 - 108335 filter replaced by 79-5270 1980 C-125 Automatic model 01-12KS01 - 102819 filter replaced by 79-5270 1980 C-145 Automatic model 01-14KE01 - 108335 filter replaced by 79-5270 1980 C-145 Automatic model 01-14KS01 - 102819 filter replaced by 79-5270 1980 C-165 Automatic model 01-16KE01 - 108335 filter replaced by 79-5270 1980 C-165 Automatic model 01-16KS01 - 102819 filter replaced by 79-5270 1980 C-165 Automatic model 01-16KS91 - 102819 filter replaced by 79-5270 1980 C-175 Twin Automatic model 01-17KE01 - 108335 filter replaced by 79-5270 1980 C-175 Twin Automatic model 01-17KS02 - 102819 filter replaced by 79-5270 1980 D-160 Automatic model 01-16OS01 - 102819 filter replaced by 79-5270 1980 D-200 Automatic model 01-20KS00 - 102819 filter replaced by 79-5270 1981 C-125 Automatic model 01-12KE02 - 108335 filter replaced by 79-5270 1981 C-145 Automatic model 01-14KE02 - 108335 filter replaced by 79-5270 1981 C-165 Automatic model 01-16KE02 - 108335 filter replaced by 79-5270 1981 C-175 Twin Automatic model 01-17KE01 - 108335 filter replaced by 79-5270 1981 D-160 Automatic model 01-16OS01 - 102819 filter replaced by 79-5270 1981 D-200 Automatic model 01-20KS00 - 102819 filter replaced by 79-5270 1982 B-115 Automatic model 02-11BE01 1982 B-165 Twin Automatic model 02-16BE01 1982 C-145 Automatic model 01-14KE03 - 108335 filter replaced by 79-5270 1982 C-175 Twin Automatic model 01-17KE02 - 108335 filter replaced by 79-5270 1982 C-195 Twin Automatic model 01-19KE01 - 108335 filter replaced by 79-5270 1982 D-160 Automatic model 01-16OS01 - 102819 filter replaced by 79-5270 1982 GT-1848 Twin Automatic model A1-184801 - 108335 filter replaced by 79-5270 1983 B-115 Automatic model 12-11BE01 - No filter 1983 B-165 Twin Automatic model 12-16BE01 - No filter 1983 C-145 Automatic model 01-14KE04 - 108335 filter replaced by 79-5270 1983 C-175 Twin Automatic model 01-17KE03 - 108335 filter replaced by 79-5270 1983 C-195 Twin Auto model 01-19KE01 - 108335 filter replaced by 79-5270 1983 GT-1848 Twin Automatic model D1-184801 - 108335 filter replaced by 79-5270 1984 B-165 Twin Automatic model 12-16BE02 - No filter 1984 C-145 Automatic model 11-14KE01 - 108335 filter replaced by 79-5270 1984 C-175 Twin Automatic model 11-17KE01 - 108335 filter replaced by 79-5270 1984 C-195 Twin Automatic model 01-19KE02 - 108335 filter replaced by 79-5270 1984 GT-1800 Twin Automatic model A1-18BE01 - 108335 filter replaced by 79-5270 1985 211-A model 22-11BE01 - No filter 1985 314-A model 21-14KE01 - 108335 filter replaced by 79-5270 1985 417-A model 31-17KE01 - 108335 filter replaced by 79-5270 1986 YT12-A model 22-12TE01 - No filter 1986 312-A model 21-12KE01 - No filter 1986 312-A model 21-12KE02 - No filter 1986 417-A model 31-17KE02 - 108335 filter replaced by 79-5270 1986 420-LSE Automatic model 31-20KE01 - 108335 filter replaced by 79-5270 1987 312-A model 21-12KE03 - 108335 filter replaced by 79-5270 1987 418-A model 31-18KE01 - 108335 filter replaced by 79-5270 1987 418-C model 41-18KE01 - 108335 filter replaced by 79-5270 1988 252-H model 22-13KE01 1988 257-H model 22-17KE01 1988 516-H model 31-16OE01 1988 518-H model 31-18OE01 1988 518-He model E1-18OE01 1988 520-H model 31-20OE01 1988 520-HC model C1-20OE01 1989 212-H model 32-12BE01 1989 212-H model A2-12KE01 1989 212-He model E2-12KE01 1989 212-He model R2-12KE01 (This may be a 1990 model) 1989 252-H model 22-13KE02 1989 257-H model 22-17KE02 1989 518-H model 31-18OE02 1989 518-He model E1-18OE02 1989 520-H model 31-20OE02 1989 520-HC model C1-20OE02 1990 210-H model 32-10BE01 1990 212-H model 32-12BEA1 1990 212-H model 32-12OE01 1990 212-He model R2-12BE01 {OM not available Model not recognized @ Toro} 1990 212-HSBe model S2-12BE01 {OM not available Model not recognized @ Toro} 1990 216-H model 32-16BE01 1990 312-H model 31-12KE01 - 108335 filter replaced by 79-5270 1990 416-H model 41-16OE01 1990 518-He model R1-18OE01 1990 518-He model R1-18OE02 1990 520-H model 41-20OE01 1991 210-H model 32-10BE02 Serial 1000001-1999999 1991 212-H model 32-12BEA2 Serial 1000001-1999999 1991 212-H model 32-12BEA3 Serial 1000001-1999999 1991 212-H model 32-12OE02 Serial 1000001-1999999 1991 212-H model 32-12OEA1 Serial 1000001-1999999 1991 212-H model A2-12KE02 Serial 1000001-1999999 1991 212-He model R2-12OE01 Serial 1000001-1999999 1991 244-H model 22-14OE01 Serial 1000001-1999999 1991 246-He model R2-16BE01 Serial 1000001-1999999 1991 312-H model 51-12KE01 Serial 1000001-1999999 1991 416-H model 51-16OE01 Serial 1000001-1999999 1991 520-H model 41-20OE02 Serial 1000001-1999999 - 108335 filter replaced by 79-5270 1991 520-He model R1-20OE01 Serial 1000001-1999999 1992 210-H model 32-10BE03 Serial 2000001-2999999 1992 212-H model 32-12OE03 Serial 2000001-2999999 1992 212-He model R2-12OE02 Serial 2000001-2999999 1992 244-H model 22-14OE02 Serial 2000001-2999999 1992 246-H model 42-16BE01 Serial 2000001-2999999 1992 246-He model R2-16BE01 Serial 2000001-2999999 (On the OM this is a 1991 model) 1992 312-H model 51-12KE02 Serial 2000001-2999999 1992 416-H model 51-16OE02 Serial 2000001-2999999 1992 520-H model 41-20OE03 Serial 2000001-2999999 - 79-5270 filter 1992 520-He model R1-20OE02 Serial 2000001-2999999 - 79-5270 filter 1993 244-H model 72041 Serial 3900001-3999999 1993 246-H model 72081 Serial 3900001-3999999 1993 246-H model 72101 Serial 3900001-3999999 1993 314-H model 73401 Serial 3900001-3999999 1993 416-H model 73421 Serial 3900001-3999999 1993 520-H model 73501 Serial 39000001-39999999 - 79-5270 filter 1993 520-He model 73520 Serial 39000001-39999999 - 79-5270 filter 1994 264-H model 72043 Serial 4900001-4999999 1994 264-He model 72063 Serial 4900001-4999999 1994 266-H model 72083 Serial 4900001-4999999 1994 268-He model 72103 Serial 4900001-4999999 1994 314-H model 73401 Serial 4900001-4999999 1994 416-H model 73421 Serial 4900001-4999999 1994 520-H model 73501 Serial 49000001-49999999 - 79-5270 filter 1994 520-He model 73520 Serial 4900001-4999999 - 79-5270 filter 1995 264-H model 72043 Serial 5900001-5901475 1995 264-H model 72043 Serial 5901476-5999999 1995 264-He model 72063 Serial 5900001-5900498 1995 264-He model 72063 Serial 5900499-5999999 1995 266-H model 72084 Serial 5900001-5999999 1995 268-He model 72103 Serial 5900001-5900600 1995 268-He model 72103 Serial 5900601-5999999 1995 314-H model 73401 Serial 5900001-5900260 1995 314-H model 73401 Serial 5900261-5901260 1995 314-H model 73401 Serial 5901261-5999999 1995 416-H model 73421 Serial 5900001-5901046 - 79-5270 filter 1995 416-H model 73421 Serial 5901047-5999999 - 79-5270 filter 1995 520-H model 73501 Serial 59000001-59000411 - 79-5270 filter 1995 520-H model 73501 Serial 59000412-59002868 - 79-5270 filter 1995 520-H model 73501 Serial 59002869-59002946 - 79-5270 filter 1995 520-H model 73501 Serial 59002947-59999999 - 79-5270 filter 1995 520-He model 73520 Serial 5900001-5900177 - 79-5270 filter 1995 520-He model 73520 Serial 5900178-5999999 - 79-5270 filter 1996 264-H model 72043 Serial 6900001-6999999 1996 265-H model 72046 Serial 6900001-6999999 1996 265-H model 72064 Serial 6900001-6999999 1996 265-He model 72064 Serial 6900001-6999999 1996 266-H model 72084 Serial 6900001-6999999 1996 267-H model 72085 Serial 6900001-6999999 1996 267-H model 72104 Serial 6900001-6999999 1996 267-He model 72104 Serial 6900001-6999999 1996 269-H model 72102 Serial 6900001-6999999 1996 270-H model 72110 Serial 6900001-6999999 1996 270-He model 72110 Serial 6900001-6999999 1996 314-H model 73401 Serial 6900001-6999999 1996 314-H model 73403 Serial 6900001-6999999 - 79-5270 filter 1996 416-H model 73421 Serial 6900001-6999999 - 79-5270 filter 1996 416-H model 73423 Serial 6900001-6999999 - 79-5270 filter 1996 520-H model 73501 Serial 69000001-69999999 - 79-5270 filter 1996 520-H model 73502 Serial 6900001-6999999 - 79-5270 filter 1996 520-H model 73521 Serial 6900001-6999999 - 79-5270 filter 1996 520-He model 73521 Serial 6900001-6999999 - 79-5270 filter 1997 265-H model 72046 Serial 7900001-7999999 - No external filter 1997 265-H model 72064 Serial 7900001-7999999 - No external filter - Export model 1997 265-He model 72064 Serial 7900001-7999999 - No external filter - Export model 1997 267-H model 72085 Serial 7900001-7999999 - No external filter 1997 267-H model 72104 Serial 7900001-7999999 - No external filter - Export model 1997 267-He model 72104 Serial 7900001-7999999 - No external filter - Export model 1997 269-H model 72102 Serial 7900001-7999999 - No external filter 1997 270-H model 72110 Serial 7900001-7999999 - No external filter - Export model 1997 270-He model 72110 Serial 7900001-7999999 - No external filter - Export model 1997 314-H model 73403 Serial 7900001-7999999 - 79-5270 filter 1997 416-H model 73423 Serial 7900001-7999999 - 79-5270 filter 1997 520-H model 73502 Serial 7900001-7999999 - 79-5270 filter - Last year for the 520 1997 520-H model 73521 Serial 7900001-7999999 - 79-5270 filter - Last year for the 520 1997 520-He model 73521 Serial 7900001-7999999 - 79-5270 filter - Last year for the 520 1998 518xi model 73470 Serial 8900001-8999999 - 79-5270 filter 1998 520Lxi model 73545 Serial 8900001-8999999 1998 520Lxi model 73546 Serial 8900001-8999999 - Export model 1998 520Lxie model 73546 Serial 8900001-8999999 - Export model 1998 520xi model 73540 Serial 8900001-8999999 1998 520xi model 73541 Serial 8900001-8999999 - Export model 1998 520xie model 73541 Serial 8900001-8999999 - Export model 1998 522xi model 73560 Serial 8900001-8999999 1998 523Dxi model 73550 Serial 8900001-8999999 1998 523Dxi model 73551 Serial 8900001-8999999 - Export model 1998 523Dxie model 73551 Serial 8900001-8999999 - Export model 1999 518xi model 73471 Serial 9900001-9999999 - 79-5270 filter 1999 520Lxi model 73547 Serial 9900001-9999999 1999 520Lxi model 73580 Serial 9900001-9999999 - Export model 1999 520Lxie model 73580 Serial 9900001-9999999 - Export model 1999 520xi model 73542 Serial 9900001-9999999 1999 520xi model 73570 Serial 9900001-9999999 - Export model 1999 520xie model 73570 Serial 9900001-9999999 - Export model 1999 522xi model 73561 Serial 9900001-9999999 1999 523Dxi model 73552 Serial 9900001-9999999 - 79-5270 filter 1999 523Dxi model 73590 Serial 9900001-999999 - Export model 1999 523Dxie model 73590 Serial 9900001-999999 - Export model

Going thru some of the old paperwork from my Dad's shop and came across these. Can't imagine there are too many companies today that would provide this kind of information for an obsolete part to their customers or their distribution channel. Just goes to show what a great company they were back in the day. Transmission drive belt guard Part Numbers were 4962, 4993, and 5308 Files are in pdf format 4962 fits Lauson powered tractors (Same as 5308 except has 5/16-24 tapped hole in mounting bracket) 1964 models 604, 654, 34E, 34R 1965 models L-105, L-155 1966 models L-106, L-156 1967 models L-107, L-157 1968 Lawn Ranger models 1-1631, 1-2631 1969 WorkHorse 700 models 1-3741, 1-3745, Commando 1-3741 sold in Europe but not on the Belgium list 4993 fits Kohler powered tractors 1964 models 704, 754, 854 1965 model 855, 1966 models 706, 856 1967 models 857, 867 1968 model 1-4831 Commando 8 5308 fits Lauson powered tractors (Same as 4962 except omit 5/16-24 tapped hole in mounting bracket) 1965 models 605, 655, 1966 models 606, 656 1967 models 607, 657 1968 models 500 Special model 1-3631, Commando 6 model 1-4631

Operator manual #359 IPL Wiring 12 pages 1.76MB - B&W 12 pages 3.41MB - Color Dated 8/1/67 Wiring Color pdf 1 page 301KB Transmission drive belt 78-7100 replaced by 7473 - HB x 81.9" or 5/8" x 81.9" Lube chart SS Details & Attachments 3 pages 116.43KB 1968 Raider 9 model 1-6931 1968 serial numbers that have shown up for the 1-6931 410134 413191 413424 426002 426083 426125 426165 428468 - Could be 420486 and/or a model 1-6231 439453 439645 439880 - Decaled a Raider 10 439894 440143 440199 440307 440412 440473 445255 445268 445450 445475 466813 - Decaled a Raider 10 466832 466876 466926 468075 478137 - Decaled a Raider 10 478259 - Decaled a Raider 10 489582 489673 489765 - Decaled a Raider 10 489770 - Decaled a Raider 10 489771 4899XX - Decaled a Raider 10 494348 - Decaled a Raider 10 494441 494483 - Decaled a Raider 10

Battery ignition switch with electric starter/generator 4988 (Threads 5/8"-32) 3-terminal 3-position used 1964-1967 4988 switch replaced by 7263 4988 ignition switch used in 1964 models 854, 1045 1965 models 855, 875, 1055, 1075 1966 models 856, 876, 1056, 1276 1967 models 857, 877, 1257, 1277 --------------------------------------------------------------------------------------------------------------------------------------------------------- Battery ignition switch with electric starter/generator 7263 (Threads 9/16"-24) 3-terminal 3-position 7263 replaces 4988 7263 3-terminal 3-position available 06/2008 $32.04 from RCPW 7263 3-terminal 3-position available 06/2017 $60.18 from RCPW 7263 3-terminal 3-position available 01/2021 $71.37 from RCPW 7263 ignition switch used in 1967 models 867, 1067, 1267 1968 Commando 8 model 1-4831 1968 Charger 12 model 1-7231 - Early production has battery ignition and electric starter/generator - Mid year change 1968 Raider 12 model 1-6231 - Early production has battery ignition and electric starter/generator - Mid year change The original parts list for the 1968 Commando 8 model 1-4831 list a 7262 ignition switch but that is the part number for the key (typo). Switch is 7263. Cole Hersee 95521B

Service manual Wiring 74 pages 15.69MB Dated 07/78 B-Series wiring color pdf 1 page 392KB C-161 Twin wiring color pdf 1 page 352KB C-Series wiring color pdf 1 page 366KB D-160 wiring color pdf 1 page 367KB D-200 wiring color pdf 1 page 380KB Lube chart SS Rear wheel hub set screw torque 28-32 Ft. Lb. or 39-45 Nm Service manual 27 pages 4.71MB Section 1 - Specifications including spark plugs used and gaps - NOTE - Correct spark plug for Onan B43 - 48M is RH18Y Section 2 - Pre-delivery Service Section 3 - General Maintenance Section 4 - Engine Service manual 18 pages 4.87MB Section 5 - Clutch, Brakes, Transmission/Transaxle Service manual 13 pages 2.63MB Section 6 - Electrical Service manual 16 pages 3.48MB Section 7 - Attachment Lifts Section 8 - Chassis Section 9 - Power Take-off (PTO) 1979 B-81 model 92-08BP01 in 1978-79 service manual is likely a mistake 1979 B-81 6-Speed model 92-08BF01 1979 B-111 4-Speed model 92-11BP01 1979 B-111 6-Speed model 92-11BF01 (Made in USA) 1979 B-111 6-Speed model 91-11BF91 (Made in Belgium with serial 170049) 1979 B-111 6-Speed model 92-11BF91 (Made in Belgium with serial 178838 & 182588) 1979 B-111 6-Speed model 92-11BF92 (Made in Belgium with serial 175611) 1979 C-81 8-Speed model 91-08K801 1979 C-81 8-Speed model 91-08K802 1979 C-81 8-Speed model 91-08K891 (Made in Belgium with serial 163175) 1979 C-101 8-Speed model 91-10K801 1979 C-101 8-Speed model 91-10K802 1979 C-101 8-Speed model 91-10K892 (Made in Belgium with serial 183695) 1979 C-111 8-Speed model 91-11B801 1979 C-121 8-Speed model 91-12K801 (Two found made in Belgium) 1979 C-121 8-Speed model 91-12K802 1979 C-121 8-Speed model 91-12K891 (Made in Belgium with serials 167136 169593) 1979 C-121 8-Speed model 91-12K892 - Belgium built with serial 184568 1979 C-121 Automatic model 91-12KS01 1979 C-121 Automatic model 91-12KS91 (Made in Belgium with serial 16?329) 1979 C-141 8-Speed model 91-14K801 1979 C-141 8-Speed model 91-14K802 1979 C-141 Automatic model 91-14KS01 1979 C-161 8-Speed model 91-16K801 1979 C-161 Automatic model 91-16KS01 (One found in Holland Made in Belgium) 1979 C-161 Automatic model 91-16KS91 - Made in Belgium serial 167284 1979 C-161 Twin 8-Speed model 91-16B801 1979 C-161 Twin 8-Speed model 91-16B802 1979 C-161 Twin Automatic model 91-16BS01 1979 C-161 Twin Automatic model 91-16BS02 1979 C-171 Automatic model - that was not built 1979 D-160 Automatic model 91-16OS01 1979 D-160 Automatic model 91-16OS02 - Not listed @ Toro and may be an invalid model number 1979 D-200 Automatic model 91-20KS01 1979 D-200 Automatic model 91-20KS02

Tractor vs. Implement cross reference chart for models from 1955 - 2000 110 pages 513.43KB This chart lists the original attachment model The model that replaced the original model The model that was available when the list was made Often many models between the last two are not listed. You must go from year to year and follow the model numbers to see them all. For a complete list of models click on the magnifying glass in the Search box. Enter DNA in the Search box and select Files from the drop down menu. Two pages of 33 results will come up in random order. Find the attachment you are looking for and click on it. The DNA for that model of attachment will come up. Look for the model of your attachment in the DNA list. They are organized from earliest to latest. OR Search the Files using a model number you know will work. Look through the results for DNA in another file name for the same item. That will have the full list of models. STD for a model indicates that attachment was standard equipment that came on that model of tractor. Mistakes in the online attachment list @ Toro. The Attachment Interchange is correct but confusing and the source of the mistakes. 1970 *VS rear discharge mower deck 5-7362 is correct replaced by 5-0610 both CCW rotation 1971 rear discharge mower deck 5-0600 - CW spindle rotation fits long frame tractors only 1971 *CG-7 & 8 rear discharge mower deck should be model 5-7362 - CCW spindle rotation 1972 *CG-7 & 8 rear discharge mower deck should be model 5-0610 - CCW spindle rotation 1973 *VS rear discharge mower deck should be model 5-0611 - CCW spindle rotation 1970 *VS side discharge mower deck 5-2365 is correct replaced by 5-0700 both CCW rotation 1971 side discharge mower deck 5-0710 - CW spindle rotation fits long frame tractors only 1971 *CG-7 & 8 side discharge mower deck should be model 5-0700 - CCW spindle rotation 1972 *CG-7 & 8 side discharge mower deck should be model 5-0701 - CCW spindle rotation 1973 *VS side discharge mower deck should be model 5-0702 - CCW spindle rotation 1974 Replacement rear discharge mower deck for the model 5-0622 (side discharge) is wrong - should be 65-36XR01 *Models using a vertical engine crankshaft

Operator manual Illustrated parts list 6 pages 1.2MB Fits 10hp 12hp long frame tractors 5-1482 fits 1969 GT-14 and followed by 1970 model 5-0481, 1971 model 5-1200, 1972 model 5-1201 and 1972-73 model 5-1202 These decks all use blades with 5/8" x 3/4" double-D center hole unless the spindles have been upgraded. Drive belt 6771 replaced by 9783 (1/2" x 71") Spindle belt 1594 (1/2" x 107.21") Mower spindle assemblies could be J, N, U, V, Y or Z For N and U see service bulletin 221B For V and Y see service bulletin 292B 4380 blade replaced by 6758 and then by 100202 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D) Mower Rotary 1969 48in SD model 5-1482 1969 serial numbers that have shown up for the 5-1482 554519 554637 565589

Fits 5xi-Series tractors This is the original manual for the Kwik-Way front end loader attachment for the 5xi series of tractors. Special thanks to doc724 for mailing me a hard copy! Kwik Way KwikWay 32 pages 4.5MB

1956-1999 Chart belt 20 pages 1.77MB Belt sizes on the last pages Mistakes in mower belt chart 1967 RL-367 drive belt lists 1587 Correct belt is 1563 1968 5-1361 drive belt lists 8975 Correct belt is 1563 5-1362 drive belt lists 8975 Correct belt is 1563 5-2321 drive belt lists 8975 Correct belt is 1577 replaced by 7430 5-2322 drive belt lists 8975 Correct belt is 1577 replaced by 7430 5-2361 drive belt lists 1587 Correct belt is 1577 replaced by 7430 5-2362 drive belt lists 1587 Correct belt is 1577 replaced by 7430 1969 5-8321 drive belt 8975 (1/2" x 58") [1561 in the belt chart is wrong] 1970 5-8322 drive belt 8975 (1/2" x 58") [104865 in the belt chart is wrong] 1971 5-1000 drive belt 9782 (1/2" x 69") [9783 in the chart is wrong] 1978 85-42MR01 drive belt 108834 is correct as per PSB #272 1979 95-42MR01 drive belt 108834 is correct as per PSB #272 95-42MR02 drive belt 108834 is correct as per PSB #272 1980-1983 05-42MR01 drive belt 108834 is correct as per PSB #272 1983 The 2nd A5-42MS02 in the chart should be A5-48MS02 1984 Model 23-11BP03 tractor shows belt 108491 (1/2" x 67"). Believe it should be 108503 (1/2" x 65.25") for 05-32XS02 mower on the A-111 5-Speed 05-42MS02 should be 05-42MR02 1985 There is one model number missing for every style and size of deck listed. Do a search of the Files for a deck model number if it is not listed in the chart. The belts are listed there. 1991 Model C5-60SC02 not in the chart { (Drive belt 113072 (1/2" x 103") (Spindle belt 112449 (5/8" x 131.25") } 1993 8-32 Rear Engine Rider Recycler model 70042 - Mower drive and spindle belt 92-0875 (1/2" x 58" @ Gates) [Belt 47-1420 (1/2" x 65.56") in belt chart is wrong] 10-32 Rear Engine Rider Recycler model 70080 - Mower drive and spindle belt 92-0875 (1/2" x 58" @ Gates) [Belt 47-1420 (1/2" x 65.56") in belt chart is wrong] 12-32 Rear Engine Rider Recycler model 70120 - Mower drive and spindle belt 92-0875 (1/2" x 58" @ Gates) [Belt 47-1420 (1/2" x 65.56") in belt chart is wrong] 12-32 Rear Engine Rider model 70140 - Mower drive and spindle belt 92-0875 (1/2" x 58" @ Gates) [Belt 47-1420 (1/2" x 65.56") in belt chart is wrong] 1994 10-32 Rear Engine Rider Recycler model 70080 - Mower drive and spindle belt 92-0875 (1/2" x 58" @ Gates) [Belt 47-1420 (1/2" x 65.56") in belt chart is wrong] 12-32 Rear Engine Rider Recycler model 70120 - Mower drive and spindle belt 92-0875 (1/2" x 58" @ Gates) [Belt 47-1420 (1/2" x 65.56") in belt chart is wrong] 10-32e Rear Engine Rider Recycler model 70100 - Mower drive and spindle belt 92-0875 (1/2" x 58" @ Gates) [Belt 47-1420 (1/2" x 65.56") in belt chart is wrong] 12-32e Rear Engine Rider Recycler model 70141 - Mower drive and spindle belt 92-0875 (1/2" x 58" @ Gates) [Belt 47-1420 (1/2" x 65.56") in belt chart is wrong] 1996 78345 42`side discharge lists drive belt 108834 and spindle belt 106125 - Correct drive belt is 102742 and spindle belt 6738 78355 42`recycler lists drive belt 102742 and spindle belt 6738 - Correct drive belt is 108834 and spindle belt 106125 1997 78345 42`side discharge lists drive belt 108834 and spindle belt 106125 - Correct drive belt is 102742 and spindle belt 6738 78355 42`recycler lists drive belt 102742 and spindle belt 6738 - Correct drive belt is 108834 and spindle belt 106125 1998 78345 42`side discharge lists drive belt 108834 and spindle belt 106125 - Correct drive belt is 102742 and spindle belt 6738 78355 42`recycler lists drive belt 102742 and spindle belt 6738 - Correct drive belt is 108834 and spindle belt 106125 1999 78345 42`side discharge lists drive belt 108834 and spindle belt 106125 - Correct drive belt is 102742 and spindle belt 6738 1999 and 2000 79375 36" tiller for 5xi models Front belt 98-8707 or 94-7877 (1/2" x 113.75" found with Google search) Rear belt 98-8706 (1/2" x 92.66" found with Google search)

Operator manual #810301R2 or 810301 R2 IPL 8 pages 1000.19KB Dated 11/83 Fits C-Series tractors The years the model numbers changed not known Mower Rotary 1980 42in SD model 07-01MC01 Carrier Mower Rotary 1981 42in SD model 07-01MC01 Carrier Mower Rotary 1982 42in SD model 07-01MC01 Carrier Mower Rotary 1983 42in SD model 07-01MC01 Carrier Mower Rotary 1984 42in SD model 07-01MC01 Carrier Mower Rotary 1985 42in SD model 07-01MC02 Carrier Mower Rotary 1986 42in SD model 07-01MC02 Carrier Mower Rotary 1987 42in SD model 07-01MC02 Carrier Mower Rotary 1988 42in SD model 07-01MC02 Carrier Mower Rotary 1980 48in SD model 07-01MC01 Carrier Mower Rotary 1981 48in SD model 07-01MC01 Carrier Mower Rotary 1982 48in SD model 07-01MC01 Carrier Mower Rotary 1983 48in SD model 07-01MC01 Carrier Mower Rotary 1984 48in SD model 07-01MC01 Carrier Mower Rotary 1985 48in SD model 07-01MC02 Carrier Mower Rotary 1986 48in SD model 07-01MC02 Carrier Mower Rotary 1987 48in SD model 07-01MC02 Carrier Mower Rotary 1988 48in SD model 07-01MC02 Carrier

Operator manual #803967 IPL 6 pages 1.26MB Fits 1975 D-160 Automatic model 1-0651 1975 D-180 Automatic model 1-0612 1975 D-200 Automatic model 1-0631 1976 D-160 Automatic model 61-16OS01 1976 D-160 Automatic model 61-16OS02 1976 D-200 Automatic model 61-20KS01 1976 D-200 Automatic model 61-20KS02 1977 D-160 Automatic model 71-16OS01 1977 D-200 Automatic model 71-20KS01 1978 D-160 Automatic model 81-16OS01 1978 D-200 Automatic model 81-20KS01 1979 D-160 Automatic model 91-16OS01 1979 D-160 Automatic model 91-16OS02 - Not listed @ Toro and may be an invalid model number 1979 D-200 Automatic model 91-20KS01 1979 D-200 Automatic model 91-20KS02 1980 D-160 Automatic model 01-16OS01 1980 D-200 Automatic model 01-20KS00 1981 D-160 Automatic model 01-16OS01 - Not listed @ Toro 1981 D-200 Automatic model 01-20KS00 1982 D-160 Automatic model 01-16OS01 Hitch Rear Three Point 1975 model 8-5422 Hitch Rear Three Point 1976 model 8-5422 Hitch Rear Three Point 1977 model 8-5422 Hitch Rear Three Point 1978 model 8-5422 Hitch Rear Three Point 1979 model 8-5422 Hitch Rear Three Point 1980 model 8-5422 Hitch Rear Three Point 1981 model 8-5422 Hitch Rear Three Point 1982 model 8-5422

A hand-out brochure showing the line up and features of the tractors for the 1978 year...... 6 pages 4.8MB

I had to buy a photocopy of this from eBay for $13. That's rediculous. Hopefully someone can get use of it here. Operator manual IPL Original file 8 pages 79.6MB Replaced with 8 pages 3.7MB H60-75063B electric start H60-75064B recoil start Used on 1964 models 604 and 654 1964 Lawn Ranger models 34E and 34R

1989 tractor prices from ad

Cecil pond patent filed September 8, 1958 Patent issued June 13, 1961 12 pages 1.3MB

Drawing for the Wheel Horse clevis hitch.

This is my original Haban 414 Sickle bar mower Operation and Service Manual with repair parts list. I removed it from my GT 14.

"Today's Compact Tractor" is a 1969 article about the genealogy of the compact tractor, originally published in Lawn/Garden/Outdoor Living Magazine in 1969. Reader needs to keep in mind as the article is read that the present day is 1969.

JOHNNY BUCKET Jr. For Wheelhorse Tractors

Operator manual #A-5193 IPL 1 page 152.10KB Dated 7/8/70 Fits GT-14 Completing package requires 6-9612 54" blade Also see the 6-4113 file for 42" blade Although the 6th or last digit is not used you can subtract 5 from that number to determine the model year. 1970 Blade Dozer 54in model 6-4113 A-Frame 1970 serial numbers that have shown up for the 6-4113 647370 655328 655758 656686 656733 666011 1971 Blade Dozer 54in model 6-4113 A-Frame 1971 serial numbers that have shown up for the 6-4113 742599 - 6-4113-6 743024 - 6-4113-6 786850 - 6-4113-6 1972 Blade Dozer 54in model 6-4113 A-Frame 1973 Blade Dozer 54in model 6-4113 A-Frame

Service bulletin #11 issued in 1960 2 pages 391KB
