101845 Ball safety switch NO=Normally open
9/16-18 threads on 102277 mounting nut
This switch has screw terminals
Used 1972-1981 & 1986
Later 105877 replaced by 38-0430 Ball switch NO=Normally open - Nail head terminals for a slide on Packard connector. Some illustrations show a switch with flat spade terminals.
82-12o502* - Correct
82 -12o502 - Not correct
82-12o502 - Suspicious and not checked or determined yet
101845 Ball switch used on
1972 models 1-0110, 1-0301, 1-0311, 1-0320, 1-0330, 1-0401, 1-0402, 1-0410,1-0422, 1-0423
1973 models 1-0120, 1-0130, 1-0340, 1-0350, 1-0355, 1-0360, 1-0365, 1-0370, 1-0430, 1-0435, 1-0440, 1-0460, 1-0465,1-0470, 1-0475, 1-0600, 1-0601, 1-0610, 1-0620
1974 models 1-0140, 1-0145, 1-0353, 1-0354, 1-0356, 1-0380, 1-0385, 1-0390, 1-0393, 1-0480, 1-0485, 1-0490, 1-0495, 1-0510, 1-0611, 1-0630, 1-0650, 2-4300
1975 models 1-0141, 1-0357, 1-0375, 1-0381(1)*, 1-0391(1)*, 1-0395(1)*, 1-0396, 1-0481(1)*, 1-0491(1)*, 1-0511,1-0612, 1-0631, 1-0651, 3-5001, 13-5000
1976 models 3-5002, 61-07K801, 61-07K802, 61-08K801, 61-08K802, 61-08K803, 61-08K804, 61-10K801, 61-10K802, 61-10K803, 61-10K804, 61-12K801, 61-12K802, 61-12K803, 61-12K804, 61-12KS01, 61-12KS02, 61-12KS04, 61-16K801, 61-16K802, 61-12K803, 61-12K804, 61-16KS01, 61-16KS02, 61-16KS04, 61-16OS01, 61-16OS02, 61-20KS01, 61-20KS02
1977 models 71-16OS01, 71-20KS01
1978 models 81-16OS01, 81-20KS01
1979 models 91-16OS01, 91-20KS01, 91-20KS02
1980 models 01-16OS01, 01-20KS00
1981 model 01-20KS00
1986 models 33-08B303, 33-08B502, 33-08X303, 33-11B502, B3-08B303, B3-11B502
