About This File
Operator manual #A-5252
IPL
10 pages 1.75MB
Dated 5/1/67
Includes PSB's #094 #097 #221B
5-1421 42" Side discharge mower deck. Commonly used on mid-late 60s models using 10 or 12 Hp.
Fits Raider, Charger and Electro long frame models
Drive belt 7041 (1/2" x 72")
Spindle belt 6738 (1/2" X 86")
Mower spindle assemblies could be J, N, U, V, X or Z
For N and U see service bulletin 221B
For X and V see service bulletin 207B
6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Stens replacement - 3 of 350-041 still available March 6, 2021
Mower Rotary 1968 42in SD model 5-1421
1968 serial numbers that have shown up for the 5-1421
406134
406214
418777
430023
460100
465646
