About This File
Operator manual
IPL
Wiring
Dated 11/29/62
Supplement #1 #123-A dated 1/15/63
Supplement #2 #123-B dated 5/10/63
15 pages 1.97MB
#123 manual is an earlier version.
#A-7136 has later info, including the 1054 style steering
IPL #A-7136
Wiring
17 pages 2.19MB
Includes PSB #048 #058 #060 #080 #399C
Wiring Color pdf
1 page 176KB
Tractor drive belt 1592 nla from Toro (4L x 82.00" or 1/2" x 82")
Starter/generator belt
Kohler 10hp, 12hp - 235262 (7345 Gates .410" x 35.09" 36 degree) (25-7345 Napa .410" x 35.09" 36 degree)
Wheel Horse 1593 (3L x 34.4") - nla (Gates replacement 6735 3/8" x 35" 38 degree)
Early production 953s can be distinguished by four primary features. The headlights are recessed behind the grill rather than protruding from it, they use a "Ross" steering gear rather than the later "Fan Gear", Have Serial Numbers beginning with "62" and the steering wheel has a diamond shaped center cap rather than a round one. It is thought that only about one thousand early models were produced though no actual production numbers are available. (953 nut)
Generator light bulb #57
Hydraulic pump belt - Wheel Horse 1591 nla Use Toro 83-2900, Gates 6748 3/8"x48", Napa 3L480W 3/8"x48".
Lube chart SS
Details & Attachments
2 pages 108.96KB
1963 model 953
1963 serial numbers that have shown up for the 953 - Late models may not be correct because owners often don't know what model they have
62-00100
62-00137
62-00155
62-00168
62-00176
62-00292
62-00304
62-00369
62-00379
62-00381
62-00461
62-00533
62-00534
62-00560
62-00580
62-00589 - Thought to be a 1054?
62-00602
62-00604
62-00613
62-00627
62-00672
62-00727
62-00728
62-00780
62-00798
62-00799
62-0083x
62-00921
62-00928
30637 - May be 36637
32508
34148
34163
34250
34444
34578
34598
34637
34661
34683
34696
34698
34728
34945
34976
36637 - May be 30637
41516
41745
41762
41969
42062 - Decaled a 953
42110
42111
42143 - May be a 1054
42159 - May be a 1054
1963 953 production changed to 1964 model 1054 production at some point
Early 1964 model 1054
019578 - May be a typo Also posted as 049578
019725 - May be a typo Also posted as 049725
042143 - May be a 953
042159 - May be a 953
042296
042299
042416
042424
042431
042540
042649
042654
042698
042805
042810
