About This File
Operator manual
IPL
7 pages each
Includes PSB #142
Fits 10hp 12hp 14hp 16hp except GT-14 tractors
Drive belt 102742 replaced by 94-2501 (1/2" x 103")
Spindle belt 6738 (1/2" x 86")
Mower spindle assemblies could be S, K, V, X or Z
For K see service bulletin 211C
For X and V see service bulletin 207B
6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Stens replacement - 3 of 350-041 still available March 6, 2021
Mower Rotary 1973 42in SD model 5-1010
1973 serial numbers that have shown up for the 5-1010
0233248 - Model 5-1010-8
0912741 - Model 5-1010-8
0913013 - Model 5-1010-8
0913499 - Model 5-1010-8
0956642 - Could be a 1974 model
0976509 - Model 5-1010-8
Mower Rotary 1974 42in SD model 5-1010
1974 serial numbers that have shown up for the 5-1010
0045496 - Model 5-1010-9
0956642 - Could be a 1973 model
0999526 - Model 5-1010-9
Manual sources
Mower Rotary 42in SD 1973-74 5-1010 & 48in SD 5-1210 OM IPL1 #749-750
Mower Rotary 42in SD 1973-74 5-1010 & 48in SD 5-1210 OM IPL2 #A-5328
Mower Rotary 42in SD 1973-74 5-1010 & 48in SD 5-1210 OM IPL3 #803881
Mower Rotary 42in SD 1974 5-1010 OM #803859
