About This File
Operator manual
IPL
7 pages each
Mower Rotary 48in SD 1973-74 5-1210 (new) OM IPL #A-5328
Mower Rotary 48in SD 1973-74 5-1210 (newer) OM #803859
Mower Rotary 48in SD 1973-74 5-1210 (newest) OM IPL #803881
Drive belt 102742 replaced by 94-2501 (1/2" x 103")
Spindle belt 1594 (1/2" x 107.21")
Mower spindle assemblies could be S, K, V, Y or Z
For K see service bulletin 211C
For V and Y see service bulletin 292B
4380 blade replaced by 6758 and then by 100202 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Mower Rotary 1973 48in SD model 5-1210 - Fits 12hp, 14hp and 16hp long frame tractors
1973 serial numbers that have shown up for the 5-1210
0134525 - Located in Kent England - Possibly made in Belgium
0939473
0939620 - Model 5-1210-8
Mower Rotary 1974 48in SD model 5-1210 - Fits 12hp and 16hp C-Series tractors
