161 files
-
Free
Switch Seat push button 111645 replaced by 112430 List.jpg
By gwest_ca-(File Mod)
111645 replaced by 112430 seat push button switch wiring ($58.91 May 22, 2020)
White wire connector part number 111498 ($3.01 May 22, 2020)
Same as used with the 111332 pto switches and used with 114240 and 112418 seat switches.
Taken from 1986 300-Series 400-Series IPL SM Wiring manual
Switch push-button 111645 used on
1986 models 21-08K801, 21-08K802, 21-10K802, 21-10K803, 21-12K802, 21-12K803, 21-12KE01, 21-12KE02, 22-08B302, 22-11B302, 22-11B502, 22-12TE01, 31-14K801, 31-16K802, 31-17K802, 31-17KE02, 31-20KE01
1987 model B2-11B392
29 downloads
Updated
-
Free
Switch Micro 40-8200 List.jpg
By gwest_ca-(File Mod)
Taken from #492-4509 Electrical Manual
40-8200 micro switch used on
1988 model 56127
1989 models 56123, 56127, 56128
1990 models 56123, 56133, 56176, 56177, 56185, 56190, 56195
1991 models 56132, 56133, 56176, 56177, 56185, 56190, 56195
1992 models 56132, 56133, 56177, 56185, 56190, 56195
1993 models 70040, 70060
1994 models 70040, 70060
1995 models 70040, 70060
30 downloads
Updated
-
Free
Switch Micro 88-9931 List.jpg
By gwest_ca-(File Mod)
Taken from the #492-4761 Electrical Manual
Microswitch description and testing Micro switch
88-9931 Micro switch used on
1993 models 70042, 70080, 70120, 70140, 71140, 71180, 71181, 71200, 71202, 71203
1994 models 70080, 70100, 70120, 70141, 71182, 71184, 71191, 71200, 71202, 71213
1995 models 70080, 70120, 70141, 70142
1996 models 70040, 70060, 70080, 70081, 70120, 70183
1997 models 70040 x 2, 70060, 70081, 70183
1998 models 70040, 70082
1999 models 70089, 70171, 73429, 73449
2000 models 70089 x 3, 70171, 73429, 73449
2001 models 70089, 70171, 73429, 73449
2002 models 70089, 73450
2003 model 73450
2004 model 73450
2005 model 73450
2007 model 73450
21 downloads
Updated
-
Free
Switch Neutral Clutch 115230 List.jpg
By gwest_ca-(File Mod)
Taken from #492-3203 Electrical Manual
115230 clutch neutral switch used on
1989 model E2-17K502
1990 models 41-20O801, 41-20OE01, R1-18OE02, R2-17K501, R2-17K502
1991 models 22-14O501, 22-14OE01, 31-10K802, 31-12K802, 31-16O803, 32-10B5202, 32-10BE02, 32-12B5A3, 32-12BEA3, 32-12O502, 32-12OE02, 41-20OE02, 51-12KE01, 51-16OE01, R2-12O501, R2-12OE01, S2-12B502
1992 models 22-14O502, 22-14OE02, 31-10K803, 31-12K804, 31-16O804, 32-10B503, 32-10BE03, 32-12O803, 32-12OE03, 41-20OE03, 42-16BE01, 51-12KE02, 51-16OE02, R1-20OE02, R2-12O502, R2-12OE02, R2-16BE01
1993 models 72040, 72041, 72060, 72081, 72101, 73401, 73421, 73501, 73520
1994 models 72042, 72043, 72062, 72063, 72083, 72103, 73421, 73501, 73520
1995 models 72042 x 2, 72043 x 2, 72062 x 2, 72063 x 2, 72103 x 2, 73401 x 2, 73421 x 2, 73501 x 4, 73520 x 2
1996 models 72042, 72043, 72045, 72062, 73401, 73403, 73421, 73423, 73501, 73502, 73521
1997 models 72045, 73403, 73423, 73502, 73521
1998 models 72045 x 2
1999 model 72047
2000 model 72049
25 downloads
Updated
-
Free
Switch Micro Pto Lever 114565 List.jpg
By gwest_ca-(File Mod)
114565 Micro Lever Switch
These switches came in the SA121395 service assembly for a recall on the 1984-1988 A-85, A-115 and 100-Series of tractors.
Service bulletin WH61-90 #442
3 pages 98KB
Instructions 3319-626
1 page 55KB
114565 Micro Lever Switch used on
1989 models E3-10B401, E3-12K602
1990 models R3-10B401, R3-12B601, R3-12K601
1991 models R3-10B402
1992 models R3-10B404, R3-12B602
1993 model R3-10B404
56 downloads
Updated
-
Free
Switch Pto Electric clutch Toggle 105027 List.jpg
By gwest_ca-(File Mod)
Switch pto 105027 for electric pto clutch
The files are photos only
105027 electric pto switch used on
1976 D-160 Automatic model 61-16OS01
1976 D-160 Automatic model 61-16OS02
1976 D-200 Automatic model 61-20KS01
1976 D-200 Automatic model 61-20KS02
1977 D-160 Automatic model 71-16OS01
1977 D-200 Automatic model 71-20KS01
1978 D-160 Automatic model 81-16OS01
1978 D-200 Automatic model 81-20KS01
1979 D-160 Automatic model 91-16OS01
1979 D-200 Automatic model 91-20KS01
1979 D-200 Automatic model 91-20KS02
1980 D-160 Automatic model 01-16OS01
1980 D-200 Automatic model 01-20KS00
1981 D-200 Automatic model 01-20KS00
1988 724-Z model Z1-24OE01 Zero-turn mower
1989 724-Z model Z1-24OE02 Zero-turn mower
31 downloads
Updated
-
Free
Switch Pto Electric clutch Toggle 116716 List.jpg
By gwest_ca-(File Mod)
Taken from #492-4509 Electrical Manual
82-12o502* - Correct
82 -12o502 - Not correct
82-12o502 - Suspicious and not checked or determined yet
Pto switch 116716 used on
1990 models 32-10B501, 32-10BE01, 32-12O501, 32-12OE01, 32-16BE01
1991 models 32-12O5A1, 32-12OEA1, 32-12B5A2, 32-12BEA2
27 downloads
Updated
-
Free
Switch Pto Electric clutch Toggle 78-3030 List.jpg
By gwest_ca-(File Mod)
Taken from #492-4509 Electrical Service Manual
78-3030 Pto switch used on
1991 models 22-14O501, 22-14OE01, 32-10B502, 32-10BE02, 32-12B5A3, 32-12BEA3, 32-12O502, 32-12OE02, R2-12O501, R2-12OE01, S2-12B502
1992 models 22-14O502, 22-14OE02, 32-10B503, 32-10BE03, 32-12O503, 32-12OE03, 42-16BE01, R2-12O502, R2-12OE02, R2-16BE01
1993 models 72040, 72041, 72060, 72081, 72101
34 downloads
Updated
-
Free
Switch Ignition Magneto Keyed 920163 replaced by 117292 List.jpg
By gwest_ca-(File Mod)
Switch Ignition Magneto Keyed 920163 replaced by 117292
1 page from #492-4509 Demystification Guide
Rotated the switch to place the single terminal at the top.
1 page 138KB
6-terminal 3-position for magneto ignition.
Used on the 600-Series zero turn models with battery ignition by using the A terminal to power the ignition. The M and G terminals are not used.
82-12o502* - Correct
82 -12o502 - Not correct
82-12o502 - Suspicious and not checked or determined yet
Magneto ignition switch 920163 used on
1990 models Y1-12OE01, Y1-16OE02
Magneto ignition switch 117292 used on
1991 models Y1-12OE02, Y1-16OE03, Y1-20OE02 (Y1-16OEE3e found on 3320-673 OM)
1992 models Y1-16OE04, Y1-16OEE4*e, Y1-20OE03
1993 models 74021, 74041, 74101
1994 models 74021, 74041, 74101, 74120
1995 models 74021, 74101, 74120
25 downloads
Updated
-
Free
Switch Ignition Battery Keyed 88-9830 replaced by 104-2541 List.jpg
By gwest_ca-(File Mod)
88-9830 replaced by 104-2541
6-terminal 3-position for battery ignition - Often used to control a kill relay for magneto ignition
Used on the XL-Series tractors and Time Cutter zero turn models
Switch rotated to put single terminal at the top
1 page 125KB
82-12o502* - Correct
82 -12o502 - Not correct
82-12o502 - Suspicious and not checked or determined yet
88-9830 used on
1993 models 70040, 70042, 70080, 70120, 70140, 71140, 71180, 71181, 71200, 71202, 71203
1994 models 70100, 70141, 71182, 71184, 71191, 71200, 71202, 71213
1995 models 70060, 70141, 70142, 71182, 71184 x 2, 71191 x 2, 71192, 71200 x 2, 71202, 71205, 71213 x 2, 71216
1996 models 70040, 70060, 70081, 70131, 70142, 70183, 71182, 71184, 71185, 71188, 71191, 71192, 71193, 71196, 71201, 71205, 71217, 71218
1997 models 70040 x 2, 70060, 70081, 70131, 70142, 70183, 71185, 71188, 71189, 71190, 71193, 71196, 71201, 71205, 71208, 71215, 71217, 71218, 71219
1998 models 70040, 70041, 70060, 70082, 70084, 71185, 71188, 71189, 71190, 71196, 71201, 71208, 71215, 71218, 71219
1999 models 70044, 70089, 70122, 70171, 70186, 71197, 71198, 71199, 71209, 71220, 71221, 71240, 71254, 70122, 71280
2000 models 70044 x 2, 70089 x 2, 70122, 70171, 71197, 71199, 71209, 71212, 71223, 71225, 71226, 71241, 71280, 71300, 77102, 77104, 77106
2001 models 70044, 70089, 70122, 70171, 71199, 71209, 71223, 71226, 71227, 71233, 71242, 71282, 71301
2002 models 70044, 70089, 70125, 70184, 71199, 71209, 71223 x 2, 71226, 71227 x 2, 71228 x 2, 71233, 71242 x 2, 71283
2003 models 70125, 70184,71199, 71209, 71223, 71227, 71228, 71233, 71242, 71245, 71283
2004 models 70185, 70186, 71199, 71209, 71223, 71227, 71228, 71242, 71243, 71245, 71283, 71285
2005 models 70185, 70186, 71199, 71209 x 2, 71246, 71286, 71427, 71428, 71429
2006 models 70185, 70186, 71209, 71246, 71286
2007 models 70185, 70186, 71209, 71246, 71286
104-2541 used on
2007 models 74406, 74407
2008 model 74406
88-9830 used on
2008 models 70185, 70186, 71209, 71252, 71253
2009 models 70185, 70186, 71252, 71253, 71257, 74433, 74437
2010 models 70185, 70186, 71252 x 2, 71253, 71257
2011 models 70186, 71254, 71255
2012 models 71254, 71255
2013 models 71254, 71255
Tractor Switch IgnitionMagneto ignition with recoil start 22509652 downloads
Updated
-
Free
Switch Ignition 104270 List.jpg
By gwest_ca-(File Mod)
82-12o502* - Correct
82 -12o502 - Not correct
82-12o502 - Suspicious and not checked or determined yet
104270 Ignition switch used on
1975 models 3-5001, 3-5002, 13-5000
1979 models 93 -05BP01, 93 -05BP02, 93 -08BP01, 93 -08BP02, 93 -08XP02, 93 -11BP01
1980 model 03-08EP01*
1981 model 03-08EP01*
1982 model 03-08EP01*
1983 model 03-08EP01*
37 downloads
Updated
-
Free
Switch Ignition Battery Keyed 101917 replaced by 92-6785 List.jpg
By gwest_ca-(File Mod)
2 pages from Demystification Guide #492-4761
Switch rotated to place single terminal at the top
1 page 142KB
How to troubleshoot
101917 switch replaced by 92-6785
5-terminal 4-position key switch
This switch requires a starter solenoid
82-12o502* - Correct
82 -12o502 - Not correct
82-12o502 - Suspicious and not checked or determined yet
-------------------------------------------------------------------------------------------------------------------------------------------
Tractor Switch Ignition Battery ignition with electric start 101917
(Threads 5/8"-32) 5-terminal 4-position used 1972-1974
101917 5-terminal 4-position replaced by 92-6785
Switch 101917 used on
1970 model 1 -8755 is not correct. Shows up in the online lists because Toro included the D-Series parts list with the Lawn Ranger.
1972 models 1-0110*, 1-0301*, 1-0311*, 1-0320*, 1-0330*, 1-0401*, 1 -0402, 1-0410*, 1-0422*, 1-0423*
1973 models 1-0120*, 1-0130*, 1-0340*, 1-0350*, 1 -0355*, 1-0360*, 1-0365*, 1-0370*, 1-0430*, 1-0435*, 1-0440*, 1-0460*, 1-0465*, 1-0470*, 1-0475*, 1-0600*, 1-0601*, 1-0610*, 1-0620*
1973 model 1-0355 - One made in Belgium and located in Wales? Suspect 1973 12hp 8-Speed because of the 101917 switch listed - Not on the Belgium list
1974 model 1-0393*
1974 C-120 8-Speed model 1-0353 - Listed in PSB #301E for 1973-74. Suspect 1973 12hp 8-Speed is wrong ? - Most likely a 1974 model using a 3 key-position switch - 1974 on Belgium list
1974 C-120 8-Speed model 1-0354 - Listed in PSB #301E for 1973-74. Suspect 1973 12hp 8-Speed is wrong ? - Most likely a 1974 model using a 3 key-position switch - 1974 on Belgium list
--------------------------------------------------------------------------------------------------------------
Tractor Switch Ignition Battery ignition with electric start 92-6785 ----------- (The switch key function is not correct in most manuals.)
(Threads ? Retained by 700919 nut) 5-terminal 4-position used 1994-2007
Replaces 101917 5-terminal 4-position
92-6785 5-terminal 4-position available 06/08 $31.47 from RCPW
Battery style of ignition switch with "I" (eye) terminal
Also used on magneto ignition to control a kill relay.
Switch 92-6785 used on
1994 models 72042, 72043, 72062, 72063, 72083, 72103
1995 models 72042 x 2, 72043 x 2, 72062 x 2, 72063 x 2, 72084, 72103 x 2
1996 models 72042, 72043, 72045, 72046, 72062, 72064, 72084, 72085, 72102, 72104, 72110
1997 models 72045, 72046, 72064, 72085, 72102, 72104, 72110
1998 models 72045 x 2, 72046 x 2, 72064 x 2, 72085 x 2, 72102 x 2, 72104 x 2, 72110 x 2, 73428 x 2, 73448 x 2, 73470, 73540, 73541, 73545, 73546, 73550, 73551, 73560
1999 models 72047, 72048, 72070, 72086, 72105, 72106, 72115, 73429, 73449, 73471, 73542, 73547, 73552, 73561, 73570, 73580, 73590
2000 models 72049, 72050, 72071, 72087, 72107, 72108, 72116, 73429, 73449, 73471 x 2, 73542 x 2, 73547 x 2, 73552, 73561 x 3, 73561SEI, 73570, 73580, 73590,74570, 74590
2001 models 72051, 72052, 72072, 72087, 72107, 72108, 72116, 73429, 73449, 73471, 73542, 73547, 73561, 73580, 73590, 74570, 74590
2002 models 72051, 72052, 72072, 72087, 72107, 72108, 72116, 73450, 73542, 73561, 73570, 73590, 74570, 74590
2003 models 72107, 72116, 72200, 72201, 72202, 73450, 73542, 73561, 73570, 73590, 74570, 74590
2004 models 72200, 72201, 72202, 72211, 72212, 73450, 73542, 73561, 73590, 74570, 74571, 74590
2005 models 72200, 72201, 72202, 72211, 72212, 73450, 73561, 74570, 74571, 74590
2006 models 72211, 72212, 74570, 74571, 74591
2007 models 73450, 74573, 74582, 74592 x 2
2008 models 74573, 74582, 74592 x 2
2009 models 74573 x 2, 74582, 74590, 74592, 74593
2010 models 74573, 74582, 74593
2011 models 74582, 74593 x 2
386 downloads
Updated
-
Free
Switch Ignition Battery Keyed 4988 replaced by 7263 List .jpg
By gwest_ca-(File Mod)
Battery ignition switch with electric starter/generator 4988
(Threads 5/8"-32)
3-terminal 3-position used 1964-1967
4988 switch replaced by 7263
4988 ignition switch used in
1964 models 854, 1045
1965 models 855, 875, 1055, 1075
1966 models 856, 876, 1056, 1276
1967 models 857, 877, 1257, 1277
---------------------------------------------------------------------------------------------------------------------------------------------------------
Battery ignition switch with electric starter/generator 7263
(Threads 9/16"-24)
3-terminal 3-position
7263 replaces 4988
7263 3-terminal 3-position available 06/2008 $32.04 from RCPW
7263 3-terminal 3-position available 06/2017 $60.18 from RCPW
7263 3-terminal 3-position available 01/2021 $71.37 from RCPW
7263 ignition switch used in
1967 models 867, 1067, 1267
1968 Commando 8 model 1-4831
1968 Charger 12 model 1-7231 - Early production has battery ignition and electric starter/generator - Mid year change
1968 Raider 12 model 1-6231 - Early production has battery ignition and electric starter/generator - Mid year change
The original parts list for the 1968 Commando 8 model 1-4831 list a 7262 ignition switch but that is the part number for the key (typo). Switch is 7263.
Cole Hersee 95521B
108 downloads
Updated
-
Free
Switch Ignition Magneto Keyed 116338 List.jpg
By gwest_ca-(File Mod)
1 page 163KB from Demystification Guide #492-4509
1 page 161KB from Demystification Guide #492-3203
Switch turned over to place START terminal at the top
1 page 167KB
How to troubleshoot
Note on the switch description page - The switch terminals may not be properly identified.
116338 switch ($50.46 May 22, 2020)
5-terminal 3-position key switch for magneto ignition
This switch requires a starter solenoid
--------------------------------------------------------------------
Tractor Switch Ignition Magneto ignition with electric start 116338
(Threads 5/8"-32) 5-terminal 3-position switch
116338 5-terminal 3-position available 08/08 $23.80 from RCPW
Used 1991 thru 1997
82-12o502* - Correct
82 -12o502 - Not correct
82-12o502 - Suspicious and not checked or determined yet
116338 Magneto ignition switch used on
1991 models 22-14O501*, 22-14OE01*, 32 -10B502, 32 -10BE02, 32-12O502*, 32-12OE02*, R2-12O501*, R2-12OE01* *****
1992 models 22-14O502*, 22-14OE02*, 31-10K803*, 31-12K804*, 31 -16O804, 32 -10B503, 32 -10BE03, 32-12O503*, 32-12OE03*, 42-16BE01*, 51-12KE02*, 51 -16OE02, R1-12K804*, R2-12O502*, R2-12OE02*, R2-16BE01* *****
1993 models 72040*, 72041*, 72060*, 72081*, 72101e*, 73320*, 73380*, 73400*, 73401*
1994 models 73362*, 73380*, 73400*, 73401*, 7 3420, 7 3440 *****
1995 models 73362*, 73400*, 73401* x 3, 7 3420, 7 3440 *****
1996 models 73362*, 73363*, 73400*, 73401*, 73402*, 73403* *****
1997 models 73363*, 73402*, 73403* *****
159 downloads
Updated
-
Free
Switch Pto Safety Rocker 109327 List.jpg
By gwest_ca-(File Mod)
109327 replaced by 98-2392 Rocker switch kit (Wide terminals are NO=Normally open for starter circuit) (Narrow terminals are NC=Normally closed for ignition circuit) - White
98-2392 is a replacement kit following tractor production to address a recall
Service bulletin - 1983-1984 A-Series, 1983-1984 RR-Series, 1982-1984 GT-Series and 1986 models 211-3 and 211-5
Pto rocker switch 109327
Taken from #492-4207 Electrical Service Manual
82-12o502*A - Correct and Tractor Series
82 -12o502 - Not correct
82-12o502 - Suspicious and not checked or determined yet
109327 Rocker switch used on
1982 models 02-08BX01*B, 02-11BE01*B, 02-11BP05*B, 02-16BE01*B, 02-16BP04*B, A1-114201*GT, A1-164201*GT, A1-184801*GT, A2-083201*LT, A2-103201*LT, A2-113701*LT, A2-163701*LT, A2-164201*LT
1983 models 03-08BP03*A, 12-11BE01*B, 12-11BP01*B, 12-16BE01*B, 12-16BP01*B, 23-08BP02*A, 23-08BX01*A, 23-08XP01*A, 23-11BP02*A, A1-114202*GT, A1-164202*GT, A2-083202*LT, D1-184801*GT, D2-113601*LT, D2-113701LT*, D2-163701*LT
1984 models 12-11BP02*B, 12-16BE02*B, 23-08BP03*A, 23-11BP03*A, A1-11B801*GT, A1-16B801*GT, A1-18BE01*GT, A2-11BP01*LT, A2-11BX01*LT, A2-16BP01*LT, B2-11BX91*B
1985 models 33-08B301*100, 33-08B501*100, 33-08BP01*A, 33-08X301*A, 33-11B501*100, 33-11BP01*A
1986 models 33-08B303*100, 33-08B502*100, 33-08X303*100, 33-11B502*100, B3-08B303*100, B3-11B502*100
46 downloads
Updated
-
Free
Relay Low oil 106833 replaced by 99-5365 kit List
By gwest_ca-(File Mod)
Taken from #492-4207 and #492-4509 Electrical manuals and PSB's
1 page 64KB
Used as a kill relay on 1981 B-Series tractors with magneto ignition. The battery style ignition switch controls the relay to ground the magneto ignition.
Starting in 1986 used in the low-oil starter circuit for single-cylinder Kohler engines.
106833 3-terminal relay replaced by a 5 terminal substitute in production because of a parts shortage.
These were replaced by SA121378 service assembly which was replaced by 99-5365 kit.
The 99-5365 kit contained a 48-4700 relay which has been replaced by 116397 relay.
116397 relay used on 1990 312-8 for the low oil starter circuit and 1990 200-Series and 500-Series as a starter relay.
82-12o502*C - Correct and Tractor Series
82 -12o502 - Not correct
82-12o502 - Suspicious and not checked or determined yet
106833 Low oil relay used on
1986 models 21 -08K801, 21 -08K802, 21-10K802*300, 21-10K803*300, 21-12K802*300, 21-12K803*300, 21-12KE01*300, 21-12KE02*300, 31-14K801*400, 31-16K802*400, 31 -17K802, 31 -17KE02, 31 -20KE01
1987 models 21 -08K803, 21-10K804*300, 21-12K804*300, 21-12KE03*300, 31-14K802*400, 31-16K803*400, 31 -18K801, 31 -18KE01, 41 -18KE01
1988 models 21 -08K804, 21-10K805*300, 21-12K805*300, 31-14K803*400, 31-16K804*400, B1 -16O801, E1-12K801
1989 models 21-10K806*300, 21-12K806*300, 31-14K804*400, 31 -16O801, B1 -16O802, E1-12K802
1990 models R1-12K801, R1 -16O801
Links to service bulletins
28 downloads
Updated
-
Free
Relay Ignition kill 106833 replaced by 99-5365 kit List
By gwest_ca-(File Mod)
Taken from #492-4207 and #492-4509 Electrical manuals and PSB's
1 page 64KB
Used as a kill relay on 1981 B-Series tractors with magneto ignition. The battery style ignition switch controls the relay to ground the magneto ignition.
Starting in 1986 used in the low-oil starter circuit for single-cylinder Kohler engines.
106833 3-terminal relay replaced by a 5 terminal substitute in production because of a parts shortage.
These were replaced by SA121378 service assembly which was replaced by 99-5365 kit.
The 99-5365 kit contained a 48-4700 relay which has been replaced by 116397 relay.
116397 relay used on 1990 312-8 for the low oil starter circuit and 1990 520-H as a starter relay.
82-12o502*C - Correct and Tractor Series
82 -12o502 - Not correct
82-12o502 - Suspicious and not checked or determined yet
106833 Ignition kill relay used on
1978 models 81 -08K801, 81 -10K801, 81 -12K801, 81 -12KS01, 81 -14K801, 81 -14KS01, 81-16B801*C, 81-16BS01*C, 81 -16K801, 81 -16KS01
1979 models 91 -08K801, 91 -08K802, 91 -10K801, 91 -10K802, 91-11B801*C, 91 -12K801, 91 -12K802, 91 -12KS01, 91 -14K801, 91 -14K802, 91 -14KS01, 91-16B801*C, 91-16B802*C, 91-16BS01*C, 91-16BS02*C, 91 -16K801, 91 -16KS01
1980 models 01-11B803*, 02-08BP01*B, 02-11BP02*B, 02-11BX01*B, 02-16BP01*B
1981 models 01-11B804*GT, 02-08BP02*B, 02-08BP03*B, 02-11BP03*B, 02-11BP04*B, 02-11BX02*B, 02-11BX03*B, 02-16BP02*B, 02-16BP03*B
1982 models 01-11BH01*SB, 01 -16KH01, 02-11BH01*SB
1986 and later models used 106833 as a low oil relay
Links to service bulletins
76 downloads
Updated
-
Free
Switch Pto Electric clutch Toggle 78-9670 List.jpg
By gwest_ca-(File Mod)
78-9670 Pto toggle switch
Taken from the #492-4509 Electrical Manual
82-12o502*A - Correct and Tractor Series
82 -12o502 - Not correct
82-12o502 - Suspicious and not checked or determined yet
78-9670 Pto toggle switch used on
1991 model Z1-24OE04*Z
1992 model Z1-24OE05*Z
1993 model 74140*Z
30 downloads
Updated
-
Free
Switch Pto Safety Push-button 107072 List.jpg
By gwest_ca-(File Mod)
107072 Push button switch NO=Normally open - Black bottom (This switch not named correctly for this application/year @ Toro)
Taken from #492-4207 Electrical Service Manual
82-12o502*A - Correct and Tractor Series
82 -12o502 - Not correct
82-12o502 - Suspicious and not checked or determined yet
107072 Push-button switch used on
1980 models 01 -14E801, 03-05BP01*A, 03-08BP01*A, 03-08XP01*A, 03-11BP01*A
1981 models 01 -14E801, 03-05BP02*A, 03-08BP02*A, 03-11BP02*A
1982 models 01 -14E801, 23 -05BP01, 23-08BP01*A, 23-11BP01*A, 23-11BX01*A, A3 -053201, A3-083201*RR
1983 model 01 -14E801
20 downloads
Updated
-
Free
Switch Pto Safety Push-button 109329 List.jpg
By gwest_ca-(File Mod)
Push-button switch 109329 NC=Normally closed - White bottom
Used on pto
Taken from #492-4207 Electrical Service Manual
82-12o502*A - Correct and Tractor Series
82 -12o502 - Not correct
82-12o502 - Suspicious and not checked or determined yet
109329 Push-button switch used on
1981 models B3-08B302
1982 models 23-05BP01*A, 23 -08BP01, 23 -11BP01, 23 -11BX01, A3-053201*A, A3 -083201
1985 models 33-08B301, 33-08B501, 33-08BP01, 33-08X301, 33-11B501, 33-11BP01
1986 models 33-08B303, 33-08B502, 33-08X303, 33-11B502, B3-08B303, B3-11B502
1987 models 33-08B304, 33-08B401, 33-08B503, 33-11B503, 33-11B601, B3-08B391, B3-11B591, C3-12K501
1988 models 33-08B402, 33-08B504, 33-11B602, C3-12K502
1989 models E3-10B401, E3-12K602
1990 models R3-10B401, R3-12B601, R3-12K601
1991 model R3-10B402
1992 model R3-10B404, R3-12B602
1993 model R3-10B404
23 downloads
Updated
-
Free
Switch Starter push-button 1751 List.jpg
By gwest_ca-(File Mod)
Large starter push button switch 1751 used 1962-1965
Screen shot of switch
1 page 104KB
82-12o502* - Correct
82 -12o502 - Not correct
82-12o502 - Suspicious and not checked or determined yet
1751 used on
1962 model 32E*, 32 R, 5 02, 552*, 702*
1963 model 33E*, 33 R, 6 33, 653*, 753*, 953*
1964 model 1054*
1965 model 1054A*
30 downloads
Updated
-
Free
Switch Low oil Kohler List.jpg
By gwest_ca-(File Mod)
From the #492-4509 Electrical manual
Low-oil switch used in the starter circuit for Kohler single cylinder engines starting with the 1986 models
Note - Some wiring diagrams show the switch installed NO (Normally open) and some NC (Normally closed)
We do not know if they are correct.
NC will be on the top when viewed from the left side of the tractor.
NO will be on the top when viewed from the right side of the tractor.
The screen shots of Fig. 3 illustrate the switch positions.
Left and right is always from the operator's position in the seat.
Help us out. Observations and comments welcome to solve this mystery.
KH10138 = 47 099 04 - Use 25 704 04
47 099 04 - Use 25 704 04
25 099 03 - Use 25 704 01
25 099 17 - Use 25 704 03
25 099 19 - Use 25 704 04
25 704 01 - Used in Kohler M10 & M12 replaced by 25 704 03 - Not listed for engines used by Wheel Horse
25 704 03 - Used in Kohler M14 & M16 replaced by 25 704 03S - Still available from Toro (PT $143.73 January 29, 2021)
25 704 04 - replaced by 25 704 04S - Still available from Toro (PT $115.32 January 29, 2021)
25 704 04 Low oil switch used in (Kohler #) ------------------------------
K321-60440 - 1986 414-8 31-14K801
K341-71381 - 1986 416-8 31-16K802
M10-461521 - (1987-1991) 1987 310-8 21-10K804, 1988 310-8 21-10K805, 1989 310-8 21-10K806, 1990 310-8 31-10K801, 1991 310-8 31-10K802
M10-461533 - (1992?) This engine listed by Kohler as used by Wheel Horse but no record at Toro
M10- 46154 - Listed by Toro for 1992 310-8 31-10K803 but is listed by Kohler as built for Sanborn M10-461540 (typo?)
M10-461545 - Listed in the 1992 310-8 31-10K803 ipl as the engine used
M12-471527 - (1987-1997) 1987 312-8 21-12K804, 1987 312-A 21-12KE03, 1988 312-8 21-12K805, 1989 312-8 21-12K806, 1990 312-8 31-12K801, 1990 312-H 31-12KE01, 1990 312-8e R1-12K802, 1991 312-8 31-12K802, 1992 312-8 31-12K804, 1992 312-8e R1-12K804, 1993 312-8e 73380, 1994 312-8 73362, 1994 312-8e 73380, 1995 312-8 73362, 1996 312-8 73362, 1996 312-8 73363, 1997 312-8 73363
M12-471546 - 1988 312-8e E1-12K801, 1989 312-8e E1-12K802, 1990 312-8e R1-12K801
M14-601524 - 1987 414-8 31-14K802
M14-601540 - 1988 414-8 31-14K803, 1989 414-8 31-14K804
M16-711523 - 1987 416-8 31-16K803, 1988 416-8 31-16K804
KH10138 Low oil switch used on (Wheel Horse #) ----------------------------
1988 models 21-10K805, 21-12K805, 31-14K803, 31-16K804
1989 models 21-10K806, 21-12K806, 31-14K804
1990 models 31-10K801, 31-12K801, 31-12KE01
1991 models 31-10K802, 31-12K802, 51-12KE01
1992 models 31-10K803, 31-12K804, 51-12KE2
KH10826 Low oil switch used on (Wheel Horse #) --------------------------------------------------
1991 models 31-10K802, 31-12K802, 51-12KE01 - KH10826 listed as a washer for the governor - Should be KH10136 - typo
1992 model R1-12K804
1993 models 73320, 73380
1994 models 73362, 73380
1995 model 73362
1996 model 73362
47-099-04 Low oil switch used on (Kohler #) ----------------------------------------------------------
1996 model 73363
1997 model 73363
Service bulletin on the switch has instructions on how to remove switch without damage.
71 downloads
Updated
-
Free
Relay 98-7249 Description .jpg
By gwest_ca-(File Mod)
Taken from #492-4761 Electrical manual
Common relay 98-7249
Used on 1999 312-8 model 73429
Notice there is a diode or resistor across the coil terminals as illustrated on the relay cover so the polarity of 85 and 86 is important.
85 should be 12VDC +
70 downloads
Updated
-
Free
Switch Ignition Battery Keyed 101876 .jpg
By gwest_ca-(File Mod)
Illustration from PSB #134A
101876 switch used on
1972 GT-14 Automatic model 1-0502
1972 GT-14 Automatic model 1-0503
1973 GT-14 Automatic model 1-0502-8 - Listed in attachment interchange
Not listed at Toro
Discontinued June 10, 2014
92-6785 should be a suitable replacement ignition switch if used with a starter solenoid
35 downloads
Updated
-
Free
Switch Ignition Magneto Keyed 7596 List.jpg
By gwest_ca-(File Mod)
Ignition Magneto ignition with recoil start 7596
(Threads 9/16"-24)
1-terminal 2-position keyed ignition switch
7596 1-terminal 2-position nla
82-12o502* - Correct
82 -12o502 - Not correct
82-12o502 - Suspicious and not checked or determined yet
7596 Magneto ignition switch used on
1968 model 1-3631*
1969 models 1-3741*, 1 -3745
26 downloads
Updated
