Service Bulletins

586 files

  1. Free

    WH61-90 #050 Transmission Usage 1964 Orig.pdf

    1 page 200.84KB
    Dated November 12, 1963
    Models 5025 and 5046 are the same except for the shifters
    All replacement transmissions shipped less shifter and boot including 5047
    1964 model 34E Lawn Ranger
    1964 model 34R Lawn Ranger
    1964 model 604
    1964 model 654
    1964 model 704
    1964 model 754 - missed @ Toro
    1964 model 854
    1964 model 1045 - Not in PSB Used 5025
    1964 model 1054

    45 downloads

    Updated

  2. Free

    WH61-90 #369 Inner Axle Bearing 1984 GT-Series C-Series.pdf

    2 pages 93.93KB
    Dated March 1984

    1533 bearing

    Some models use 8048 transmission carrier bearing (1/2" x 2-1/8" x 2-1/2") and 8052 inner bearing race.

    1984 C-105 8-Speed model 11-10K802
    1984 C-125 8-Speed model 11-12K802
    1984 C-145 Automatic model 11-14KE01
    1984 C-165 8-Speed model 11-16K801
    1984 C-175 Twin Automatic model 11-17KE01

    1984 GT-1100 8-Speed model A1-11B801
    1984 GT-1600 Twin 8-Speed model A1-16B801
    1984 GT-1800 Twin Automatic model A1-18BE01

    93 downloads

    Updated

  3. Free

    WH61-90 #189 Peerless Transaxle Usage 1969-76.pdf

    1 page 431.64KB

    1969 Lawn Ranger model 1-8741
    1969 Lawn Ranger model 1-8745
    1970 Lawn Ranger model 1-8751
    1970 Lawn Ranger model 1-8752 - Not in PSB
    1970 Lawn Ranger model 1-8755 - Not in PSB
    1970 Lawn Ranger model 1-8756
    1971 Lawn Ranger model 2-0200
    1971 Lawn Ranger model 2-0210
    1971 800 Automatic model 1-0450
    1971 800 Special model 1-0150
    1972 Lawn Ranger model 2-0200 - Not listed @ Toro
    1972 Ranger 800 model 2-0211
    1973 Ranger 700 model 2-0220
    1973 Ranger 800 model 2-0230
    1974 A-800 Ranger model 1-0280
    1974 A-800 Ranger model 1-0285
    1974 A-90 Special model 2-4300
    1974 Norlet Commander 8/36 model 2-4300
    1975 A-80 Ranger model 1-0281
    1975 A-80 Ranger model 1-0282 - Not in PSB
    1975 A-80 Ranger model 1-0286
    1975 A-80 Ranger model 1-0287 - Not in PSB
    1975 A-60 Electric Horse model 3-5001
    1975 A-65 Elec-Trak model 3-6000
    1975 B-145 Elec-Trak model 1-0720
    1975 C-185 Elec-Trak model 1-0700
    1976 A-60 26" 4-Speed Rear Engine Rider model 63-05BF01
    1976 A-70 30" 5-Speed Rear Engine Rider model 63-08BP01
    1976 A-90 36" 4-Speed model 62-08BP01
    1976 A-100 36" 4-Speed model 62-10BP01
    1976 B-145 Elec-Trak model 1-0720
    1976 C-185 Elec-Trak model 1-0700

    46 downloads

    Updated

  4. Free

    Toro83-presMisc #0017 Service bulletin Summary & Corrections.pdf

    2 pages 96.37KB
    Dated July 16, 1993

    PSB
    301g - Page 5 Model 31-14OE01 corrected to 31-16OE01 Model Z1-24OE01 corrected to Z1-24OE02
    301e - Page 7 Added engine type to 800 Auto model 1-0450 & 800 Special model 1-0150
    301e - Page 8 Added Pathmaker snowthrower
    301e- Page 8 Corrected type number for 800 Auto model 1-0451
    388a - Kohler PSB #199 - Low oil switch
    399c - Added 1057 to model list
    411 - Wide blade 30227 nla Use 113579. New mower baffles 79-0630 & 79-0640
    430 - Sector gear 5627 nla
    437b - BJ Hydraulics
    T1 - Cancelled - Tires
    T2 - Cancelled
    T3 - Cancelled
    T4 - Use sealed switch 78-9670
    T17 - Kohler PSB #199 - Low oil switch
    T25 - 1990 312-H belt declutch lever
    T26a - Change in service interval

    46 downloads

    Updated

  5. Free

    WH61-90 #128 Electric Pto Clutch Service.pdf

    2 pages 97.69KB

    This bulletin dated November 1970 for 1971 tractor models.
    101472 and 101473 electric clutches

    1971 800 Automatic model 1-0450
    1971 800 Special model 1-0150
    1971 Bronco 14 model 1-0420
    1971 Bronco 14 model 1-0421
    1971 Charger 12 model 1-0400
    1971 Raider 10 model 1-0300
    1971 Raider 12 model 1-0310
    1971 GT-14 model 1-0500
    1971 GT-14 model 1-0501

    126 downloads

    Updated

  6. Free

    WH61-90 #217 Failed Driven Coupling 18hp Auto & D-Series Auto.pdf

    5 pages 132.42KB

    Service assembly SA #105147
    Also see PSB #305

    103029 drive coupling

    1973 18hp Auto model 1-0600
    1973 18hp Auto model 1-0601
    1973 18hp Auto model 1-0610
    1973 18hp Auto model 1-0620

    1974 D-160 Auto model 1-0650
    1974 D-180 Auto model 1-0611
    1974 D-200 Auto model 1-0630

    1975 D-160 Auto model 1-0651
    1975 D-180 Auto model 1-0612
    1975 D-200 Auto model 1-0631

    1976 D-160 Auto model 61-16OS01
    1976 D-160 Auto model 61-16OS02
    1976 D-200 Auto model 61-20KS01
    1976 D-200 Auto model 61-20KS02

    1977 D-160 Auto model 71-16OS01
    1977 D-200 Auto model 71-20KS01

    178 downloads

    Updated

  7. Free

    WH61-90 #260 16hp Onan Rod Bolt Torque.pdf

    1 page 65.24KB

    1976 D-160 Automatic model 61-16OS01
    1976 D-160 Automatic model 61-16OS02
    1977 D-160 Automatic model 71-16OS01
    1978 D-160 Automatic model 81-16OS01
    1979 D-160 Automatic model 91-16OS01
    1979 D-160 Automatic model 91-16OS02 - Not listed @ Toro and may be an invalid model number
    1980 D-160 Automatic model 01-16OS01

    36 downloads

    Updated

  8. Free

    WH61-90 #305 Failed Driven Coupling 18hp Auto & D-Series.pdf

    2 pages 85.06KB
    Dated April 1981

    Service assembly SA #105147
    Also see PSB #217

    103029 drive coupling

    1973 18hp Auto model 1-0600
    1973 18hp Auto model 1-0601
    1973 18hp Auto model 1-0610
    1973 18hp Auto model 1-0620

    1974 D-160 Auto model 1-0650
    1974 D-180 Auto model 1-0611
    1974 D-200 Auto model 1-0630

    1975 D-160 Auto model 1-0651
    1975 D-180 Auto model 1-0612
    1975 D-200 Auto model 1-0631

    1976 D-160 Auto model 61-16OS01
    1976 D-160 Auto model 61-16OS02
    1976 D-200 Auto model 61-20KS01
    1976 D-200 Auto model 61-20KS02

    1977 D-160 Auto model 71-16OS01
    1977 D-200 Auto model 71-20KS01

    1978 D-160 Automatic model 81-16OS01
    1978 D-200 Automatic model 81-20KS01

    1979 D-160 Automatic model 91-16OS01
    1979 D-160 Automatic model 91-16OS02 - Not listed @ Toro and may be an invalid model number
    1979 D-200 Automatic model 91-20KS01
    1979 D-200 Automatic model 91-20KS02

    1980 D-160 Automatic model 01-16OS01
    1980 D-200 Automatic model 01-20KS00

    1981 D-160 Automatic model 01-16OS01 - Not listed @ Toro
    1981 D-200 Automatic model 01-20KS00

    169 downloads

    Updated

  9. Free

    WH61-90 #284 Hydraulic Lift Valve Repair Kit.pdf

    2 pages 76.32KB

    Service assembly SA #101536
    Service assembly SA #105108
    Service assembly SA #105145
    Service assembly SA #105178


    C-Series 103204 valve - Uses oversize O-ring at spool cap end
    1973 10hp Automatic model 1-0470
    1973 10hp Automatic model 1-0475
    1973 12hp Automatic model 1-0460
    1973 12hp Automatic model 1-0465
    1973 14hp Automatic model 1-0430
    1973 14hp Automatic model 1-0435
    1973 16hp Automatic model 1-0440
    1974 B-100 Automatic model 1-0510 - Hydraulic lift optional
    1974 C-120 Automatic model 1-0485
    1974 C-120 Automatic model 1-0490
    1974 C-120 Automatic model 1-0495 - Tecumseh engine
    1974 C-160 Automatic model 1-0480

    84113, Hydraulic Lift, 1975 Fits B-100 Auto, C-120 Auto and C-160 Auto tractors ??????
    1975 B-100 Automatic model 1-0511 - Hydraulic lift optional
    1975 C-120 Automatic model 1-0491
    1975 C-160 Automatic model 1-0481

    84113, Hydraulic Lift, 1976 Fits B-100 Auto, C-120 Auto and C-160 Auto tractors ??????
    1976 C-120 Automatic model 61-12KS01
    1976 C-120 Automatic model 61-12KS02
    1976 C-120 Automatic model 61-12KS03
    1976 C-120 Automatic model 61-12KS04
    1976 C-160 Automatic model 61-16KS01
    1976 C-160 Automatic model 61-16KS02
    1976 C-160 Automatic model 61-16KS03
    1976 C-160 Automatic model 61-16KS04

    84113, Hydraulic Lift, 1977 Fits B-100 Auto, C-120 Auto and C-160 Auto tractors ??????
    1977 C-120 Automatic model 71-12KS01
    1977 C-120 Automatic model 71-12KS02
    1977 C-160 Automatic model 71-16KS01
    1977 C-160 Automatic model 71-16KS02

    C-Series 106680 valve C-141 C-161 C-161 Twin only
    1978 C-121 Automatic model 81-12KS01 - Manual lift standard equipment
    1978 C-141 Automatic model 81-14KS01 - Hydraulic lift standard equipment
    1978 C-161 Automatic model 81-16KS01 - Hydraulic lift standard equipment
    1978 C-161 Twin Automatic model 81-16BS01 - Hydraulic lift standard equipment
    1979 C-121 Automatic model 91-12KS01 - Manual lift standard equipment
    1979 C-121 Automatic model 91-12KS91 - Manual lift standard equipment
    1979 C-141 Automatic model 91-14KS01 - Hydraulic lift standard equipment
    1979 C-161 Automatic model 91-16KS01 - Hydraulic lift standard equipment
    1979 C-161 Twin Automatic model 91-16BS01 - Hydraulic lift standard equipment
    1979 C-161 Twin Automatic model 91-16BS02 - Hydraulic lift standard equipment

    C-Series 108494 valve
    1980 C-125 Automatic model 01-12KE01
    1980 C-125 Automatic model 01-12KS01
    1980 C-145 Automatic model 01-14KE01
    1980 C-145 Automatic model 01-14KS01
    1980 C-165 Automatic model 01-16KE01
    1980 C-165 Automatic model 01-16KS01
    1980 C-165 Automatic model 01-16KS91
    1980 C-175 Twin Automatic model 01-17KE01
    1980 C-175 Twin Automatic model 01-17KS02
    1981 C-125 Automatic model 01-12KE02
    1981 C-145 Automatic model 01-14KE02
    1981 C-165 Automatic model 01-16KE02
    1981 C-175 Twin Automatic model 01-17KE01
    1982 C-145 Automatic model 01-14KE03
    1982 C-175 Twin Automatic model 01-17KE02

    1982 C-195 Twin Automatic model 01-19KE01 - Uses 105178 valve repair kit
    1982 GT-1848 Twin Automatic model A1-184801

    D-Series 102874 valve - Uses oversize O-ring at spool cap end
    1973 18hp Automatic model 1-0600
    1973 18hp Automatic model 1-0601
    1973 18hp Automatic model 1-0610
    1973 18hp Automatic model 1-0620
    1974 D-160 Automatic model 1-0650
    1974 D-180 Automatic model 1-0611
    1974 D-200 Automatic model 1-0630
    1975 D-160 Automatic model 1-0651
    1975 D-180 Automatic model 1-0612
    1975 D-200 Automatic model 1-0631
    1976 D-160 Automatic model 61-16OS01
    1976 D-160 Automatic model 61-16OS02
    1976 D-200 Automatic model 61-20KS01
    1976 D-200 Automatic model 61-20KS02
    1977 D-160 Automatic model 71-16OS01
    1977 D-200 Automatic model 71-20KS01

    D-Series 106681 valve
    1978 D-160 Automatic model 81-16OS01
    1978 D-200 Automatic model 81-20KS01
    1979 D-160 Automatic model 91-16OS01
    1979 D-160 Automatic model 91-16OS02 - Not listed @ Toro and may be an invalid model number
    1979 D-200 Automatic model 91-20KS01
    1979 D-200 Automatic model 91-20KS02
    1980 D-160 Automatic model 01-16OS01
    1980 D-200 Automatic model 01-20KS00
    1981 D-160 Automatic model 01-16OS01 Not listed @ Toro
    1981 D-200 Automatic model 01-20KS00

    Lift valve

    162 downloads

    Updated

  10. Free

    WH61-90 #274 Onan Oil Pickup Service.pdf

    1 page 70.24KB

    1974 D-160 Auto model 1-0650
    1975 D-160 Auto model 1-0651
    1976 D-160 Auto model 61-16OS01
    1976 D-160 Auto model 61-16OS02
    1977 D-160 Auto model 71-16OS01
    1978 D-160 Auto model 81-16OS01
    1979 D-160 Auto model 91-16OS01
    1979 D-160 Auto model 91-16OS02 - This may be an invalid model number. No record @ Toro.
    1980 D-160 Auto model 01-16OS01
    1981 D-160 Auto model 01-16OS01
    1982 D-160 Auto model 01-16OS01 - Last year for D-160 Auto

    35 downloads

    Updated

  11. Free

    WH61-90 #195 Sundstrand Sudden Loss of Power B C D-Series.pdf

    1 page 67.07KB

    Service assembly SA #105124
    No B-Series Auto models in 1976-1977
    It is possible the revised snap ring was used in the 02 models at the factory

    1977 C-120 Automatic model 71-12KS01
    1977 C-120 Automatic model 71-12KS02
    1977 C-160 Automatic model 71-16KS01
    1977 C-160 Automatic model 71-16KS02
    1977 D-160 Automatic model 71-16OS01
    1977 D-200 Automatic model 71-20KS01

    46 downloads

    Updated

  12. Free

    WH61-90 #298c Replacement Parts Electric Pto Clutches.pdf

    9 pages 410.45KB
    Dated September 1984

    See PSB #126
    See PSB #127
    Replaces PSB #128 dated November 1970
    Replaces PSB #298b dated March 1983

    1968 Electro 12 model 1-7235 - 7915 1-1/8" clutch replaced by 101473
    1968 GT-14 (No 1968 model)

    1969 Electro 12 model 1-7245 - 7915 1-1/8" clutch replaced by 101473
    1969 GT-14 model 1-7441 - 8278 1-1/8" clutch replaced by 101473

    1970 Electro 12 model 1-7255 - 9656 1-1/8" clutch replaced by 101473
    1970 GT-14 model 1-7451 - 9656 1-1/8" clutch replaced by 101473
    1970 GT-14 model 1-7452 - 9656 1-1/8" clutch replaced by 101473
    1970 GT-14 model 1-7453 - 9656 1-1/8" clutch replaced by 101473

    1971 Early production long frame tractors used the clutches above
    1971 Late production long frame tractors used the clutches below
    1971 800 Special model 1-0150 uses 1" 101472 clutch
    1971 800 Automatic model 1-0450 uses 1" 101472 clutch
    1971 WorkHorse 800 model 1-0100 - [Crankshaft diameter and clutch unknown]
    1971 Raider 10 model 1-0300 uses 1-1/8" 101473 clutch
    1971 Raider 12 model 1-0310 uses 1-1/8" 101473 clutch

    1972 800 Automatic model 1-0451 uses 1" 101472 clutch
    Clutch Pto Optional 1in 1972 model 8-3521 83521 uses 1" 101472 clutch
    1972 Bronco 14 model 1-0422 uses 1-1/8" 101473 clutch
    1972 Bronco 14 model 1-0423 uses 1-1/8" 101473 clutch
    1972 Charger 10 model 1-0410 uses 1-1/8" 101473 clutch
    1972 Charger 12 model 1-0401 uses 1-1/8" 101473 clutch
    1972 Charger 12 model 1-0402 uses 1-1/8" 101473 clutch
    Clutch Pto Optional 1-1/8in 1972 model 8-3513 83513 uses 1-1/8" 101473 clutch

    1973 10hp Automatic model 1-0470 uses manual pto clutch
    1973 10hp Automatic model 1-0475 uses manual pto clutch

    Clutch Pto Optional 1in 1973 model 8-3521 83521 uses 1" 101472 clutch
    1973 12hp Automatic model 1-0460 uses 1-1/8" 101473 clutch
    1973 12hp Automatic model 1-0465 uses 1-1/8" 101473 clutch
    1973 14hp Automatic model 1-0430 uses 1-1/8" 101473 clutch
    1973 14hp Automatic model 1-0435 uses 1-1/8" 101473 clutch
    1973 16hp Automatic model 1-0440 uses 1-1/8" 101473 clutch
    Clutch Pto Optional 1-1/8in 1973 model 8-3513 83513 uses 1-1/8" 101473 clutch

    1974 A-90 Special model 2-4300 uses 1" 101472 clutch
    Clutch Pto Optional 1in 1974 model 8-3521 83521 uses 1" 101472 clutch
    Clutch Pto Optional 1-1/8in 1974 model 8-3513 83513 uses 1-1/8" 101473 clutch

    1975?

    1976 D-160 Automatic model 61-16OS01 uses 105007 clutch
    1976 D-160 Automatic model 61-16OS02 uses 105007 clutch
    1977 D-160 Automatic model 71-16OS01 uses 105007 clutch
    1978 D-160 Automatic model 81-16OS01 uses 105007 clutch
    1979 D-160 Automatic model 91-16OS01 uses 105007 clutch
    1979 D-160 Automatic model 91-16OS02 uses 105007 clutch - Not listed @ Toro and may be an invalid model number
    1980 D-160 Automatic model 01-16OS01 uses 105007 clutch
    1981 D-160 Automatic model 01-16OS01 uses 105007 clutch
    1982 D-160 Automatic model 01-16OS01 uses 105007 clutch

    246 downloads

    Updated

  13. Free

    WH61-90 #175 Improved 42in 48in Spindle Assembly.pdf

    1 page 72.17KB
    June 1975

    Service Assembly SA #101685 and K spindle
    Remove 9798 shipping retainer before installing washer and pulley
    Add a 1535 thrust washer before installing the pulley to eliminate pulley wobble

    Mower Rotary 1975 42" SD model 5-1011
    Mower Rotary 1976 42" SD model 65-42MS01
    Mower Rotary 1976 42" SD model 65-42MS02
    Mower Rotary 1976 42" RD model 65-42MR01
    Mower Rotary 1977 42" RS model 75-42MS01
    Mower Rotary 1977 42" RD model 75-42MR01

    Mower Rotary 1975 48" SD model 5-1211
    Mower Rotary 1975 48" SD model 5-1221
    Mower Rotary 1976 48" SD model 65-48MS01
    Mower Rotary 1976 48" SD model 65-48MS02
    Mower Rotary 1976 48" SD model 65-48XS02
    Mower Rotary 1977 48" SD model 75-48MS01
    Mower Rotary 1977 48" SD model 75-48XS01

    62 downloads

    Updated

  14. Free

    WH60 #11 400 & 550 tractors.pdf

    Service bulletin #11 issued in 1960
    2 pages 391KB

    44 downloads

    Updated

  15. Free

    WH60 #10 Electric Start System.pdf

    Service bulletin #10 issued in 1960
    6 pages 248.88KB

    41 downloads

    Updated

  16. Free

    WH61-90 #076 Transmission Replacement L-105 L-155 Lawn Ranger Orig.pdf

    1 page 175.70KB
    1 page 83.57KB
    Dated October 1966

    1965 model L-105
    1965 model L-155

    Model 5048 could be upgraded to a model 5053 with kit # 7168

    29 downloads

    Updated

  17. Free

    WH61-90 #098 Conversion Kits no longer covered by warranty.pdf

    1 page 70.57KB
    Dated May 1968

    Kit # 6067 1965 Reo Rider to inside idler system
    Kit # 6069 RM-425 to 2-belt drive system
    Kit # 7168 1965 Lawn Ranger axle and gear kit

    43 downloads

    Updated

  18. Free

    WH61-90 #223 Mid-Mount Idler Spring Bolt 36in Tiller.pdf

    1 page 72.43KB
    Tiller 1978 36in model 87-36TL01
    See PSB #180a, #220
    1978 C-81 8-Speed model 81-08K801
    1978 C-101 8-Speed model 81-10K801
    1978 C-121 8-Speed model 81-12K801
    1978 C-121 Automatic model 81-12KS01
    1978 C-141 8-Speed model 81-14K801
    1978 C-141 Automatic model 81-14KS01
    1978 C-161 8-Speed model 81-16K801
    1978 C-161 Automatic model 81-16KS01
    1978 C-161 Twin 8-Speed model 81-16B801
    1978 C-161 Twin Automatic model 81-16BS01

    42 downloads

    Updated

  19. Free

    WH61-90 #338b Parts Manual Corrections.pdf

    3 pages 123.75KB
    Dated October 1983

    1963 model 953
    1966 model 1046
    1968 Commando 8 model 1-4831
    1970 Commando V7 model 1-4751
    1971 800 Automatic model 1-0450
    1971 800 Special model 1-0150
    1971 Bronco 14 model 1-0420
    1971 Bronco 14 model 1-0421
    1971 Charger 12 model 1-0400 - Uses breakerless magneto ignition
    1971 Lawn Ranger model 2-0200
    1971 Lawn Ranger model 2-0210
    1971 Raider 10 model 1-0300
    1971 Raider 12 model 1-0310 - Uses breakerless magneto ignition
    1971 WorkHorse 800 model 1-0100
    1972 Commando 800 4-Speed model 1-0110
    1972 Lawn Ranger model 2-0200
    1972 Raider 8 model 1-0330
    1972 Raider 10 model 1-0301
    1972 Raider 12 model 1-0311
    1972 Raider 14 model 1-0320
    1972 Ranger 800 model 2-0211
    1973 8hp 4-Speed model 1-0120
    1973 Ranger 700 model 2-0220
    1973 Ranger 800 model 2-0230
    1973 10hp 8-Speed model 1-0365
    1977 D-160 Auto model 71-16OS01
    1977 D-200 Automatic model 71-20KS01

    77 downloads

    Updated

  20. Free

    WH61-90 #018 Engine Cross Reference Reo 1968.pdf

    1 page 151.52KB
    1 page 295.79KB
    1 page 81.72KB
    Dated March 1968

    Engine cross reference

    1967 Reo walking self-propelled 21" mower model LCP-2147 Regal IV
    1967 Reo walking self-propelled 21" mower model LCP-2147-1 Regal IV
    1968 Reo walking self-propelled 21" mower model LCP-2147 Regal IV
    1968 Reo walking self-propelled 21" mower model LCP-2147-1 Regal IV
    1968 LC-2147 - Custom IV
    Mower Reel 1967 21in Walking model LL-217
    Mower Reel 1968 21in Walking model LL-217
    1968 26in Snowthrower model 4-2631
    1968 26in Trailblazer snowthrower model 4-2632
    1968 20in Pathfinder model 4-1031
    1968 6 hp Rear Engine Rider model 2-1231 - Electric start
    1968 6 hp Rear Engine Rider model 2-2231 - Recoil start

    36 downloads

    Updated

  21. Free

    WH61-90 #297a Slot-Clevis Hitch 36in Tiller Conversion 1981.pdf

    3 pages 122.15KB
    Dated April 1981

    Service assembly SA #105104 - Original PSB #179a - Dated March 1976
    Service assembly SA #105105 - Original PSB #180a - Dated March 1976
    Service assembly SA #105111 - Original PSB #180a - Dated March 1976
    Service assembly SA #105112 - Original PSB #179a - Dated March 1976
    Service assembly SA #105162 - Original PSB #220 - Dated February 1978
    Service assembly SA #106629 - Original PSB #220 - Dated February 1978

    Hitch Rear clevis 1969 model 8-5511 85511
    Hitch Rear clevis 1970 model 8-5511 85511
    Hitch Rear clevis 1971 model 8-5511 85511
    Hitch Rear clevis 1972 model 8-5511 85511
    Hitch Rear clevis 1973 model 8-5511 85511
    Hitch Rear clevis 1974 model 8-5511 85511
    Hitch Rear clevis 1975 model 8-5511 85511
    Hitch Rear clevis 1976 model 8-5512 85512
    Hitch Rear clevis 1977 model 8-5513 85513
    Hitch Rear clevis 1978 model 8-5514 85514
    Hitch Rear clevis 1979 model 8-5514 85514
    Hitch Rear clevis 1980 model 8-5515 85515
    Hitch Rear clevis 1981 model 8-5515 85515
    Hitch Rear clevis 1982 model 8-5515 85515
    Hitch Rear clevis 1983 model 8-5515 85515
    Hitch Rear clevis 1984 model 8-5515 85515
    Hitch Rear clevis 1985 model 8-5515 85515
    Hitch Rear clevis 1986 model 8-5515 85515
    Hitch Rear clevis 1987 model 8-5515 85515
    Hitch Rear clevis 1988 model 8-5515 85515

    Hitch Rear slot 1969 model 8-5521 85521
    Hitch Rear slot 1970 model 8-5521 85521
    Hitch Rear slot 1971 model 8-5521 85521
    Hitch Rear slot 1972 model 8-5521 85521
    Hitch Rear slot 1973 model 8-5521 85521
    Hitch Rear slot 1974 model 8-5521 85521
    Hitch Rear slot 1975 model 8-5521 85521
    Hitch Rear slot 1976 model 8-5522 85522
    Hitch Rear slot 1976 model 8-5523 85523
    Hitch Rear slot 1977 model 8-5523 85523
    Hitch Rear slot 1978 model 8-5524 85524
    Hitch Rear slot 1979 model 8-5524 85524
    Hitch Rear slot 1980 model 8-5525 85525
    Hitch Rear slot 1981 model 8-5525 85525
    Hitch Rear slot 1982 model 8-5525 85525
    Hitch Rear slot 1983 model 8-5525 85525
    Hitch Rear slot 1984 model 8-5525 85525
    Hitch Rear slot 1985 model 8-5525 85525
    Hitch Rear slot 1986 model 8-5525 85525
    Hitch Rear slot 1987 model 8-5525 85525

    Tiller 1973 36in model 7-1251
    Tiller 1974 36in model 7-1251
    Tiller 1975 36in model 7-1252
    Tiller 1976 36in model 67-36TL01
    Tiller 1977 36in model 77-36TL01
    Tiller 1977 36in model 77-36TL02
    Tiller 1978 36in model 87-36TL01
    Tiller 1979 36in model 97-36TL01
    Tiller 1980 36in model 07-36TL01
    Tiller 1981 36in model 07-36TL01
    Tiller 1982 36in model 07-36TL01

    82 downloads

    Updated

  22. Free

    WH61-90 #245 Modify 8-5514 Clevis Hitch for More Lift.pdf

    1 page 74.29KB

    Hitch Rear clevis 1978 model 8-5514 85514
    Hitch Rear clevis 1979 model 8-5514 85514

    1978 C-81 8-Speed model 81-08K801
    1978 C-101 8-Speed model 81-10K801
    1978 C-121 8-Speed model 81-12K801
    1978 C-121 Automatic model 81-12KS01
    1978 C-141 8-Speed model 81-14K801
    1978 C-141 Automatic model 81-14KS01
    1978 C-161 8-Speed model 81-16K801
    1978 C-161 Automatic model 81-16KS01
    1978 C-161 Twin 8-Speed model 81-16B801
    1978 C-161 Twin Automatic model 81-16BS01

    1979 C-81 8-Speed model 91-08K801
    1979 C-81 8-Speed model 91-08K802
    1979 C-81 8-Speed model 91-08K891
    1979 C-101 8-Speed model 91-10K801
    1979 C-101 8-Speed model 91-10K802
    1979 C-101 8-Speed model 91-10K892
    1979 C-111 8-Speed model 91-11B801
    1979 C-121 8-Speed model 91-12K801
    1979 C-121 8-Speed model 91-12K802
    1979 C-121 8-Speed model 91-12K891
    1979 C-121 8-Speed model 91-12K892
    1979 C-121 Automatic model 91-12KS01
    1979 C-121 Automatic model 91-12KS91
    1979 C-141 8-Speed model 91-14K801
    1979 C-141 8-Speed model 91-14K802
    1979 C-141 Automatic model 91-14KS01
    1979 C-161 8-Speed model 91-16K801
    1979 C-161 Automatic model 91-16KS01
    1979 C-161 Twin 8-Speed model 91-16B801
    1979 C-161 Twin 8-Speed model 91-16B802
    1979 C-161 Twin Automatic model 91-16BS01
    1979 C-161 Twin Automatic model 91-16BS02

    81 downloads

    Updated

  23. Free

    Toro91-presGT #GT36 5xi Epoxy Patch Screws Torque Specs.pdf

    4 pages 121.80KB
    Dated February 3, 1999

    1998 518xi model 73470 Serial 8900001-8999999
    1998 520Lxi model 73545 Serial 8900001-8999999
    1998 520Lxie model 73546 Serial 8900001-8999999 - Export model
    1998 520xi model 73540 Serial 8900001-8999999
    1998 520xie model 73541 Serial 8900001-8999999 - Export model
    1998 522xi model 73560 Serial 8900001-8999999
    1998 523Dxi model 73550 Serial 8900001-8999999
    1998 523Dxie model 73551 Serial 8900001-8999999

    1999 518xi model 73471 Serial 9900001-9999999
    1999 520xi model 73542 Serial 9900001-9999999
    1999 520Lxi model 73547 Serial 9900001-9999999
    1999 523Dxi model 73552 Serial 9900001-9999999
    1999 522xi model 73561 Serial 9900001-9999999
    1999 520xi model 73570 Serial 9900001-9999999
    1999 520Lxi model 73580 Serial 9900001-9999999
    1999 523Dxi model 73590 Serial 9900001-9999999

    35 downloads

    Updated

  24. Free

    Toro91-presGT #GT29 5xi Battery Cables with Kawasaki Kohler.pdf

    Proper installation of battery cables on the 5xi garden tractors with Kohler and Kawasaki engines
    7 pages 177.01KB

    1998 518xi model 73470 Serial 8900001-8999999
    1998 520xi model 73540 Serial 8900001-8999999
    1998 520xi model 73541 Serial 8900001-8999999 - Export model
    1998 520Lxi model 73545 Serial 8900001-8999999
    1998 520Lxi model 73546 Serial 8900001-8999999 - Export model
    1998 522xi model 73560 Serial 8900001-8999999

    28 downloads

    Updated

  25. Free

    Toro91-presGT #GT34 Grass Blow-Out 5xi 52in SD Mower.pdf

    1 page 108.40KB
    Dated November 9, 1998

    Mower Rotary 1998 52in SD model 78370 Serial 8900001-8999999
    Mower Rotary 1999 52in SD model 78370 Serial 9900001-9999999
    Mower Rotary 2000 52in SD model 78370 Serial 200000001-200999999
    Mower Rotary 2001 52in SD model 78370 Serial 210000001-210999999
    Mower Rotary 2002 52in SD model 78370 Serial 220000001-220999999
    Mower Rotary 2003 52in SD model 78370 Serial 230000001-230999999
    Mower Rotary 2004 52in SD model 78370 Serial 240000001-240999999
    Mower Rotary 2005 52in SD model 78370 Serial 250000001-250999999
    Mower Rotary 2006 52in SD model 78370 Serial 260000001-260999999

    35 downloads

    Updated




×
×
  • Create New...
