586 files
-
Free
WH61-90 #130a Mower Spindle and Pulleys.pdf
By admin-(Admin)
2 pages 160.21KB
WH61-90 #130 a
1 page 107KB
Service Assembly SA 101525
8390 bearing was replaced by 103119 and still available from after-market suppliers. No longer available from Toro.
1966 32" RD mower model RM-326
1967 32" RD mower model RM-327
1968 32" RD mower model 5-2321
1966 36" RD mower model RL-366
1966 36" RD mower model RM-366
1967 36" RD mower model RL-367
1967 36" RD mower model RM-367
1968 36" RD mower model 5-1361
1968 36" RD mower model 5-2361
1969 32" SD mower model 5-0200
1969 36" RD mower model 5-1362
1969 36" RD mower model 5-7361
1969 36" RD mower model 5-7365
1970 32" SD mower model 5-0200
1970 36" RD mower model 5-7362
1970 36" RD mower model 5-7366
1970 36" SD mower model 5-2365
1971 32" SD mower model 5-0200
1971 36" RD mower model 5-0600
1971 36" SD mower model 5-0710
1972 32" SD mower model 5-0200
1972 36" RD mower model 5-0601
1972 36" SD mower model 5-0711
132 downloads
Updated
-
Free
WH61-90 #071 Engine Cross Reference 1955-1966 Orig.pdf
By admin-(Admin)
1 page 233.20KB
Dated December 1965
1955 model RJ-35 - Clinton B1290-1107 or Kohler K90
1956 model RJ-35 - Clinton B1290-1107 or Kohler K90
1957 model RJ-35 - Clinton B1290-1107 or Kohler K90
1958 model RJ-58 - Clinton B1290-1107 or Kohler K90
1959 model RJ-59 - Clinton B1290-1107 or Kohler K90
1960 model 400 - Clinton B1290-1107 or Kohler K91-31388A
1960 model 550 - Lauson H55B-1170
1960 model WT-30 - Kohler K91
1961 model 401 - Clinton B1290-1107 or Kohler K91-31388A (K91-41437A @ Toro is wrong)
1961 model 551 - Lauson H55D-2113
1961 model 701 - Kohler K161S-28522E
1961 model WT-241 5.5hp tiller - Lauson V55D-2339P
1962 model 32E Lawn Ranger - Lauson HT55C-3089
1962 model 32R Lawn Ranger - Lauson HT55C-3088
1962 model 502 - Lauson HT55C-3088
1962 model 552 - Lauson HT55C-3089
1962 model 702 - Kohler K161S-28626E - K161S-28622E at Toro likely a typo
1962 model WT-242 5.5hp tiller - Lauson V55D-2339P
1963 model 33E Lawn Ranger - Lauson H60-75009
1963 model 33R Lawn Ranger - Lauson H60-75016
1963 model 603 - Lauson H60-75016
1963 model 633 - Kohler K141T-29102A
1963 model 653 - Lauson H60-75009
1963 model 753 - Kohler K161S-28626E
1963 model 953 - Kohler K241S-4613A
1963 model WT-242 5.5hp tiller - Lauson V55D-2339P
1964 model 34E Lawn Ranger - Lauson H60-75063B
1964 model 34R Lawn Ranger - Lauson H60-75064B
1964 model 604 - Lauson H60-75064B
1964 model 654 - Lauson H60-75063B
1964 model 704 - Kohler K161T-28937E
1964 model 754 - Kohler K161S-28626E - missed @ Toro
1964 model 854 - Kohler K181S-30108A
1964 model 1045 - Kohler K241AS-46219A
1964 model 1054 - Kohler K241S-46215A
1964 model WT-244 6hp tiller - Lauson V60-70094D
1965 model 605 - Lauson H60-75118D
1965 model 655 - Lauson H60-75117D
1965 model 855 - Kohler K181S-30108A
1965 model 875 - Kohler K181S-30108A
1965 model 1054A - Kohler K241S-46215A - Wrong 47176 spec number @ Toro
1965 model 1055 - Kohler K241AS-46219A
1965 model 1075 - Kohler K241AS-46219A
1965 model L-105 Lawn Ranger - Lauson H60-75118D
1965 model L-155 Lawn Ranger - Lauson H60-75117D
1965 model WT-244 6hp tiller - Lauson V60-70094D
1966 model 606 - Lauson HH60-105014A
1966 model 656 - Lauson HH60-105013A
1966 model 706 - Likely used Kohler K161S-28626E - Not listed @ Toro
1966 model 856 - Kohler K181S-30108D
1966 model 876 - Kohler K181S-30108D
1966 model 1046 - Kohler K241S-46219A - Not in PSB
1966 model 1056 - Kohler K241AS-46333D
1966 model 1076 - Kohler K241AS-46333D
1966 model 1276 - Kohler K301AS-4712B
1966 model L-106 Lawn Ranger - Lauson H60-75118E
1966 model L-156 Lawn Ranger - Lauson H60-75117E
1966 model WT-244 6hp tiller - Lauson V60-70094D
109 downloads
Updated
-
Free
WH61-90 #301e Engine Cross Reference 1955 thru 1984.pdf
By admin-(Admin)
16 pages 208.66KB
Includes 1975-1984 ignition and charging systems
Also see revised #121 for 1969 and 1970 models
1975 A-50 Rear Engine Rider model 3-0114
1975 A-60 Electric Horse model 3-5001 - Not in PSB
1975 A-60 Electric Horse model 13-5000 - Not in PSB
1975 A-65 Elec-Trak model 3-6000 - Not in PSB
1975 A-80 Ranger (E)model 1-0281
1975 A-80 Ranger (E) model 1-0282 - Not in PSB
1975 A-80 Ranger (R model 1-0286
1975 A-80 Ranger ® model 1-0287 - Not in PSB
1975 B-80 4-Speed model 1-0141 - Made in USA
1975 B-100 Automatic model 1-0511
1975 B-145 Elec-Trak model 1-0720 - Not in PSB
1975 C-100 4-Speed model 1-0394 - Made in USA
1975 C-100 8-Speed model 1-0391 (one found made in Belgium
1975 C-120 8-Speed model 1-0357 - Made in USA using Tecumseh HH120-120180D and 5091 transmission
1975 C-120 8-Speed model 1-0375 using Tecumseh HH120-120180E and 5091 transmission
1975 C-120 8-Speed model 1-0395 using Kohler K301S-47421d and 5091 transmission
1975 C-120 8-Speed model 1-0396 using Kohler K301S-47421d and 5091 transmission
1975 C-120 Automatic model 1-0491 (One found made in Belgium)
1975 C-160 8-Speed model 1-0381
1975 C-160 Automatic model 1-0481
1975 C-185 Elec-Trak model 1-0700 - Not in PSB
1975 Commando 800 4-Speed 1-0141 - Made in Belgium
1975 D-160 Automatic model 1-0651
1975 D-180 Automatic model 1-0612
1975 D-200 Automatic model 1-0631
1975 Raider 10 4-Speed model 1-0394 - Made in Belgium - Not in PSB
1975 Raider 12 8-Speed model 1-0357 - Made in Belgium
1975 Raider 12 8-Speed model 1-0375 (One found in Sweden with Kohler K301S-47421d
1975 Raider 14 model 1-0380 (One found in Europe with serial 151298 made in Belgium. This was also a 1974 C-160 8-Speed)- Not in PSB
1976 A-60 Electric Horse model 3-5002 - Not in PSB
1976 A-60 26" 4-Speed Rear Engine Rider model 63-05BF01
1976 A-65 Elec-Trak model 3-6000 - Not in PSB
1976 A-70 30" 5-Speed Rear Engine Rider model 63-08BP01
1976 A-90 36" 4-Speed Rear Engine Rider model 62-08BP01
1976 A-100 36" 4-Speed Rear Engine Rider model 62-10BP01
1976 B-60 8-Speed model 61-07K801
1976 B-60 8-Speed model 61-07K802
1976 B-80 8-Speed model 61-08K801 - Incorrectly named a B-60 @ Toro
1976 B-80 8-Speed model 61-08K802 - Incorrectly named a B-60 @ Toro
1976 B-80 8-Speed model 61-08K803
1976 B-80 8-Speed model 61-08K804 - Incorrectly named a B-60 @ Toro
1976 B-100 8-Speed model 61-10K801
1976 B-100 8-Speed model 61-10K802
1976 B-100 8-Speed model 61-10K803
1976 B-100 8-Speed model 61-10K804
1976 B-145 Elec-Trak model 1-0720 - Not in PSB
1976 C-120 8-Speed model 61-12K801
1976 C-120 8-Speed model 61-12K802
1976 C-120 8-Speed model 61-12K803
1976 C-120 8-Speed model 61-12K804
1976 C-120 Automatic model 61-12KS01
1976 C-120 Automatic model 61-12KS02
1976 C-120 Automatic model 61-12KS03
1976 C-120 Automatic model 61-12KS04
1976 C-140 8-Speed model 61-14K8 (Found in Europe with serial 151811 made in Belgium) - Not in PSB
1976 C-160 8-Speed model 61-16K801
1976 C-160 8-Speed model 61-16K802
1976 C-160 8-Speed model 61-16K803
1976 C-160 8-Speed model 61-16K804
1976 C-160 Automatic model 61-16KS01
1976 C-160 Automatic model 61-16KS02
1976 C-160 Automatic model 61-16KS03
1976 C-160 Automatic model 61-16KS04
1976 C-185 Elec-Trak model 1-0700 - Not in PSB
1976 D-160 Automatic model 61-16OS01
1976 D-160 Automatic model 61-16OS02
1976 D-200 Automatic model 61-20KS01
1976 D-200 Automatic model 61-20KS02
1976 D-250 10-Speed model 61-20RG01
1977 A-60 26" 4-Speed Rear Engine Rider model 73-05BF01
1977 A-65 Elec-Trak model 3-6000 - Not in PSB
1977 A-90 36" 4-Speed Rear Engine Rider model 72-08BP01
1977 A-100 36" 4-Speed Rear Engine Rider model 72-10BP01
1977 B-60 8-Speed model 71-07K801
1977 B-80 8-Speed model 71-08K801
1977 B-100 8-Speed model 71-10K801 (Also made in Belgium)
1977 B-145 Elec-Trak model 1-0720 - Not in PSB
1977 C-80 4-Speed model 71-08K4 (Found in Europe with serials 158039 159837 made in Belgium) - Not in PSB
1977 C-100 8-Speed model 71-10K8 (Found in Europe with serials 155729 155758 made in Belgium)
1977 C-120 8-Speed model 71-12K801
1977 C-120 Automatic model 71-12KS01
1977 C-120 Automatic model 71-12KS02
1977 C-160 8-Speed model 71-16K801
1977 C-160 8-Speed model 71-16K802
1977 C-160 Automatic model 71-16KS01
1977 C-160 Automatic model 71-16KS02
1977 C-185 Elec-Trak model 1-0700 - Not in PSB
1977 D-160 Automatic model 71-16OS01
1977 D-200 Automatic model 71-20KS01
1977 D-250 10-Speed model 61-20RG01
Found in 1978 sales brochure No record @ Toro
1978 A-51 5-speed on attachment list, 6-speed in tractor specs Rear engine rider model 83-05BP01 a guess - Not in PSB
1978 A-81 5-speed on attachment list, 6-speed in tractor specs Rear engine rider model 83-08BP01 a guess - Not in PSB
In 1979 these were 5-speed models
1978 B-81 4-Speed model 82-08BP01
1978 B-111 4-Speed model 82-11BP01
1978 C-81 8-Speed model 81-08K801
1978 C-101 8-Speed model 81-10K801
1978 C-121 8-Speed model 81-12K801(One found made in Belgium)
1978 C-121 Automatic model 81-12KS01
1978 C-141 8-Speed model 81-14K801(Two found made in Belgium)
1978 C-141 Automatic model 81-14KS01
1978 C-161 8-Speed model 81-16K801
1978 C-161 Automatic model 81-16KS01
1978 C-161 Twin 8-Speed model 81-16B801
1978 C-161 Twin Automatic model 81-16BS01
1978 D-160 Automatic model 81-16OS01
1978 D-200 Automatic model 81-20KS01
1978 D-250 10-Speed model 81-20RG01
1978 E-141 8-Speed PSB #226 lists the E-141 as being a 1978 model - Not in PSB
1979 A-51 5-Speed Rear Engine Rider model 93-05BP01
1979 A-51 5-Speed Rear Engine Rider model 93-05BP02
1979 A-81 (E) 5-Speed Rear Engine Rider model 93-08BP01
1979 A-81 (E) 5-Speed Rear Engine Rider model 93-08BP02
1979 A-81 ® 5-Speed Rear Engine Rider model 93-08XP02
1979 A-111 5-Speed Rear Engine Rider model 93-11BP01
1979 B-81 model 92-08BP01 in 1978-79 service manual is likely a mistake - Not in PSB
1979 B-81 6-Speed model 92-08BF01
1979 B-111 4-Speed model 92-11BP01
1979 B-111 6-Speed model 92-11BF01 (Made in USA)
1979 B-111 6-Speed model 91-11BF91 (Made in Belgium with serial 170049) - Not in PSB
1979 B-111 6-Speed model 92-11BF91 (Made in Belgium with serial 178838 & 182588) - Not in PSB
1979 B-111 6-Speed model 92-11BF92 (Made in Belgium with serial 175611) - Not in PSB
1979 C-81 8-Speed model 91-08K801
1979 C-81 8-Speed model 91-08K802
1979 C-81 8-Speed model 91-08K891 (Made in Belgium with serial 163175) - Not in PSB
1979 C-101 8-Speed model 91-10K801
1979 C-101 8-Speed model 91-10K802
1979 C-101 8-Speed model 91-10K892 (Made in Belgium with serial 183695) - Not in PSB
1979 C-111 8-Speed model 91-11B801
1979 C-121 8-Speed model 91-12K801 (Two found made in Belgium)
1979 C-121 8-Speed model 91-12K802
1979 C-121 8-Speed model 91-12K891 (Made in Belgium with serials 167136 169593) - Not in PSB
1979 C-121 8-Speed model 91-12K892 - Belgium built with serial 184568 - Not in PSB
1979 C-121 Automatic model 91-12KS01
1979 C-121 Automatic model 91-12KS91 (Made in Belgium with serial 16?329) - Not in PSB
1979 C-141 8-Speed model 91-14K801
1979 C-141 8-Speed model 91-14K802
1979 C-141 Automatic model 91-14KS01
1979 C-161 8-Speed model 91-16K801
1979 C-161 Automatic model 91-16KS01 (One found in Holland Made in Belgium)
1979 C-161 Twin 8-Speed model 91-16B801
1979 C-161 Twin 8-Speed model 91-16B802
1979 C-161 Twin Automatic model 91-16BS01
1979 C-161 Twin Automatic model 91-16BS02
1979 C-171 A model that was not built - Not in PSB
1979 D-160 Automatic model 91-16OS01
1979 D-160 Automatic model 91-16OS02 - Not listed @ Toro and may be an invalid model number - Not in PSB
1979 D-200 Automatic model 91-20KS01
1979 D-200 Automatic model 91-20KS02
1979 D-250 10-Speed model 91-20RG01
1979 E-141 8-Speed (PSB #226 lists the E-141 as being a 1978 model so possibly a 1979 model also) - Not in PSB
1980 1100 Special model 01-11B803
1980 A-51 5-Speed Rear Engine Rider model 03-05BP01
1980 A-81 (E) 5-Speed Rear Engine Rider model 03-08BP01
1980 A-81 ® 5-Speed Rear Engine Rider model 03-08XP01
1980 A-111 5-Speed Rear Engine Rider model 03-11BP01
1980 B-82 3-Speed model 02-08BP01
1980 B-112 3-Speed model 02-11BX01
1980 B-115 5-Speed model 02-11BP02
1980 B-165 Twin 5-Speed model 02-16BP01
1980 C-85 8-Speed model 01-08K801 Incorrectly named a C-81 @ Toro (One found made in Belgium)
1980 C-85 8-Speed model 01-08K802 (Listed in PSB #276)
1980 C-105 8-Speed model 01-10K801 (One found made in Belgium)
1980 C-125 8-Speed model 01-12K801
1980 C-125 Automatic model 01-12KE01
1980 C-125 Automatic model 01-12KS01
1980 C-145 8-Speed model 01-14K801
1980 C-145 8-Speed model 01-14K891 (Made in Belgium with serial 196489) - Not in PSB
1980 C-145 Automatic model 01-14KE01
1980 C-145 Automatic model 01-14KS01
1980 C-165 8-Speed model 01-16K801
1980 C-165 Automatic model 01-16KE01
1980 C-165 Automatic model 01-16KS01
1980 C-165 Automatic model 01-16KS91 (Made in Belgium with serial 194044) - Not in PSB
1980 C-175 Twin 8-Speed model 01-17K801
1980 C-175 Twin Automatic model 01-17KE01
1980 C-175 Twin Automatic model 01-17KS02
1980 D-160 Automatic model 01-16OS01
1980 D-200 Automatic model 01-20KS00
1980 D-250 10-Speed model 91-20RG01
1980 E-81 5-Speed Rear Engine Rider model 03-08EP01 - Not in PSB
1980 E-141 8-Speed model 01-14E801 - Not in PSB
1981 A-51 5-Speed Rear Engine Rider model 03-05BP02
1981 A-81 (E) 5-Speed Rear Engine Rider model 03-08BP02
1981 A-81 ® 5-Speed Rear Engine Rider model 03-08XP01 Not listed @ Toro
1981 A-111 5-Speed Rear Engine Rider model 03-11BP02
1981 B-82 3-Speed model 02-08BP02
1981 B-82 3-Speed model 02-08BP03
1981 B-112 3-Speed model 02-11BX02
1981 B-112 3-Speed model 02-11BX03
1981 B-115 5-Speed model 02-11BP03
1981 B-115 5-Speed model 02-11BP04
1981 B-165 Twin 5-Speed model 02-16BP02
1981 B-165 Twin 5-Speed model 02-16BP03
1981 C-85 8-Speed model 01-08K802 Incorrectly named a C-81 @ Toro
1981 C-105 8-Speed model 01-10K802
1981 C-125 8-Speed model 01-12K802 (One found made in Belgium)
1981 C-125 Automatic model 01-12KE02
1981 C-145 8-Speed model 01-14K802 - Wrong 30373 spec number listed @ Toro - should be 60373
1981 C-145 Automatic model 01-14KE02 - Wrong 30373 spec number listed @ Toro - should be 60373
1981 C-165 8-Speed model 01-16K802
1981 C-165 Automatic model 01-16KE02
1981 C-175 Twin 8-Speed model 01-17K802
1981 C-175 Twin Automatic model 01-17KE01
1981 D-160 Automatic model 01-16OS01 Not listed @ Toro
1981 D-200 Automatic model 01-20KS00
1981 D-250 10-Speed model 91-20RG01
1981 E-81 5-Speed Rear Engine Rider model 03-08EP01 - Not in PSB
1981 E-141 8-Speed model 01-14E801 - Not in PSB
1981 GT-2500 8-Speed model 01-11B804
1982 A-51 5-Speed Rear Engine Rider model 23-05BP01
1982 A-81 5-Speed Rear Engine Rider model 23-08BP01
1982 A-111 5-Speed Rear Engine Rider model 23-11BP01
1982 A-111 5-Speed Rear Engine Rider model 23-11BX01
1982 B-85 5-Speed model 02-08BX01
1982 B-115 5-Speed model 02-11BP05
1982 B-115 Automatic model 02-11BE01
1982 B-165 Twin 5-Speed model 02-16BP04
1982 B-165 Twin Automatic model 02-16BE01
1982 C-85 8-Speed model 01-08K803
1982 C-105 8-Speed model 01-10K803
1982 C-125 8-Speed model 01-12K803
1982 C-145 Automatic model 01-14KE03
1982 C-175 Twin 8-Speed model 01-17K803
1982 C-175 Twin Automatic model 01-17KE02
1982 C-195 Twin Automatic model 01-19KE01
1982 D-160 Automatic model 01-16OS01 - Not listed @ Toro
1982 E-81 5-Speed Rear Engine Rider model 03-08EP01 - Not in PSB
1982 E-141 8-Speed model 01-14E801 - Not in PSB
1982 GT-1142 8-Speed model A1-114201
1982 GT-1642 Twin 8-Speed model A1-164201
1982 GT-1848 Twin Automatic model A1-184801
1982 LT-832 3-Speed model A2-083201
1982 LT-1032 3-Speed model A2-103201
1982 LT-1137 5-Speed model A2-113701
1982 LT-1637 Twin 5-Speed model A2-163701
1982 LT-1642 Twin 5-Speed model A2-164201
1982 RR-532 5-Speed Rear Engine Rider model A3-053201
1982 RR-832 5-Speed Rear Engine Rider model A3-083201
1982 SB-371 3-Speed model 02-11BH01
1982 SB-421 8-Speed model 01-11BH01
1982 SK-486 8-Speed model 01-16KH01
1983 A- 81 5-Speed Rear Engine Rider model 03-08BP03
1983 A- 81 5-Speed Rear Engine Rider model 23-08BP02
1983 A- 81 5-Speed Rear Engine Rider model 23-08BX01
1983 A- 81 5-Speed Rear Engine Rider model 23-08XP01
1983 A-111 5-Speed Rear Engine Rider model 23-11BP02
1983 B-85 5-Speed model 02-08BX01 - Also 1982 model
1983 B-115 Automatic model 12-11BE01
1983 B-115 5-Speed model 12-11BP01
1983 B-165 Twin Automatic model 12-16BE01
1983 B-165 Twin 5-Speed model 12-16BP01
1983 C- 85 8-Speed model 11-08K801
1983 C-105 8-Speed model 11-10K801
1983 C-125 8-Speed model 11-12K801
1983 C-145 Automatic model 01-14KE04
1983 C-175 Twin 8-Speed model 11-17K801
1983 C-175 Twin Automatic model 01-17KE03
1983 C-195 Twin Auto model 01-19KE01 - Not listed @ Toro for 1983, 1982 only
1983 E- 81 5-Speed Rear Engine Rider model 03-08EP01 - Not in PSB
1983 E-141 8-Speed model 01-14E801 - Not in PSB
1983 GT-1142 8-Speed model A1-114202
1983 GT-1642 Twin 8-Speed model A1-164202
1983 GT-1848 Twin Automatic model D1-184801
1983 LT- 832 3-Speed model A2-083202
1983 LT-1136 3-Speed model D2-113601
1983 LT-1137 3-Speed model D2-113701
1983 LT-1637 Twin 3-Speed model D2-163701
1984 A-81 5-Speed Rear Engine Rider model 23-08BP03
1984 A-81 5-Speed Rear Engine Rider model 23-08BX01
1984 A-85 5-Speed Rear Engine Rider model 33-08BP01 - 1985 @ Toro - 1984 model in PSB 228j
1984 A-111 5-Speed Rear Engine Rider model 23-11BP03
1984 A-115 5-Speed Rear Engine Rider model 33-11BP01- 1985 @ Toro - 1984 model in PSB 228j
1984 B-115 5-Speed model 12-11BP02
1984 B-165 Twin Automatic model 12-16BE02
1984 B-1136 model B2-11BX91
1984 C-105 8-Speed model 11-10K802
1984 C-125 8-Speed model 11-12K802
1984 C-145 Automatic model 11-14KE01
1984 C-165 8-Speed model 11-16K801
1984 C-175 Twin Automatic model 11-17KE01
1984 C-195 Twin Automatic model 01-19KE02
1984 GT-1100 8-Speed model A1-11B801
1984 GT-1600 Twin 8-Speed model A1-16B801
1984 GT-1800 Twin Automatic model A1-18BE01
1984 LT-1100 5-Speed model A2-11BP01
1984 LT-1100 3-Speed model A2-11BX01
1984 LT-1600 Twin 5-Speed model A2-16BP01
191 downloads
Updated
-
Free
Toro91-presGT #GT15 44in 2-stage Snowthrower 1995.pdf
By admin-(Admin)
2 pages 90.91KB
Dated December 15, 1994
Snowthrower 1990 44in model 06-44SC01 - Not in PSB but may apply
Snowthrower 1991 44in model 06-44SC01 Serial 1000001-1999999 - Not in PSB but may apply
Snowthrower 1992 44in model 06-44SC01 Serial 2000001-2999999 - Not in PSB but may apply
Snowthrower 1993 44in model 79361 Serial 3900001-3999999
Snowthrower 1994 44in model 79361 Serial 4900001-4999999
Snowthrower 1995 44in model 79361 Serial 5900001-5999999
75 downloads
Updated
-
Free
WH61-90 #413 Clutch Idler Damper 1988-on.pdf
By admin-(Admin)
2 pages 150.70KB
Adjustment procedure
Clutch idler damper 1988-on
Dated September 1987 for 1988 models - first year to have them
Also called a dampener
1988 312-8 model 21-12K805
1988 414-8 model 31-14K803
1988 416-8 model 31-16K804
1989 310-8 model 21-10K806
1989 312-8 model 21-12K806
1989 414-8 model 31-14K804
1989 416-8 model 31-16O801
1990 310-8 model 31-10K801
1990 312-8 model 31-12K801
1990 416-8 model 31-16O802
1990 520-8 model 41-20O801
84 downloads
Updated
-
Free
WH61-90 #417 50in Grader Blade Lift link.pdf
By admin-(Admin)
2 pages 82.38KB
Dated January 1988
Lift link 113160 replaced by 92-0983-01 - 1-3/16" offset
Blade Grader 1986 50in model 07-50BM02
Blade Grader 1987 50in model 07-50BM02
Blade Grader 1988 50in model 07-50BM02
Blade Grader 1989 50in model 07-50BM02
92 downloads
Updated
-
Free
Toro91-presGT #GT21 48in Dozer Blade Index Lever 1996.pdf
By admin-(Admin)
1 page 86.22KB
Dated November 1996
New right footrest 94-3521
New right footrest mat 94-3710
1996 314-H model 73401 Serial 6900001-6999999 - Not in PSB?
1996 314-H model 73403 Serial 6900001-6999999
1996 416-H model 73421 Serial 6900001-6999999 - Not in PSB?
1996 416-H model 73423 Serial 6900001-6999999
1996 520-H model 73501 Serial 69000001-69999999 - Not in PSB?
1996 520-H model 73502 Serial 6900001-6999999 - Not in PSB?
1996 520-He model 73521 Serial 6900001-6999999 - Export model
Dozer 1993 48in model 79350 Serial 3900001-3999999
Dozer 1994 48in model 79350 Serial 4900001-4999999
Dozer 1995 48in model 79350 Serial 5900001-5999999
Dozer 1996 48in model 79350 Serial 6900001-6999999
Dozer 1997 48in model 79350 Serial 7900001-7999999
Dozer 1998 48in model 79350 Serial 8900001-8999999 - Not in PSB?
Dozer 1999 48in model 79350 Serial 9900001-9999999 - Not in PSB?
Dozer 2000 48in model 79350 Serial 200000001-200999999 - Not in PSB?
Dozer 2001 48in model 79350 Serial 210000001-210999999 - Not in PSB?
58 downloads
Updated
-
Free
WH61-90 #026 Engineering Changes 1962 Orig.pdf
By admin-(Admin)
1 page 245.31KB
1 page 95.21KB
Dated November 29, 1961
1962 model 32E Lawn Ranger
1962 model 32R Lawn Ranger
Steering stop / turning stop 4447 added to 3919 arm
1962 model 502
Hood gets a 4443 plastic strip added to the left side
1962 model 552
1962 model 702
Lift Hydraulic 1962 model HY-2
Lift Hydraulic 1963 model HY-2
Straight gear shift lever 4215 replaced by 4440 to clear the hydraulic pump. (4440 replaced by 95-7684 which was also used in the 2007 315-8 high-low transmission)
Lower lift lever plunger 4243 replaced by 4438
Lift plunger rod 3987 replaced by 4439
Blade Dozer 1962 42in model BD-4262
Left inside spring retainer 2140
Left spring hook assembly 2144
Right inside spring retainer 2133
Right spring hook assembly 2145
73 downloads
Updated
-
Free
WH61-90 #403a 3amp Unregulated Charging System 300-Series 400-Series.pdf
By admin-(Admin)
1 page 91.80KB
Dated March 1987 Revised May 1987
1985 310-8 model 21-10K801 - K241 engine
1985 312-8 model 21-12K801 - K301 engine
1985 314-8 model 21-14K801 - K321 engine
1985 314-A model 21-14KE01- K321 engine
1985 416-8 model 31-16K801 - K341 engine
1986 310-8 model 21-10K802 - K241 engine
1986 310-8 model 21-10K803 - K241 engine
1986 312-8 model 21-12K802 - K301 engine
1986 312-8 model 21-12K803 - K301 engine
1986 312-A model 21-12KE01 - K301 engine
1986 312-A model 21-12KE02 - K301 engine
1986 414-8 model 31-14K801 - K321 engine
1987 310-8 model 21-10K804 - M10 engine
1987 414-8 model 31-14K802 - M14 engine
3 amp
overcharging
high voltage
Part # 113332 no longer available from Toro (May 23, 2022)
107 downloads
Updated
-
Free
WH61-90 #376 C-Series 1978-84 Replacement Kohler Engines.pdf
By gwest_ca-(File Mod)
1 page 91.18KB
Dated December 1984
10hp K241AS Spec 46766, 46805 and 46812
12hp K301AS Spec 47648, 47723 and 47742
14hp K321AS Spec 60322, 60562 and 60373
16hp K341AS Spec 71246, 71303 and 71311
1978
1978 C-101 8-Speed model 81-10K801 - K241AS-46766
1978 C-121 8-Speed model 81-12K801
1978 C-121 Automatic model 81-12KS01
1978 C-141 8-Speed model 81-14K801
1978 C-141 Automatic model 81-14KS01
1978 C-161 8-Speed model 81-16K801
1978 C-161 Automatic model 81-16KS01
1979
1979 C-101 8-Speed model 91-10K801 - K241AS-46766
1979 C-101 8-Speed model 91-10K802 - K241AS-46766
1979 C-101 8-Speed model 91-10K892
1979 C-121 8-Speed model 91-12K801
1979 C-121 8-Speed model 91-12K802
1979 C-121 8-Speed model 91-12K891
1979 C-121 8-Speed model 91-12K892
1979 C-121 Automatic model 91-12KS01
1979 C-121 Automatic model 91-12KS91
1979 C-141 8-Speed model 91-14K801
1979 C-141 8-Speed model 91-14K802
1979 C-141 Automatic model 91-14KS01
1979 C-161 8-Speed model 91-16K801
1979 C-161 Automatic model 91-16KS01
1980
1980 C-105 8-Speed model 01-10K801 - K241AS-46805
1980 C-125 8-Speed model 01-12K801
1980 C-125 Automatic model 01-12KE01
1980 C-125 Automatic model 01-12KS01
1980 C-145 8-Speed model 01-14K801
1980 C-145 8-Speed model 01-14K891
1980 C-145 Automatic model 01-14KE01
1980 C-145 Automatic model 01-14KS01
1980 C-165 8-Speed model 01-16K801
1980 C-165 Automatic model 01-16KE01
1980 C-165 Automatic model 01-16KS01
1980 C-165 Automatic model 01-16KS91
1981
1981 C-105 8-Speed model 01-10K802 - K241AS-46812d
1981 C-125 8-Speed model 01-12K802
1981 C-125 Automatic model 01-12KE02
1981 C-145 8-Speed model 01-14K802
1981 C-145 Automatic model 01-14KE02
1981 C-165 8-Speed model 01-16K802
1981 C-165 Automatic model 01-16KE02
1982
1982 C-105 8-Speed model 01-10K803 - K241AS-46812d
1982 C-125 8-Speed model 01-12K803
1982 C-145 Automatic model 01-14KE03
1983
1983 C-105 8-Speed model 11-10K801 - K241AS-46812
1983 C-125 8-Speed model 11-12K801
1983 C-145 Automatic model 01-14KE04
1984
1984 C-105 8-Speed model 11-10K802 - K241AS-46812
1984 C-125 8-Speed model 11-12K802
1984 C-145 Automatic model 11-14KE01
1984 C-165 8-Speed model 11-16K801
77 downloads
Updated
-
Free
WH61-90 #246 Engine Cross Reference 1979.pdf
By admin-(Admin)
1 page 93.26KB
Includes ignition switches and charging systems
1979 A-51 5-Speed Rear Engine Rider model 93-05BP01
1979 A-51 5-Speed Rear Engine Rider model 93-05BP02
1979 A-81 (E) 5-Speed Rear Engine Rider model 93-08BP01
1979 A-81 (E) 5-Speed Rear Engine Rider model 93-08BP02
1979 A-81 ® 5-Speed Rear Engine Rider model 93-08XP02
1979 A-111 5-Speed Rear Engine Rider model 93-11BP01
1979 B-81 model 92-08BP01 in 1978-79 service manual is likely a mistake
1979 B-81 6-Speed model 92-08BF01
1979 B-111 4-Speed model 92-11BP01
1979 B-111 6-Speed model 92-11BF01
1979 B-111 6-Speed model 91-11BF91
1979 B-111 6-Speed model 92-11BF91
1979 B-111 6-Speed model 92-11BF92
1979 C-81 8-Speed model 91-08K801
1979 C-81 8-Speed model 91-08K802
1979 C-81 8-Speed model 91-08K891
1979 C-101 8-Speed model 91-10K801
1979 C-101 8-Speed model 91-10K802
1979 C-101 8-Speed model 91-10K892
1979 C-111 8-Speed model 91-11B801
1979 C-121 8-Speed model 91-12K801
1979 C-121 8-Speed model 91-12K802
1979 C-121 8-Speed model 91-12K891
1979 C-121 8-Speed model 91-12K892
1979 C-121 Automatic model 91-12KS01
1979 C-121 Automatic model 91-12KS91
1979 C-141 8-Speed model 91-14K801
1979 C-141 8-Speed model 91-14K802
1979 C-141 Automatic model 91-14KS01
1979 C-161 8-Speed model 91-16K801
1979 C-161 Automatic model 91-16KS01
1979 C-161 Twin 8-Speed model 91-16B801
1979 C-161 Twin 8-Speed model 91-16B802
1979 C-161 Twin Automatic model 91-16BS01
1979 C-161 Twin Automatic model 91-16BS02
1979 C-171 Twin 8-Speed Kohler powered model that was not built
1979 C-171 Twin Automatic Kohler powered model that was not built
1979 D-160 Automatic model 91-16OS01
1979 D-160 Automatic model 91-16OS02 - Not listed @ Toro and may be an invalid model number
1979 D-200 Automatic model 91-20KS01
1979 D-200 Automatic model 91-20KS02
1979 D-250 10-Speed model 91-20RG01
48 downloads
Updated
-
Free
WH61-90 #451 Kill relay replacement.pdf
By admin-(Admin)
2 pages 110.95KB
Dated September 1991
Last service bulletin in this WH61-90 series
Original 106833 3-terminal relay replaced by a 5-terminal on some models because of a parts shortage.
Service assembly 121378 at the time was replaced by 99-5365 kit which included a 48-4700 relay.
The 48-4700 relay has been replaced by 116397
Current part 99-5365 still available from Toro December 26, 2016
1978 C-161 Twin 8-Speed model 81-16B801
1978 C-161 Twin Automatic model 81-16BS01
1979 C-111 8-Speed model 91-11B801 - Typo in PSB 01-11BH81
1979 C-161 Twin 8-Speed model 91-16B801
1979 C-161 Twin 8-Speed model 91-16B802
1979 C-161 Twin Automatic model 91-16BS01
1979 C-161 Twin Automatic model 91-16BS02
1980 B-82 3-Speed model 02-08BP01
1980 B-112 3-Speed model 02-11BX01
1980 B-115 5-Speed model 02-11BP02
1980 B-165 Twin 5-Speed model 02-16BP01
1980 1100 Special model 01-11B803
1981 B-82 3-Speed model 02-08BP02
1981 B-82 3-Speed model 02-08BP03
1981 B-112 3-Speed model 02-11BX02
1981 B-112 3-Speed model 02-11BX03
1981 B-115 5-Speed model 02-11BP03
1981 B-115 5-Speed model 02-11BP04
1981 B-165 Twin 5-Speed model 02-16BP02
1981 B-165 Twin 5-Speed model 02-16BP03
1981 GT-2500 8-Speed model 01-11B804
1982 SB-371 3-Speed model 02-11BH01
1982 SB-421 8-Speed model 01-11BH01
131 downloads
Updated
-
Free
WH61-90 #334 Mower leveling Cables A, B, LT & RR-Series.pdf
By gwest_ca-(File Mod)
2 pages 87.97KB ---- Note - 2nd page is blank
Dated July 1982
106472 cable 37.37" long + or - .120"
05-36XR01, 36" Rear Discharge Mower, 1982
05-36XR02, 36" Rear Discharge Mower, 1983
05-36XR03, 36" Rear Discharge Mower, 1985
05-36XR04, 36" Rear Discharge Mower, 1985
05-36XS01, 36" Side Discharge Mower, 1980
05-36XS01, 36" Side Discharge Mower, 1981
05-37MS02, 37" Side Discharge Mower, 1983
05-37MS03, 37" Side Discharge Mower, 1984
05-37MS04, 37" Side Discharge Mower, 1985
05-37MS05, 37" Side Discharge Mower, 1985
05-42SB01, 42" Side Discharge Mower, 1982
05-42SB01, 42" Side Discharge Mower, 1983
05-42SB02, 42" Side Discharge Mower, 1984
05-42SB03, 42" Side Discharge Mower, 1985
05-42SB04, 42" Side Discharge Mower, 1985
05-42XR01, 42" Rear Discharge Mower, 1980
05-42XR01, 42" Rear Discharge Mower, 1981
05-42XR02, 42" Rear Discharge Mower, 1982
05-42XR02, 42" Rear Discharge Mower, 1983
05-42XR03, 42" Rear Discharge Mower, 1984
05-42XR04, 42" Rear Discharge Mower, 1985
05-42XR05, 42" Rear Discharge Mower, 1985
85-36XR01, 36" Rear Discharge Mower, 1978
85-36XS01, 36" Side Discharge Mower, 1978
85-42XR01, 42" Rear Discharge Mower, 1978
95-36XR00, 36" Rear Discharge Mower, 1979
95-36XR01, 36" Rear Discharge Mower, 1979
95-36XS00, 36" Side Discharge Mower, 1979
95-36XS01, 36" Side Discharge Mower, 1979
95-42XR01, 42" Rear Discharge Mower, 1979
95-42XR02, 42" Rear Discharge Mower, 1979
A2-083201, LT-832 3-Speed Tractor, 1982
A2-103201, LT-1032 3-Speed Tractor, 1982
A2-113701, LT-1137 5-Speed Tractor, 1982
A2-163701, LT-1637 Twin 5-Speed Tractor, 1982
A2-164201, LT-1642 Twin 5-Speed Tractor, 1982
A5-36XR02, 36" Rear Discharge Mower, 1983
A5-37MS02, 37" Side Discharge Mower, 1983
B5-36XR01, 36" Rear Discharge Mower, 1983
B5-42XR01, 42" Rear Discharge Mower, 1983
108179 cable 38" long + or - .120"
05-32SB05, 32" Side Discharge Mower, 1985
05-32SB06, 32" Side Discharge Mower, 1986
05-32YS01, 32" Side Discharge Mower, 1981
05-32YS01, 32" Side Discharge Mower, 1982
05-36XR04, 36" Rear Discharge Mower, 1985
05-36XR05, 36" Rear Discharge Mower, 1986
05-37MS01, 37" Side Discharge Mower, 1981
05-37MS01, 37" Side Discharge Mower, 1982
05-37MS05, 37" Side Discharge Mower, 1985
05-37MS06, 37" Side Discharge Mower, 1986
05-37SK01, 37" Side Discharge Mower, 1989
05-42RK01, 42" Rear Discharge Mower, 1988
05-42SB04, 42" Side Discharge Mower, 1985
05-42SB05, 42" Side Discharge Mower, 1986
05-42SK01, 42" Side Discharge Mower, 1988
05-42XR05, 42" Rear Discharge Mower, 1985
05-42XR06, 42" Rear Discharge Mower, 1986
A2-083201, LT-832 3-Speed Tractor, 1982
A2-103201, LT-1032 3-Speed Tractor, 1982
A2-113701, LT-1137 5-Speed Tractor, 1982
A2-163701, LT-1637 Twin 5-Speed Tractor, 1982
A2-164201, LT-1642 Twin 5-Speed Tractor, 1982
E5-36XR01, 36" Rear Discharge Mower, 1988
E5-42XR01, 42" Rear Discharge Mower, 1988
108554 cable 36.37" long + or - .120"
03-08BP03, A-81 5-Speed Rear Engine Rider, 1983
05-32MS01, 32" Side Discharge Mower, 1980
05-32MS01, 32" Side Discharge Mower, 1981
05-32SB05, 32" Side Discharge Mower, 1985
05-32SB06, 32" Side Discharge Mower, 1986
05-32XS01, 32" Side Discharge Mower, 1980
05-32XS02, 32" Side Discharge Mower, 1981
05-36XR04, 36" Rear Discharge Mower, 1985
05-36XR05, 36" Rear Discharge Mower, 1986
05-36YR01, 36" Rear Discharge Mower, 1980
05-36YR01, 36" Rear Discharge Mower, 1981
05-37MS05, 37" Side Discharge Mower, 1985
05-37MS06, 37" Side Discharge Mower, 1986
05-42SB04, 42" Side Discharge Mower, 1985
05-42SB05, 42" Side Discharge Mower, 1986
05-42XR05, 42" Rear Discharge Mower, 1985
05-42XR06, 42" Rear Discharge Mower, 1986
23-05BP01, A-51 5-Speed Rear Engine Rider, 1982
23-08BP01, A-81 5-Speed Rear Engine Rider, 1982
23-08BP02, A-81 5-Speed Rear Engine Rider, 1983
23-08BX01, A-81 5-Speed Rear Engine Rider, 1983
23-08XP01, A-81 5-Speed Rear Engine Rider, 1983
23-11BP01, A-111 5-Speed Rear Engine Rider, 1982
23-11BP02, A-111 5-Speed Rear Engine Rider, 1983
23-11BX01, A-111 5-Speed Rear Engine Rider, 1982
A2-083201, LT-832 3-Speed Tractor, 1982
A2-103201, LT-1032 3-Speed Tractor, 1982
A2-113701, LT-1137 5-Speed Tractor, 1982
A2-163701, LT-1637 Twin 5-Speed Tractor, 1982
A2-164201, LT-1642 Twin 5-Speed Tractor, 1982
109273 cable 35.69" long + or -.120"
05-32SB03, 32" Side Discharge Mower, 1984
05-32SB04, 32" Side Discharge Mower, 1985
05-36XR03, 36" Rear Discharge Mower, 1985
05-37MS03, 37" Side Discharge Mower, 1984
05-37MS04, 37" Side Discharge Mower, 1985
05-42SB01, 42" Side Discharge Mower, 1982
05-42SB01, 42" Side Discharge Mower, 1983
05-42SB02, 42" Side Discharge Mower, 1984
05-42SB03, 42" Side Discharge Mower, 1985
05-42XR02, 42" Rear Discharge Mower, 1982
05-42XR02, 42" Rear Discharge Mower, 1983
05-42XR03, 42" Rear Discharge Mower, 1984
05-42XR04, 42" Rear Discharge Mower, 1985
A5-32SB02, 32" Side Discharge Mower, 1983
B5-42XR01, 42" Rear Discharge Mower, 1983
E5-42XR02, 42" Rear Discharge Mower, 1991 (SN 1000001-1999999)
109449 cable 37.12" long + or -.120"
03-08BP03, A-81 5-Speed Rear Engine Rider, 1983
23-05BP01, A-51 5-Speed Rear Engine Rider, 1982
23-08BP01, A-81 5-Speed Rear Engine Rider, 1982
23-08BP02, A-81 5-Speed Rear Engine Rider, 1983
23-08BP03, A-81 5-Speed Rear Engine Rider, 1984
23-08BX01, A-81 5-Speed Rear Engine Rider, 1983
23-08XP01, A-81 5-Speed Rear Engine Rider, 1983
23-11BP01, A-111 5-Speed Rear Engine Rider, 1982
23-11BP02, A-111 5-Speed Rear Engine Rider, 1983
23-11BP03, A-111 5-Speed Rear Engine Rider, 1984
23-11BX01, A-111 5-Speed Rear Engine Rider, 1982
A3-053201, RR-532 5-Speed Rear Engine Rider, 1982
A3-083201, RR-832 5-Speed Rear Engine Rider, 1982
94 downloads
Updated
-
Free
WH61-90 #225 Identifying 1963-1978 Steering Tie Rods.pdf
By admin-(Admin)
Product service bulletin
2 pages 97.55KB
Tie rod 1772 1773
1963 model 33E Lawn Ranger
1963 model 33R Lawn Ranger
1963 model 603 Tractor
1963 model 633 Tractor
1963 model 653 Tractor
1963 model 753 Tractor
1964 model 34E Lawn Ranger
1964 model 34R Lawn Ranger
1964 model 604 Tractor
1964 model 654 Tractor
1964 model 704 Tractor
1964 model 754 Tractor - missed @ Toro
1964 model 854 Tractor
1965 Lawn Ranger model L-105
1965 Lawn Ranger model L-155
1966 Lawn Ranger model L-106
1966 Lawn Ranger model L-156
1967 Lawn Ranger model L-107
1967 Lawn Ranger model L-157
1968 Lawn Ranger model 1-1631
1968 Lawn Ranger model 1-2631
1969 model 1-4741 Commando V7
1969 model 1-4841 Commando V8
1969 model 1-7741 Charger V7
1969 model 1-7841 Charger V8
1970 Commando V7 model 1-4751 - (1-6751 wrong on PSB)
1970 Commando V7 model 1-4752
1970 Charger V7 model 1-7751
1970 Commando V8 model 1-4851
1970 Commando V8 model 1-4852
1970 Charger V8 model 1-7851
1971 CG-7 model 1-0275 - (1-02200 wrong on PSB)
1971 CG-7R model 1-0270
1971 CG-8 model 1-0200
1972 CG-7 3-Speed model 1-0275 - (1-02757 wrong on PSB [1-0275-7 would be correct])
1972 CG-7R 3-Speed model 1-0270
1972 CG-8 Auto model 1-0200 - (8hp 4-speed wrong on PSB)
1972 CG-8 Auto model 1-0201 - (8hp 4-speed wrong on PSB)
1972 CG-8 model 1-7752 - (1-0752 & 8hp 4-speed wrong on PSB)
1974 A-800 Ranger model 1-0280
1974 A-800 Ranger model 1-0285
1975 A-80 Ranger model 1-0281
1975 A-80 Ranger model 1-0282 - (Not on PSB)
1975 A-80 Ranger model 1-0286
1975 A-80 Ranger model 1-0287 - (Not on PSB)
1976 A-90 36" 4-Speed model 62-08BP01
1976 A-100 36" 4-Speed model 62-10BP01 - (62-10BR01 on PSB)
1977 A-90 36" 4-Speed model 72-08BP01
1977 A-100 36" 4-Speed model 72-10BP01
1978 B-81 4-Speed model 82-08BP01
1978 B-111 4-Speed model 82-11BP01
124 downloads
Updated
-
Free
Toro91-presGT #GT30 5xi Cruise Control with Vac Bagger.pdf
By gwest_ca-(File Mod)
1 page 108.93KB
Dated May 14, 1998
1998 520xi model 73540 Serial 8900001-8999999
1998 520xi model 73541 Serial 8900001-8999999 - Export model
1998 522xi model 73560 Serial 8900001-8999999
1998 520Lxi model 73545 Serial 8900001-89999999
1998 520Lxi model 73546 Serial 8900001-8999999 - Export model
1998 523Dxi model 73550 Serial 8900001-8999999
1998 523Dxi model 73551 Serial 8900001-8999999 - Export model
Mower Rotary 1998 44in SD model 79305 Vacuum Serial 8900001-8999999
Mower Rotary 1999 44in SD model 79305 Vacuum Serial 9900001-9999999
Mower Rotary 1998 48in SD model 79310 Vacuum Serial 8900001-8999999
Mower Rotary 1999 48in SD model 79310 Vacuum Serial 9900001-9999999
Mower Rotary 2001 48in SD model 79310 Vacuum Serial 210000001-210999999
Mower Rotary 2003 48in SD model 79310 Vacuum Serial 230000001-230999999
Mower Rotary 2004 48in SD model 79310 Vacuum Serial 240000001-240999999
Mower Rotary 2006 48in SD model 79310 Vacuum Serial 260000001-260999999
Mower Rotary 1998 48in SD model 79448 Vacuum Serial 8900001-8999999 - Export model
Mower Rotary 1999 48in SD model 79448 Vacuum Serial 9900001-9999999 - Export model
46 downloads
Updated
-
Free
WH61-90 #396 1978-84 Electric Lift Kit C-Series Style Frame.pdf
By gwest_ca-(File Mod)
15 pages
Dated July 1986
Wiring from 1986 service manual Color pdf
1 page 230KB
Lift Electric model 8-4223 - 84223 @ Toro
Replaced by 8-4224 (84224)
1978 C-81 8-Speed model 81-08K801
1978 C-101 8-Speed model 81-10K801
1978 C-121 8-Speed model 81-12K801
1978 C-141 8-Speed model 81-14K801
1978 C-161 8-Speed model 81-16K801
1978 C-161 Twin 8-Speed model 81-16B801
1979 C-81 8-Speed model 91-08K801
1979 C-81 8-Speed model 91-08K802
1979 C-81 8-Speed model 91-08K891
1979 C-101 8-Speed model 91-10K801
1979 C-101 8-Speed model 91-10K802
1979 C-101 8-Speed model 91-10K892
1979 C-111 8-Speed model 91-11B801
1979 C-121 8-Speed model 91-12K801
1979 C-121 8-Speed model 91-12K802
1979 C-121 8-Speed model 91-12K891
1979 C-121 8-Speed model 91-12K892
1979 C-141 8-Speed model 91-14K801
1979 C-141 8-Speed model 91-14K802
1979 C-161 8-Speed model 91-16K801
1979 C-161 Twin 8-Speed model 91-16B801
1979 C-161 Twin 8-Speed model 91-16B802
1980 1100 Special model 01-11B803
1980 C-85 8-Speed model 01-08K801
1980 C-85 8-Speed model 01-08K802 (Listed in PSB #276)
1980 C-105 8-Speed model 01-10K801
1980 C-125 8-Speed model 01-12K801
1980 C-145 8-Speed model 01-14K801
1980 C-145 8-Speed model 01-14K891
1980 C-165 8-Speed model 01-16K801
1980 C-175 Twin 8-Speed model 01-17K801 - Not in PSB?
1981 C-85 8-Speed model 01-08K802
1981 C-105 8-Speed model 01-10K802
1981 C-125 8-Speed model 01-12K802
1981 C-145 8-Speed model 01-14K802
1981 C-165 8-Speed model 01-16K802
1981 C-175 Twin 8-Speed model 01-17K802 - Not in PSB?
1981 GT-2500 8-Speed model 01-11B804
1982 C-85 8-Speed model 01-08K803
1982 C-105 8-Speed model 01-10K803
1982 C-125 8-Speed model 01-12K803
1982 C-175 Twin 8-Speed model 01-17K803
1982 SB-421 8-Speed model 01-11BH01
1982 SK-486 8-Speed model 01-16KH01
1982 GT-1142 8-Speed model A1-114201
1982 GT-1642 Twin 8-Speed model A1-164201
1983 C- 85 8-Speed model 11-08K801
1983 C-105 8-Speed model 11-10K801
1983 C-125 8-Speed model 11-12K801
1983 C-175 Twin 8-Speed model 11-17K801
1983 GT-1142 8-Speed model A1-114202
1983 GT-1642 Twin 8-Speed model A1-164202
1984 C-105 8-Speed model 11-10K802
1984 C-125 8-Speed model 11-12K802
1984 C-165 8-Speed model 11-16K801
1984 GT-1100 8-Speed model A1-11B801
1984 GT-1600 Twin 8-Speed model A1-16B801
178 downloads
Updated
-
Free
Toro91-presLT #LT51 Front Wheel Bearing Grease XL-Series.pdf
By admin-(Admin)
1 page 85.73KB
Dated April 3, 2000
Last service bulletin in this Toro91-presLT series
Last PSB in this Toro91-presLT series
2000 17-44HXL model 71197 Serial 200000101-200001536
2000 12-32XL model 71199 Serial 200000101-200001620
2000 16-38XL model 71223 Serial 200000101-200002127
2000 16-38HXL model 71225 Serial 200000101-200005526
2000 16-38G model 77102 Serial 200000101-200000176
2000 16-38H model 77104 Serial 200000101-200000175
2000 17-44H model 77106 Serial 200000101-200000150
46 downloads
Updated
-
Free
WH61-90 #391 Metric Spindle Grease Lock
By tunahead72
2 pages 103.50KB
Dated July 1986
Addresses the problem of mower spindles not accepting grease due to spindle shaft blocking grease hole in spindle spacer.
Mower Rotary 1983 36in RD model 05-36XR02
Mower Rotary 1984 36in RD model 05-36XR02
Mower Rotary 1984 36in SD model 05-36MS02
Mower Rotary 1985 36in RD model 05-36XR03 - Missed in PSB?
Mower Rotary 1985 36in RD model 05-36XR04 - (Typo 05-36XR05)
Mower Rotary 1985 42in RD model 05-42MR03
Mower Rotary 1985 42in RD model 05-42XR04
Mower Rotary 1985 42in RD model 05-42XR05
Mower Rotary 1985 42in SD model 05-42MS04
Mower Rotary 1985 42in SD model 05-42SB03 - (Typo 05-42BS03)
Mower Rotary 1985 42in SD model 05-42SB04
Mower Rotary 1985 48in SD model 05-48MS04
Mower Rotary 1986 36in RD model 05-36MR04
Mower Rotary 1986 36in RD model 05-36RL01
Mower Rotary 1986 36in RD model 05-36XR05
Mower Rotary 1986 42in RD model 05-42MR04
Mower Rotary 1986 42in RD model 05-42XR06
Mower Rotary 1986 42in SD model 05-42MS05
Mower Rotary 1986 42in SD model 05-42SB05
Mower Rotary 1986 48in SD model 05-48MS05
Mower Rotary 1987 36in RD model 05-36MR04
Mower Rotary 1987 36in RD model 05-36RL01
Mower Rotary 1987 42in RD model 05-42MR04
Mower Rotary 1987 42in SD model 05-42MS05
Mower Rotary 1987 48in SD model 05-48MS05
Mower Rotary 1988 36in RD model 05-36MR04
Mower Rotary 1988 42in RD model 05-42MR04
Mower Rotary 1988 42in SD model 05-42MS05
Mower Rotary 1988 48in SD model 05-48MS05
Mower Rotary 1989 36in RD model 05-36MR04
Mower Rotary 1990 36in RD model 05-36MR04
129 downloads
Updated
-
Free
Toro91-presLT #LT33 Electrical System 260-Series.pdf
By admin-(Admin)
1 page 85.39KB
Dated June 19, 1995
1994 264-6 model 72042 Serial 4900001-4999999
1994 264-6 model 72062 Serial 4900001-4999999 - Export model 264-6e
1994 264-H model 72043 Serial 4900001-4999999
1994 264-H model 72063 Serial 4900001-4999999 - Export model 264-He
1994 266-H model 72083 Serial 4900001-4999999
1994 268-H model 72103 Serial 4900001-4999999 - Export model 268-He
--------------------------------------------------------------------------------------------------
1995 264-6 model 72042 Serial 5900001-5900796
1995 264-6 model 72042 Serial 5900797-5999999
1995 264-6 model 72062 Serial 5900001-5900227 - Export model 264-6e
1995 264-6 model 72062 Serial 5900228-5999999 - Export model 264-6e
1995 264-H model 72043 Serial 5900001-5901475
1995 264-H model 72043 Serial 5901476-5999999
1995 264-H model 72063 Serial 5900001-5900498 - Export model 264-He
1995 264-H model 72063 Serial 5900499-5999999 - Export model 264-He
1995 266-H model 72084 Serial 5900001-5999999
1995 268-H model 72103 Serial 5900001-5900600 - Export model 268-He
1995 268-H model 72103 Serial 5900601-5999999 - Export model 268-He
47 downloads
Updated
-
Free
WH61-90 #340 37in SD Mowers B-Series LT-Series.pdf
By gwest_ca-(File Mod)
2 pages 119.23KB
Dated November 1982
Mower Rotary 1981 37in SD model 05-37MS01
Mower Rotary 1982 37in SD model 05-37MS01
Mower Rotary 1983 37in SD model 05-37MS02 - has been modified
1979 B-81 model 92-08BP01 in 1978-79 service manual is likely a mistake
1979 B-81 6-Speed model 92-08BF01
1979 B-111 4-Speed model 92-11BP01
1979 B-111 6-Speed model 92-11BF01
1979 B-111 6-Speed model 91-11BF91
1979 B-111 6-Speed model 92-11BF91
1979 B-111 6-Speed model 92-11BF92
1980 B-82 3-Speed model 02-08BP01
1980 B-112 3-Speed model 02-11BX01
1980 B-115 5-Speed model 02-11BP02
1980 B-165 Twin 5-Speed model 02-16BP01
1981 B-82 3-Speed model 02-08BP02
1981 B-82 3-Speed model 02-08BP03
1981 B-112 3-Speed model 02-11BX02
1981 B-112 3-Speed model 02-11BX03
1981 B-115 5-Speed model 02-11BP03
1981 B-115 5-Speed model 02-11BP04
1981 B-165 Twin 5-Speed model 02-16BP02
1981 B-165 Twin 5-Speed model 02-16BP03
1982 B-85 5-Speed model 02-08BX01
1982 B-115 5-Speed model 02-11BP05
1982 B-115 Automatic model 02-11BE01
1982 B-165 Twin 5-Speed model 02-16BP04
1982 B-165 Twin Automatic model 02-16BE01
1982 LT-832 3-Speed model A2-083201
1982 LT-1032 3-Speed model A2-103201
1982 LT-1137 5-Speed model A2-113701
1982 LT-1637 Twin 5-Speed model A2-163701
1982 LT-1642 Twin 5-Speed model A2-164201
1982 SB-371 3-Speed model 02-11BH01
53 downloads
Updated
-
Free
WH61-90 #410a 200-Series Transmission Clutch Spring.pdf
By gwest_ca-(File Mod)
2 pages 308.77KB
Dated June 1987
For transmission drive belt
1987 208-5 model 32-08B501
1987 211-3 model 32-11B301 - Not in PSB?
1987 211-3 model B2-11B392 - Not in PSB? - May be a 1986 model
1987 211-4 model 32-11B401
1987 211-5 model 32-11B501
1987 211-5 model 32-11BX01 - Not in PSB?
1987 211-5 model B2-11B591 - Not in PSB?
1987 212-6 model 32-12K601
1987 216-5 model B2-16B591 - Not in PSB?
64 downloads
Updated
-
Free
WH61-90 #389 Kohler Dip Stick 1986 300 400 single cyl.pdf
By admin-(Admin)
3 pages 99.77KB
Dated December 1985
Increases oil capacity to 2-1/2 quarts (2.37 or 2-3/8 liters)
Low oil switch
Dipstick
1986 310-8 model 21-10K802
1986 310-8 model 21-10K803
1986 312-8 model 21-12K802
1986 312-8 model 21-12K803
1986 312-A model 21-12KE01
1986 312-A model 21-12KE02
1986 414-8 model 31-14K801
1986 416-8 model 31-16K802
95 downloads
Updated
-
Free
WH61-90 #442 PTO Switch Change.pdf
By admin-(Admin)
3 pages 98.46KB
Dated May 1990
Pto switches 109327 & 110971 replaced by
Also see
Service Assembly 121389 - List of models involved - 109327 switch replaced by 98-2392 kit with rocker switch
7 pages 23KB
1982 GT-1142 8-Speed model A1-114201
1982 GT-1642 Twin 8-Speed model A1-164201
1982 GT-1848 Twin Automatic model A1-184801
1982 RR-532 5-Speed Rear Engine Rider model A3-053201 ???????
1982 RR-832 5-Speed Rear Engine Rider model A3-083201 ???????
1983 A- 81 5-Speed Rear Engine Rider model 03-08BP03
1983 A- 81 5-Speed Rear Engine Rider model 23-08BP02
1983 A- 81 5-Speed Rear Engine Rider model 23-08BX01
1983 A- 81 5-Speed Rear Engine Rider model 23-08XP01
1983 A-111 5-Speed Rear Engine Rider model 23-11BP02
1983 GT-1142 8-Speed model A1-114202
1983 GT-1642 Twin 8-Speed model A1-164202
1983 GT-1848 Twin Automatic model D1-184801
1984 A- 81 5-Speed Rear Engine Rider model 23-08BP03
1984 A-111 5-Speed Rear Engine Rider model 23-11BP03
1984 GT-1100 8-Speed model A1-11B801
1984 GT-1600 Twin 8-Speed model A1-16B801
1984 GT-1800 Twin Automatic model A1-18BE01
1986 211-3 model 22-11B302
1986 211-3 model B2-11B392 Not listed @ Toro
1986 211-5 model 22-11B502
-----------------------------------------------------------------------------------------------------------
Service Assembly 121395 - List of models involved - 109327 replaced by 98-2393 or 98-2394???? using 2 of 111332 lever micro switches
5 pages 17KB
1984 A- 85 5-Speed Rear Engine Rider model 33-08BP01 - 1985 model @ Toro
1984 A-115 5-Speed Rear Engine Rider model 33-11BP01 - 1985 model @ Toro
1985 A- 85 5-Speed Rear Engine Rider model 33-08BP01
1985 A-115 5-Speed Rear Engine Rider model 33-11BP01
1985 108-3 Rear Engine Rider model 33-08B301
1985 108-3 Rear Engine Rider model B3-08B302 [This is wrong @ Toro - 1981]
1985 108-5 Rear Engine Rider model 33-08B501
1985 108-R Rear Engine Rider model 33-08X301
1985 111-5 Rear Engine Rider model 33-11B501
1986 108-3 Rear Engine Rider model 33-08B303
1986 108-3 Rear Engine Rider model B3-08B303
1986 108-5 Rear Engine Rider model 33-08B502
1986 108-R Rear Engine Rider model 33-08X303
1986 111-5 Rear Engine Rider model 33-11B502
1986 111-5 Rear Engine Rider model B3-11B502
-----------------------------------------------------------------------------------------------------------
Service Assembly 121396 - List of models involved - 109327 and 110971 replaced by 98-2393 or 98-2394???? using 2 of 111332 lever micro switches
11 pages 28KB
1982 B-85 5-Speed model 02-08BX01
1982 B-115 5-Speed model 02-11BP05
1982 B-115 Automatic model 02-11BE01
1982 B-165 Twin 5-Speed model 02-16BP04
1982 B-165 Twin Automatic model 02-16BE01
1982 LT-832 3-Speed model A2-083201
1982 LT-1032 3-Speed model A2-103201
1982 LT-1137 5-Speed model A2-113701
1982 LT-1637 Twin 5-Speed model A2-163701
1982 LT-1642 Twin 5-Speed model A2-164201
1983 B-115 Automatic model 12-11BE01
1983 B-115 5-Speed model 12-11BP01
1983 B-165 Twin Automatic model 12-16BE01
1983 B-165 Twin 5-Speed model 12-16BP01
1983 LT- 832 3-Speed model A2-083202
1983 LT-1136 3-Speed model D2-113601
1983 LT-1137 3-Speed model D2-113701
1983 LT-1637 Twin 3-Speed model D2-163701
1984 B-115 5-Speed model 12-11BP02
1984 B-165 Twin Automatic model 12-16BE02
1984 B-1136 model B2-11BX91
1984 LT-1100 5-Speed model A2-11BP01
1984 LT-1100 3-Speed model A2-11BX01
1984 LT-1600 Twin 5-Speed model A2-16BP01
1985 208-3 model 22-08B301
1985 211-3 model 22-11B301
1985 211-3 Tractor model B2-11B301
1985 211-5 model 22-11B501
1985 211-A model 22-11BE01
1985 216-3 Tractor model B2-16B301
1985 216-5 model 22-16B501
1986 208-3 model 22-08B302
1986 211-6 model 22-11B601 Not listed @ Toro
1986 YT12-A model 22-12TE01
Do not know if these apply - Service bulletin dated 1990 - May have been changed in production
1987 108-3 Rear Engine Rider model 33-08B304
1987 108-3 Rear Engine Rider model B3-08B391
1987 108-4 Rear Engine Rider model 33-08B401
1987 108-5 Rear Engine Rider model 33-08B503
1987 110-4 model E3-09K491 - This is a 1988 model on the Belgium list so moving to the 1988 list
1987 111-5 Rear Engine Rider model 33-11B503
1987 111-5 Rear Engine Rider model B3-11B591
1987 111-6 Rear Engine Rider model 33-11B601
1987 112-6 model E3-12K691 - This is a 1988 model on the Belgium list so moving to the 1988 list
1987 112-C Rear Engine Rider model C3-12K501
1988 108-4 Rear Engine Rider model 33-08B402
1988 108-5 Rear Engine Rider model 33-08B504
1988 110-4 model E3-09K491 - This is a 1988 model on the Belgium list so copied from the 1987 list
1988 111-6 Rear Engine Rider model 33-11B602
1988 112-6 model E3-12K691 - This is a 1988 model on the Belgium list so copied from the 1987 list
1988 112-C Rear Engine Rider model C3-12K502
104 downloads
Updated
-
Free
WH61-90 #121 Engine Cross Reference 1970.pdf
By admin-(Admin)
1 page 55.79KB
1 page 83.95 - Mixed up
Split the 1969-1970 data in the original PSB to make sense
1970 Charger 12 model 1-7251
1970 Charger 12 model 1-7252
1970 Charger 12 model 1-7253
1970 Charger V7 model 1-7751
1970 Charger V8 model 1-7851
1970 Commando V7 model 1-4751
1970 Commando V7 model 1-4752
1970 Commando V8 model 1-4851
1970 Commando V8 model 1-4852
1970 Electro 12 model 1-7255
1970 GT-14 model 1-7451 - Kohler supplied the 10 amp regulator part # 4140308-S for the engine with stator spec # 6010b (K321S-6010b or K321-6010 or K321-6010b) -Toro has the incorrect engine listed and PSB #301e is wrong
1970 GT-14 model 1-7452 - Kohler supplied the 10 amp regulator part # 4140308-S for the engine with stator spec # 6010b (K321S-6010b or K321-6010 or K321-6010b) -Toro has the incorrect engine listed and PSB #301e is wrong
1970 GT-14 model 1-7453 - Kohler supplied the 10 amp regulator part # 4140308-S for the engine with stator spec # 6010b (K321S-6010b or K321-6010 or K321-6010b) -Toro has the incorrect engine listed and PSB #301e is wrong
1970 Raider 10 model 1-6051
1970 Raider 12 model 1-6251
1970 Raider 12 model 1-6252
1970 Raider 12 model 1-6253
58 downloads
Updated
-
Free
WH61-90 #069 Replacement Ignition Switches Orig.pdf
By admin-(Admin)
1 page 203.39KB
1 page 76.22KB
Dated December 1965
1 page revised 667KB
1-terminal switch 3656 replaced by 6890 switch
1962 model 552
1963 model 33E Lawn Ranger
1963 model 653
1965 model 605
1965 model 655
3-terminal switch 3656 stayed the same
1960 model 550
1961 model 551
4987 switch
1962 model 32E Lawn Ranger
1964 model 34E Lawn Ranger
1964 model 654
1965 model L-155 Lawn Ranger
1965 model RE-65 Rear Engine Rider
1966 model 606
1966 model 656
1966 model L-156 Lawn Ranger
1966 model RE-66 Rear Engine Rider
73 downloads
Updated
