Mower Rotary 42in RD 1979 95-42MR02 IPL SN.pdf
By admin-(Admin)
IPL #810121R1 or 810121 R1
7 pages 367.42KB
Dated 10/78
Fits C-Series tractors
Operator manual listed @ Toro is #810129R1
Drive belt 108834 (1/2" x 98") [Replaces 102741 as per PSB #272 in this application]
Spindle belt 106125 (1/2" x 89.03")
Mower spindle assemblies could be L, M, V or Z
For V see service bulletin 207B
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Mower Rotary 1979 42in RD model 95-42MR02
1979 serial numbers that have shown up for the 95-42MR02
018514
018998 - Build date 1979 9057 February 26, Monday
031203
031221 - Build date 1979 9097 April 07 Saturday
032419 - Build date 1979 9123 May 03 Thursday
036261 - Build date 1979 9129 May 09 Wednesday
037812 - Build date 1979 9177 June 26 Tuesday
248 downloads
Updated
-
Free
Mower Rotary 52in SD 1999 78370 5xi OM IPL SN.pdf
By gwest_ca-(File Mod)
Operator manual #3322-393
28 pages 922KB
Illustrated parts list #3323-184
12 pages 596KB
Fits 5xi tractors
Drive belt 95-4094 (HB x 96.72" or 5/8" x 96.72")
Spindle belt 102742 replaced by 94-2501 (1/2" x 103")
Mower blades 3 of 27-0990 - 18"
Mower Rotary 1999 52in SD model 78370 Serial 9900001-9999999
1999 serial numbers that have shown up for the 78370
9900179
9900312
9900613
50 downloads
Updated
-
Free
Mower Rotary 42in SD 1990 15-42SC02 OM TIPL SN.pdf
By gwest_ca-(File Mod)
Operator manual #810657R1 or 810657 R1
8 pages 2.40MB
Dated 08/89
IPL from Toro Master Parts Viewer
This ipl is shared with 48" deck so be careful selecting parts
6 pages 407.99KB
Fits 300, 400 and 500-Series tractors
Drive belt 102742 replaced by 94-2501 (1/2" x 103")
Spindle belt 6738 (1/2" x 86")
106077 replaced by 106636 3-blade set (3/4" round hole)
Front idler assembly mule
1/2" long spacer part number 101757 is on the outside between the pulley and cover.
5/8" long spacer part number 101734 is between the pulleys.
Spacer ID needs to slip over 3/4" shaft.
Mower Rotary 1990 42in SD model 15-42SC02
1990 serial numbers that have shown up for the 15-42SC02
0021465
0021654
0021746 - Build date 1989 9304 October 31 Tuesday
0022350 - Build date 1989 9331 November 27 Monday
0023217
0024827 - Build date 1990 0057 February 26 Monday
0024942
0026020 - Build date 1990 0082 March 23 Friday [0982]
0026172 - Build date 1990 0095 April 05 Thursday
0027766
412 downloads
Updated
-
Free
Mower Rotary 36in SD 1972 5-0720 TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
2 pages 202.82KB
Fits Commando 800
Clockwise spindle rotation
Drive belt 102607 (1/2" x 89.12") when used on medium frame 43-1/2" wheelbase tractors
1972 Commando 800 model 1-0110
1973 8hp 4-Speed model 1-0120
1974 B-80 4-Speed models 1-0140 and 1-0145
1974 B-100 Auto model 1-0510
1975 B-80 4-Speed model 1-0141
1975 B-100 Auto model 1-0511
Drive belt 102741 (1/2" x 96.6") for C-Series tractors (Gates replacement BladeRunner 6638BR 17/32" x 96.75")
Spindle belt 8411 (1/2" x 76.94")
100776 14-1/8" center blade and 100777 12-1/8" left and right blades replaced by 101335 3-blade kit and no longer available from Toro (Hole 5/8in.x3/4in. Double-D)
2017 Oregon catalog part number 91-802 12-1/8" and Gator blade 96-632 12-1/8" still available.
101335 blade set available again from Toro June 4, 2019
Mower Rotary 1972 36in SD model 5-0720
1972 serial numbers that have shown up for the 5-0720
064323
893483 - Model 5-0720-7
869224 - Model 5-0720-7
869612 - Model 5-0720-7
877155 - Model 5-0720-7
96 downloads
Updated
-
Free
Mower Rotary 60in SD 1997-1998 78390 500 OM SN.pdf
By gwest_ca-(File Mod)
Operator manual #3318-950
24 pages 1.89MB
Fits 520-Series tractors with forward swept front axle
Mower Rotary 1997 60in SD model 78390 Serial 7900001-7999999
1997 serial numbers that have shown up for the 78390
7900227
7900254
Mower Rotary 1998 60in SD model 78390 Serial 8900001-8999999
274 downloads
Updated
-
Free
Mower Rotary 42in RD 1990-1992 15-42RC02 IPL #3314-878.pdf
By gwest_ca-(File Mod)
IPL
8 pages 1.09MB
Operator manual dated 08/89 so should be 1990 also (1991 and 1992 @ Toro)
Fits 300, 400 and 500-Series tractors
Drive belt 108834 (1/2" x 98")
Spindle belt 106125 (1/2" x 89.03")
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Mower Rotary 1990 42in RD model 15-42RC02
Mower Rotary 1991 42in RD model 15-42RC02 Serial 1000001-1099999
Mower Rotary 1992 42in RD model 15-42RC02 Serial 2000001-2099999
418 downloads
Updated
-
Free
Mower Rotary 42in SD 1975 5-1012 OM TIPL sn.pdf
By gwest_ca-(File Mod)
Operator manual #803881 is listed by Toro for 5-1012 - 7 pages 542.54KB
Operator manual #803975 Dated 7-74 may be a better choice - 5 pages 1.73MB
IPL from Toro Master Parts Viewer
3 pages 262.28KB
Shared with 48" deck so be careful selecting parts
Fits C-Series tractors
Drive belt 102742 (1/2" x 103")
Spindle belt 6738 (1/2" x 86")
Mower spindle assemblies could be J, N, U, V, X or Z
For N and U see service bulletin 221B
For X and V see service bulletin 207B
6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Stens replacement - 3 of 350-041 still available March 6, 2021
Mower Rotary 1975 42in SD model 5-1012
130 downloads
Updated
-
Free
Mower Rotary 42in SD 1971-1972 5-1001 OM IPL SN.pdf
By gwest_ca-(File Mod)
Operator manual
IPL
10 pages 1.15MB
Dated 7-69 and Rev3/71
Includes Includes PSB's #120 #221B
Fits Raider, Charger and Electro long frame models
Listed as 1972 only at Toro
Drive belt 9782 (1/2" x 69")
Spindle belt 6738 (1/2" x 86")
Mower spindle assemblies could be J, N, U, V, X or Z
For N and U see service bulletin 221B
For X and V see service bulletin 207B
6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Stens replacement - 3 of 350-041 still available March 6, 2021
Mower Rotary 1971 42in SD model 5-1001
1971 serial numbers that have shown up for the 5-1001
827110 - Model 5-1001-6
Mower Rotary 1972 42in SD model 5-1001
1972 serial numbers that have shown up for the 5-1001
861057 - Model 5-1001-7
876359
405 downloads
Updated
-
Free
Mower Rotary 42in SD 1976 65-42MS01 OM TIPL SN.pdf
By gwest_ca-(File Mod)
Operator manual #803451R2 or 803451 R2
4 pages 3.52MB
IPL from Toro Master Parts Viewer
3 pages 201.74KB
Shared with 48" deck so be careful selecting parts
Fits C-Series tractors
Drive belt 102742 (1/2" x 103")
Spindle belt 6738 (1/2" x 86")
Mower spindle assemblies could be K, V, X or Z
For V and X see service bulletin 207B
6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Stens replacement - 3 of 350-041 still available March 6, 2021
Mower Rotary 1976 42in SD model 65-42MS01
1976 serial numbers that have shown up for the 65-42MS01
020599
020828 - Build date 1976 6174 June 22 Tuesday - Looks wrong
020987 - Build date 1976 6173 June 21 Monday - Looks wrong
219 downloads
Updated
-
Free
Mower Rotary 42in SD 1971 5-1000 OM IPL sn.pdf
By gwest_ca-(File Mod)
Operator manual
IPL
10 pages 1.15MB
Dated 7-69 and Rev3/71
Includes Includes PSB's #120 #221B
Fits Raider, Charger and Electro long frame models
Mower spindle assemblies could be J, N, U, V, X or Z
For N and U see service bulletin 221B
For X and V see service bulletin 207B
Drive belt 9782 (1/2" x 69") [9783 in belt chart is wrong]
Spindle belt 6738 (1/2" x 86")
6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Stens replacement - 3 of 350-041 still available March 6, 2021
Mower Rotary 1971 42in SD model 5-1000
102 downloads
Updated
-
Free
Mower Rotary 42in SD 1968 5-1421 OM IPL SN.pdf
By CasualObserver
Operator manual #A-5252
IPL
10 pages 1.75MB
Dated 5/1/67
Includes PSB's #094 #097 #221B
5-1421 42" Side discharge mower deck. Commonly used on mid-late 60s models using 10 or 12 Hp.
Fits Raider, Charger and Electro long frame models
Drive belt 7041 (1/2" x 72")
Spindle belt 6738 (1/2" X 86")
Mower spindle assemblies could be J, N, U, V, X or Z
For N and U see service bulletin 221B
For X and V see service bulletin 207B
6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Stens replacement - 3 of 350-041 still available March 6, 2021
Mower Rotary 1968 42in SD model 5-1421
1968 serial numbers that have shown up for the 5-1421
406134
406214
418777
430023
460100
465646
399 downloads
Updated
-
Free
Mower Rotary 42in SD 1977 75-42MS01 TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
6 pages 333.10KB
Shared with 48" deck so be careful selecting parts
Fits C-Series tractors
Drive belt 102742 replaced by 94-2501 (1/2" x 103")
Spindle belt 6738 (1/2" x 86")
Mower spindle assemblies could be K, V, X or Z
For V and X see service bulletin 207B
6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D) Last 42" side discharge deck to use blades with 5/8" x 3/4" double-D center hole unless the spindles have been upgraded
Stens replacement - 3 of 350-041 still available March 6, 2021
Mower Rotary 1977 42in SD model 75-42MS01
1977 serial numbers that have shown up for the 75-42MS01
006174
012852 - Build date 1977 7014 January 14 Friday
157493 - Could be a 75-42MS02 - Possibly made in Belgium - Located in Sweden
178 downloads
Updated
-
Free
Mower Rotary 42in SD 1977 75-42MS02 TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
7 pages 331.82KB
Shared with 48" deck so be careful selecting parts
Fits C-Series tractors
Drive belt 102742 replaced by 94-2501 (1/2" x 103")
Spindle belt 6738 (1/2" x 86")
Mower spindle assemblies could be L, M, V or Z
For V see service bulletin 207B
106077 replaced by 106636 3-blade set (3/4" round hole)
Mower Rotary 1977 42in SD model 75-42MS02
1975 serial numbers that have shown up for the 75-42MS02
157493 - Could be a 75-42MS01 - Possibly made in Belgium - Located in Sweden
95 downloads
Updated
-
Free
Mower Rotary 36in RD 1969 5-7365 CW OM IPL sn.pdf
By admin-(Admin)
Operator manual #A-5122
IPL
4 pages 539.46KB
Dated 7/69 Revised 11/9/70
CW rotation
Fits 10hp 12hp tractors
Listed in 1974 price list as a 1973 attachment for 1969 long frame tractors but there was a 5-7366 in 1970.
Drive belt 9360 (1/2" x 95.63") [1/2" x 97" in ipl looks wrong]
Spindle belt 8411 (1/2" x 76.94")
Mower spindle assemblies could be B, A1, G2 or Z
For A1 see service bulletin 292B
For G2 see service bulletin 292B
9187 center blade and 9188 left and right blades replaced by 8969 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
(101093 3-blade kit in blade chart is not correct)
8969 blade set available again from Toro June 4, 2019 - Still available January 23, 2021
Mower Rotary 1969 36in RD model 5-7365
197 downloads
Updated
-
Free
Mower Rotary Carrier Front 1994-1995 79380 IPL.pdf
By gwest_ca-(File Mod)
IPL #3316-365
4 pages 625.38KB
Fits 300 400 500-Series tractors
Mower Rotary 1994 42in SD model 79380 Carrier Serial 4900001-4999999
Mower Rotary 1995 42in SD model 79380 Carrier Serial 5900001-5999999
Mower Rotary 1994 48in SD model 79380 Carrier Serial 4900001-4999999
Mower Rotary 1995 48in SD model 79380 Carrier Serial 5900001-5999999
See 1983 service bulletin
for installation instructions and belts for the various mowers used
123 downloads
Updated
-
Free
Mower Rotary Carrier Front 1994-1996 79380 OM SN.pdf
By gwest_ca-(File Mod)
Operator manual #3315-411
8 pages 1.53MB
Fits 300 400 500-Series tractors
79380 replaces 07-01MC01, 07-01MC02, 07-01MC03
Mower Rotary 1994 42in SD model 79380 Carrier Serial 4900001-4999999
1994 serial numbers that have shown up for the 79380
4900136
Mower Rotary 1995 42in SD model 79380 Carrier Serial 5900001-5999999
Mower Rotary 1996 42in SD model 79380 Carrier Serial 6900001-6999999
1996 serial numbers that have shown up for the 79380
6900136
Mower Rotary 1994 48in SD model 79380 Carrier Serial 4900001-4999999
Mower Rotary 1995 48in SD model 79380 Carrier Serial 5900001-5999999
Mower Rotary 1996 48in SD model 79380 Carrier Serial 6900001-6999999
1996 serial numbers that have shown up for the 79380
6900136
See 1983 service bulletin
for installation instructions and belts for the various mowers used
187 downloads
Updated
-
Free
Mower Rotary 48in SD 1980 05-48MS01 C OM IPL SN.pdf
By gwest_ca-(File Mod)
Operator manual #810306R1 or 810306 R1
7 pages 1.29MB
IPL #810172R1 or 810172 R1
7 pages 788.25KB
Fits 12hp and up C-Series and GT-1848 except C-195 tractors
Drive belt 102742 replaced by 94-2501 (1/2" x 103")
Spindle belt 1594 (1/2" x 107.21")
Mower spindle assemblies could be L, M, V or Z
For V see service bulletin 292B
106078 blade replaced by 106637 3-blade set (3/4" round hole)
Mower Rotary 1980 48in SD model 05-48MS01
1980 serial numbers that have shown up for the 05-48MS01
00063450
202 downloads
Updated
-
Free
Mower Rotary 37in SD 1991 35-37SL02 IPL sn.pdf
By gwest_ca-(File Mod)
IPL #3314-818
8 pages 1.13MB
Fits 200-Series tractors
Mower drive and spindle belt 113141 replaced by 121000 (1/2" x 75.9")
Mower 2-blade set 109918 - 18.75" tip to tip (1990 and older used 109079 2-blade set)
Mower Rotary 1991 37in SD model 35-37SL02 Serial 1000001-1099999
105 downloads
Updated
-
Free
Mower Rotary 48in SD 1997-2001 78268 260 OM German sn.pdf
By gwest_ca-(File Mod)
Operator manual #3324-520
24 pages 650.81KB
Fits 260-Series export models
Available in English, French, Dutch, Italian
Mower Rotary 1997 48in SD model 78268 Serial 7900001-7900000
Mower Rotary 1998 48in SD model 78268 Serial 8900001-8900000
1998 serial numbers that have shown up for the 78268
8900001
Mower Rotary 1999 48in SD model 78268 Serial 9900001-9900000
Mower Rotary 2000 48in SD model 78268 Serial 200000001-200000000
Mower Rotary 2001 48in SD model 78268 Serial 210000001-210000000
39 downloads
Updated
-
Free
Mower Rotary 48in SD 1997-2001 78268 260 OM Dutch sn.pdf
By gwest_ca-(File Mod)
Operator manual #3324-521
24 pages 648.09KB
Fits 260-Series export models
Available in English, French, German, Italian
Mower Rotary 1997 48in SD model 78268 Serial 7900001-7900000
Mower Rotary 1998 48in SD model 78268 Serial 8900001-8900000
Mower Rotary 1999 48in SD model 78268 Serial 9900001-9900000
Mower Rotary 2000 48in SD model 78268 Serial 200000001-200000000
Mower Rotary 2001 48in SD model 78268 Serial 210000001-210000000
46 downloads
Updated
-
Free
Mower Rotary 42in RD 1979 95-42MR01 TIPL SN.pdf
By gwest_ca-(File Mod)
Illustrated parts list not available
1 page 53.64KB
Fits C-Series tractors
Drive belt 108834 (1/2" x 98") [Replaces 102741 as per PSB #272 in this application]
Spindle belt 106125 (1/2" x 89.03")
Mower spindle assemblies could be L, M, V or Z
For V see service bulletin 207B
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Mower Rotary 1979 42in RD model 95-42MR01
1979 serial numbers that have shown up for the 95-42MR01
012140 - Build date 1978 8341 December 07 Thursday
014842 - Build date 1978 8330 November 26 Sunday
023025 - Build date 1978 8352 December 18 Monday
023244
031221 - Build date 1979 9097 April 07 Saturday
122 downloads
Updated
-
Free
Mower Rotary 48in SD 2003-2006 78290 OM IPL SN.pdf
By gwest_ca-(File Mod)
Operator manual 3328-108 RevA
20 pages 654KB
Illustrated parts list 3328-130
8 pages 354KB
Fits XT-Series
Mower Rotary 2003 48" side discharge model 78290 Serial 23000000001-230999999
2003 serial numbers that have shown up for the 78290
230000679
Mower Rotary 2004 48" side discharge model 78290 Serial 24000000001-240999999
Mower Rotary 2005 48" side discharge model 78290 Serial 25000000001-250999999
Mower Rotary 2006 48" side discharge model 78290 Serial 26000000001-260999999
41 downloads
Updated
-
Free
Mower Rotary 42in RD 2003-2005 78291 OM sn.pdf
By gwest_ca-(File Mod)
Operator manual 3328-108 RevA
20 pages 654KB
Fits XT-Series
Mower Rotary 2003 42" rear discharge model 78291 Serial 23000000001-230999999
Mower Rotary 2004 42" rear discharge model 78291 Serial 24000000001-240999999
Mower Rotary 2005 42" rear discharge model 78291 Serial 25000000001-250999999
58 downloads
Updated
-
Free
Mower Rotary 48in SD 1973-1974 5-1220 D OM IPL SN DNA.pdf
By admin-(Admin)
Operator manual
IPL
6 pages each
Drive belt 102868 (1/2" x 105.5")
Spindle belt 1594 (1/2" x 107.21")
Mower spindle assemblies could be S, K, V, Y or Z
For K see service bulletin 211C
For V and Y see service bulletin 292B
4380 blade replaced by 6758 and then by 100202 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Mower Rotary 1973 48in SD model 5-1220 - Fits 18hp Auto tractors
Mower Rotary 1974 48in SD model 5-1220 - Fits D-Series Auto tractors
1974 serial numbers that have shown up for the 5-1220
0998902 - Model 5-1220-9
1019784 - Model 5-1220-9
DNA of 48in side discharge decks for the 18hp Auto, D-160 Auto, D-180 Auto and D-200 Auto
1973-1974 model 5-1220
1975 model 5-1221
1976 model 65-48XS01
1977 model 75-48XS01 - Blades up to here have a 5/8" x 3/4" double-D center hole - 3 blade set #100202 no longer available
The following decks use blades with 3/4" round center hole - 3-blade set #106637
1977 model 75-48XS02
1978 model 85-48XS01
1979 model 95-48XS00
1979 model 95-48XS01
1980 model 05-48XS01
1981-1982 model 05-48XS02
237 downloads
Updated
-
Free
Mower Rotary 36in SD 1971 5-0710 CW OM IPL DNA sn.pdf
By admin-(Admin)
Operator manual #A-5122
IPL
4 pages 1.13MB
Dated 7/69 Revised 1/22/71
CW rotation
Fits 800 models, Raider, Charger, Bronco tractors - long frame 45-1/2" wheel base
(Wrong in the Attachment Interchange for the CG-8 which uses CCW spindle rotation)
Drive belt 9360 (1/2" x 95.63") [1/2" x 97" in ipl looks wrong]
Spindle belt 8411 (1/2" x 76.94")
Mower spindle assemblies could be B, A1, G1 or Z
For A1 see service bulletin 292B
For G1 see service bulletin 292B
100776 14-1/8" center blade and 100777 12-1/8" left and right blades replaced by 101335 3-blade kit and no longer available from Toro (Hole 5/8in.x3/4in. Double-D)
2017 Oregon catalog part number 91-802 12-1/8" and Gator blade 96-632 12-1/8" still available.
101335 blade set available again from Toro June 4, 2019
Mower Rotary 1971 36in SD model 5-0710
Mower DNA
1971 model 5-0710 replaced by
1971 model 5-0711
1972 model 5-0720
1973-1974 model 5-0721
1975 model 5-0722
1976 model 65-36MS01
1977 model 75-36MS01
1977 model 75-36MS02
1978 model 85-36MS01
1979 model 95-36MS00 - These decks use blades with 5/8" x 3/4" center hole unless the spindle has been upgraded
-----------------------------------------------------------------------------------------------------------------------------------------------------------
1979 model 95-36MS01 replaced by
1980-1982 model 05-36MS01 - Last year for bearings with 3/4" ID
1983-1984 model 05-36MS02 - First year for bearings with 17mm ID unless older spindles were updated. These decks use blades with a 3/4" center hole
Note - 17mm is .669"
121 downloads
Updated
Sign in to follow this
Followers
0
