660 files
-
Free
Mower Rotary 48in SD 1995-1996 78360 3-4-500 OM SN.pdf
By gwest_ca-(File Mod)
Operator manual #3316-954
12 pages 2.46MB
Setup
1 page 112.81KB
Fits 300, 400 and 500-Series tractors
Mower Rotary 1995 48in SD model 78360 Serial 5900001-5999999
1995 serial numbers that have shown up
5900612
5900830
5901723
5902945
5904212
Mower Rotary 1996 48in SD model 78360 Serial 6900001-6999999
1996 serial numbers that have shown up
6900576
6900933
6901297
6901398
6901872
6902007
6902162
6902597
6903441
See service bulletin
Toro91-presGT #GT28
Mower Leveler Rod on 42in 48in decks
Retrofit pre-1998 mowers Service Assembly 98-1741
240 downloads
Updated
-
Free
Mower Vacuum Lawn 42in 48in 2001-2007 2010 2012 79301 OM sn.pdf
By gwest_ca-(File Mod)
Operator manual #3324-840
20 pages 444.33KB
Fits 300 400 500-Series tractors
Mower Rotary 2001 42in SD model 79301 Vacuum Serial 210000001-210999999
Mower Rotary 2002 42in SD model 79301 Vacuum Serial 220000001-220999999
Mower Rotary 2003 42in SD model 79301 Vacuum Serial 230000001-230999999
Mower Rotary 2004 42in SD model 79301 Vacuum Serial 240000001-240999999
2004 serial numbers that have shown up for the 79301
240000334
Mower Rotary 2005 42in SD model 79301 Vacuum Serial 250000001-250999999
Mower Rotary 2006 42in SD model 79301 Vacuum Serial 260000001-260999999
Mower Rotary 2007 42in SD model 79301 Vacuum Serial 270000001-270999999
Mower Rotary 2010 42in SD model 79301 Vacuum Serial 310000001-310999999
Mower Rotary 2012 42in SD model 79301 Vacuum Serial 312000001-312999999
Mower Rotary 2001 48in SD model 79301 Vacuum Serial 210000001-210999999
Mower Rotary 2002 48in SD model 79301 Vacuum Serial 220000001-220999999
Mower Rotary 2003 48in SD model 79301 Vacuum Serial 230000001-230999999
Mower Rotary 2004 48in SD model 79301 Vacuum Serial 240000001-240999999
Mower Rotary 2005 48in SD model 79301 Vacuum Serial 250000001-250999999
Mower Rotary 2006 48in SD model 79301 Vacuum Serial 260000001-260999999
Mower Rotary 2007 48in SD model 79301 Vacuum Serial 270000001-270999999
Mower Rotary 2010 48in SD model 79301 Vacuum Serial 310000001-310999999
Mower Rotary 2012 48in SD model 79301 Vacuum Serial 312000001-312999999
148 downloads
Updated
-
Free
Mower Sickle Side 48in Haban 425 OM IPL
By "Manic-Mechanic"
Haban 425 is a 48" side mounted Shaft Driven Sickle Bar Mower.
Application Bolens
Not unlike the Model 424 used on the 18 Auto & D Series, minus the Drive Shaft Assembly
24 pages 5.36MB
32 downloads
Updated
-
Free
Mower Sickle Side 48in Haban Applications & Sales.pdf
By gwest_ca-(File Mod)
2 pages 3MB - Sales
1 page 613KB - Applications
59 downloads
Updated
-
Free
Mower Rotary 32in RD 1961-1967 RMR-3261 OM IPL SN.pdf
By gwest_ca-(File Mod)
Operator manual #A-7137
IPL
2 pages 943.82KB
Fits 400, 401, 550 and 551 - Replaced by 5-7321
Model number listed as RM-3261 and RMR-32-61 in places.
Drive belt 1561 (1/2" x 30")
8777 2-blade set replaces 3719, 7760 and 7909 left blades and 3718, 7761 and 7908 right blades
Mower Rotary 1961 32in RD model RMR-3261 -
1961 serial numbers that have shown up for the RMR-3261
02294
03068
05690
Mower Rotary 1962 32in RD model RMR-3261
1961 serial numbers that have shown up for the RMR-3261
A-12167 - Serial hard to read See photo
Mower Rotary 1963 32in RD model RMR-3261
Mower Rotary 1964 32in RD model RMR-3261
Mower Rotary 1965 32in RD model RMR-3261
Mower Rotary 1966 32in RD model RMR-3261
Mower Rotary 1967 32in RD model RMR-3261
Later 1968-1969 service replacement model was 5-7321
418 downloads
Updated
-
Free
Mower Rotary 36in SD 1979 95-36MS01 IPL SN.pdf
By admin-(Admin)
IPL #810121R1 or 810121 R1
7 pages 1.34MB
Dated 10/78
Fits C-Series tractors
Drive belt 102741 (1/2" x 96.6") for B-Series & C-Series tractors with 45-1/2" wheelbase (Gates replacement BladeRunner 6638BR 17/32" x 96.75")
Spindle belt 8411 (1/2" x 76.94")
Mower spindle assemblies could be E, A1, F or Z
For A1 see service bulletin 292B
107983 3-blade set replaces 107437 left and right blades (12-1/8") and 107438 center blade (14-1/8") (Hole 3/4" round)
Mower Rotary 1979 36in SD model 95-36MS01
1979 serial numbers that have shown up for the 95-36MS01
029405 - Build date 1979 9114 April 24 Tuesday
029451 - Build date 1979 917x June
149 downloads
Updated
-
Free
Mower Rotary 42in SD 1993 78346 OM IPL SN.pdf
By gwest_ca-(File Mod)
Operator manual #3315-936
8 pages 1.57MB
Setup #3315-697
1 page 56KB
IPL #3316-268
8 pages 1.2MB
Application unknown. Sold 1993 1994 1995 and possibly 1996. Suspect it fits exported 300 and 400-Series tractors
Mower Rotary 1993 42in SD model 78346 Serial 3900001-3999999
1993 serial number that have shown up for the 78346
3900138 - Located in the UK
3900161 - Located in the UK
183 downloads
Updated
-
Free
Mower Vacuum Lawn 42in 48in 1994-1996 79301 IPL.pdf
By gwest_ca-(File Mod)
IPL #3316-888RevB or 3316-888 RevB
8 pages 1.55MB
Fits 300 400 500-Series tractors
Drive belt 42" deck 79-7480 (HA x 70.75" or 1/2" x 70.75")
Drive belt 48" deck 79-7490 (HA x 73.75" or 1/2" x 73.75")
251-288 bearing reported as being RA012RRB with extended inner ring and self-locking collar
Mower Rotary 1994 42in SD model 79301 Vacuum Serial 4900001-4999999
Mower Rotary 1995 42in SD model 79301 Vacuum Serial 5900001-5999999
Mower Rotary 1996 42in SD model 79301 Vacuum Serial 6900001-6999999
Mower Rotary 1994 48in SD model 79301 Vacuum Serial 4900001-4999999
Mower Rotary 1995 48in SD model 79301 Vacuum Serial 5900001-5999999
Mower Rotary 1996 48in SD model 79301 Vacuum Serial 6900001-6999999
113 downloads
Updated
-
Free
Mower Rotary 36in RD 1962 RMR-3662 OM IPL SN.pdf
By admin-(Admin)
Operator manual #A-7137
IPL
2 pages 997.23KB
Fits all except Lawn Ranger, 953 and 1054
Requires 6051 kit to fit 875, 1045, 1055 and 1075
Drive belt 1577 replaced by 7430 (1/2" x 28")
Spindle belts 1578 (3/8" x 37" matched pair)
8014 2-blade set replaces 4116 and 7906 right blades, 4117 and 7907 left blades and 2-blade set 101522
Mower Rotary 1962 36in RD model RMR-3662
1962 serial numbers that have shown up for the RMR-3662
A-07428
260 downloads
Updated
-
Free
Mower Rotary 60in SD 1995-1996 78390 500 OM SN.pdf
By gwest_ca-(File Mod)
Operator manual #3316-950
8 pages 1.78MB
Fits 520-Series tractors with forward swept front axle
Mower Rotary 1995 60in SD model 78390 Serial 5900001-5999999
1995 serial numbers that have shown up for the 78390
5900128
5900348
5900631
Mower Rotary 1996 60in SD model 78390 Serial 6900001-6999999
1996 serial numbers that have shown up for the 78390
6900244
6900491
205 downloads
Updated
-
Free
Mower Rotary 48in SD 1963 RM-483 OM IPL sn.pdf
By admin-(Admin)
Operator manual #A-7137
IPL
7 pages 2.9MB
Includes PSB #045 #046
Includes steering stop instructions & 6041 kit
Fits 953, 1054, 1054A tractors
Drive belt 1595 (1/2" x 66.95")
Spindle belt 1594 (1/2" x 107.21")
Mower spindle assemblies could be R, O, P, V, Y or Z
For O and P see service bulletin 221B
For V and Y see service bulletin 292B
4380 blade replaced by 6758 and then by 100202 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Mower Rotary 1963 48in SD model RM-483
151 downloads
Updated
-
Free
Mower Rotary 42in RD 1990-1992 15-42RC02 OM SN.pdf
By gwest_ca-(File Mod)
Operator manual #810735R1
8 pages 2.48MB
Dated 08/89 so should be 1990 also (1991 and 1992 @ Toro)
Fits 300, 400 and 500-Series tractors
Can be fitted with 86001 recycler kit
Mower Rotary 1990 42in RD model 15-42RC02
1990 serial numbers that have shown up for the 15-42RC02
1050564
Mower Rotary 1991 42in RD model 15-42RC02 Serial 1000001-1099999
1991 serial numbers that have shown up for the 15-42RC02
Mower Rotary 1992 42in RD model 15-42RC02 Serial 2000001-2099999
1992 serial numbers that have shown up for the 15-42RC02
2001207
2000433
2000633
107 downloads
Updated
-
Free
Mower Rotary 42in RD 1979-1983 05-42ER01 OM IPL sn.pdf
By gwest_ca-(File Mod)
Operator manual #810147R1 or 810147 R1
4 pages 1.13MB
IPL #810174R1 or 810174 R1
6 pages 1001.12KB
Fits 1980-1983 E-141 8-Speed model 01-14E801
107136 blade replaced by 106162 3-blade set - (5/8" x 3/4" double-D center hole)
Mower Rotary 1979 42in RD model 95-42ER01 - (In mower blade chart)
Mower Rotary 1980 42in RD model 05-42ER01
1980 serial numbers that have shown up for the 05-42ER01
001123 - Build date 1979 91xx
Mower Rotary 1981 42in RD model 05-42ER01
Mower Rotary 1982 42in RD model 05-42ER01
Mower Rotary 1983 42in RD model 05-42ER01
116 downloads
Updated
-
Free
Mower Rotary 37in SD 1996-1998 78315 IPL.pdf
By gwest_ca-(File Mod)
IPL #3318-365
8 pages 163.02KB
Fits 300-Series tractors
Drive and spindle belt 110265 (1/2" x 141.00")
Mower Rotary 1996 37in SD model 78315 Serial 6900001-6999999
1996 serial numbers that have shown up for the 78315
6900800
Mower Rotary 1997 37in SD model 78315 Serial 7900001-7999999
Mower Rotary 1998 37in SD model 78315 Serial 8900001-8999999
96 downloads
Updated
-
Free
Mower Rotary 42in RD 1977 75-42MR02 TIPL SN.pdf
By admin-(Admin)
IPL from Toro Master Parts Viewer
6 pages 326.69KB
Fits B-Series and C-Series tractors
Drive belt 102741 (1/2" x 96.6") (Gates replacement BladeRunner 6638BR 17/32" x 96.75")
Spindle belt 106125 (1/2" x 89.03")
Mower spindle assemblies could be L, M, V or Z
For V see service bulletin 207B
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Mower Rotary 1977 42in RD model 75-42MR02
1977 serial numbers that have shown up for the 75-42MR02
013604 - Build date 1977 7026 January 26 Wednesday
026586 - Build date 1977 7172 June 21 Tuesday
026640 - Build date 1977 7173 June 22 Wednesday
176 downloads
Updated
-
Free
Mower Rotary 36in RD 1977 75-36MR02 TIPL sn.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
5 pages 416.71KB
Fits A-90 4-Speed and A-100 4-Speed tractors
Drive belt 105477 (1/2" x 40.4")
Spindle belt 105475 replaced by 106751 (1/2" x 80.5")
Mower spindle assemblies could be D, A2, G3 or Z
For A2 and G3 see service bulletin 292B
100776 14-1/8" center blade and 100777 12-1/8" left and right blades replaced by 101335 3-blade kit and no longer available from Toro (Hole 5/8in.x3/4in. Double-D)
2017 Oregon catalog part number 91-802 12-1/8" and Gator blade 96-632 12-1/8" still available.
101335 blade set available again from Toro June 4, 2019
Mower Rotary 1977 36in RD model 75-36MR02
1977 serial numbers that have shown up for the 75-36MR02
57 downloads
Updated
-
Free
Mower Rotary 36in RD 1978 85-36MR01 TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
6 pages 373.88KB
Fits B-Series and C-Series tractors
Drive belt 102607 (1/2" x 89.12") when used on medium frame 43-1/2" wheelbase tractors
1972 Commando 800 model 1-0110
1973 8hp 4-Speed model 1-0120
1974 B-80 4-Speed models 1-0140 and 1-0145
1974 B-100 Auto model 1-0510
1975 B-80 4-Speed model 1-0141
1975 B-100 Auto model 1-0511
Drive belt 102741 (1/2" x 96.6") for B-Series & C-Series tractors with 45-1/2" wheelbase (Gates replacement BladeRunner 6638BR 17/32" x 96.75")
Spindle belt 8411 (1/2" x 76.94")
Mower spindle assemblies could be D, A1, G2 or Z
For A1 and G2 see service bulletin 292B
9187 center blade and 9188 left and right blades replaced by 8969 3-blade kit (Hole 5/8in.x3/4in. Double-D)
8969 blade set available again from Toro June 4, 2019
Mower Rotary 1978 36in RD model 85-36MR01
1978 serial numbers that have shown up for the 85-36MR01
002240 - Build date 1977 7338 December 04 Sunday (Plate stamped 338) - Best guess
007087
007128 - Build date 1978 8020 January 20 Friday
008021 - Build date 1978 8037 February 06 Monday
008150 - Build date 1978 8038 February 07 Tuesday
008240 - Build date 1978 8038 February 07 Tuesday
013307 - Build date 1978 8077 March 18 Saturday
013575 - Build date 1978 8079 March 20 Monday
017918 - Build date 1978 8111 April 21 Friday
019333 - Build date 1978 8128 May 08 Monday
021518 - Build date 1978 8136 May 16 Tuesday
021553 - Build date 1978 8136 May 16 Tuesday
021670 - Build date 1978 8136 May 16 Tuesday
206 downloads
Updated
-
Free
Mower Rotary 48in SD 1976 65-48XS01 D OM TIPL sn.pdf
By gwest_ca-(File Mod)
Operator manual #803450R2 or 803450 R2
5 pages 4.31MB
IPL from Toro Master Parts Viewer
3 pages 295.58KB
Fits D-Series Auto tractors
Drive belt 102868 (1/2" x 105.5")
Spindle belt 1594 (1/2" x 107.21")
4380 blade replaced by 6758 and then by 100202 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Mower Rotary 1976 48in SD model 65-48XS01
165 downloads
Updated
-
Free
Mower Rotary 44in SD 1998 78357 & 78358 5xi OM IPL.pdf
By gwest_ca-(File Mod)
Operator manual #3322-660
28 pages 785KB
Addendum #3322-654
1 page 9KB
Illustrated parts list #3319-729
16 pages 713KB
Fits
518xi models 73470 and 73471 tractors
520xi models 73540 and 73542 tractors
Drive belt 95-4094 (HB x 96.72" or 5/8" x 96.72")
Spindle belt 95-4228 (HA x 82.04" or 1/2" x 82.04")
Model 78357 mower blades 3 of 54-0010
Model 78358 recycler mower blades 3 of 55-4940
1998 44" SD mower model 78357 Serial 8900001-8999999 - (86041 Recycler kit can be added to make a model 78358)
1998 serial numbers that have shown up for the 78357
8901629
8901772
1998 44" SD mower model 78358 Recycler Serial 8900001-8999999
1998 serial numbers that have shown up for the 78358
8900314
86041 44" Side Discharge Recycler kit
Operator manual 3322-656
4 pages 103KB
Illustrated parts list 3321-598
4 pages 114KB
108 downloads
Updated
-
Free
Mower Rotary 42in RD 1995-1998 78355 Recycler IPL.pdf
By gwest_ca-(File Mod)
IPL #3317-341RevB or #3317-341 RevB
8 pages 152.04KB
Fits 300, 400 and 500-Series tractors
Drive belt 108834 (1/2" x 98") [102742 is wrong in the belt chart for 1996, 1997 and 1998]
Spindle belt 106125 (1/2" x 89.03") [6738 is wrong in the belt chart for 1996, 1997 and 1998]
Toro 3-blade kit 14-4879 replaces 116840, 79-2920 and 79-3070
Napa 3 of # 7-06767
Hole 3/4in. round
14.500in. 14-1/2" long
Mower Rotary 1995 42in RD model 78355 Recycler Serial 5900001-5999999
Mower Rotary 1996 42in RD model 78355 Recycler Serial 6900001-6999999 - [Belts wrong in the belt chart for 1996]
Mower Rotary 1997 42in RD model 78355 Recycler Serial 7900001-7999999 - [Belts wrong in the belt chart for 1997]
Mower Rotary 1998 42in RD model 78355 Recycler Serial 8900001-8999999 - [Belts wrong in the belt chart for 1998]
98 downloads
Updated
-
Free
Chart Spindle ID Mower Rotary 1969-1989 35 pages.pdf
By Joe Warren
35 pages 453.25KB
Dated February 1997
Click on a model line in the index and it will take you to a single page showing all the spindle assemblies used on that model over the years.
This may be publication #810415R2 replaced by 492-0393.
2,432 downloads
Updated
-
Free
Mower Rotary 42in SD 1973-1974 5-1010 OM IPL SN.pdf
By admin-(Admin)
Operator manual
IPL
7 pages each
Includes PSB #142
Fits 10hp 12hp 14hp 16hp except GT-14 tractors
Drive belt 102742 replaced by 94-2501 (1/2" x 103")
Spindle belt 6738 (1/2" x 86")
Mower spindle assemblies could be S, K, V, X or Z
For K see service bulletin 211C
For X and V see service bulletin 207B
6693 blade replaced by 100200 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Stens replacement - 3 of 350-041 still available March 6, 2021
Mower Rotary 1973 42in SD model 5-1010
1973 serial numbers that have shown up for the 5-1010
0233248 - Model 5-1010-8
0912741 - Model 5-1010-8
0913013 - Model 5-1010-8
0913499 - Model 5-1010-8
0956642 - Could be a 1974 model
0976509 - Model 5-1010-8
Mower Rotary 1974 42in SD model 5-1010
1974 serial numbers that have shown up for the 5-1010
0045496 - Model 5-1010-9
0956642 - Could be a 1973 model
0999526 - Model 5-1010-9
Manual sources
Mower Rotary 42in SD 1973-74 5-1010 & 48in SD 5-1210 OM IPL1 #749-750
Mower Rotary 42in SD 1973-74 5-1010 & 48in SD 5-1210 OM IPL2 #A-5328
Mower Rotary 42in SD 1973-74 5-1010 & 48in SD 5-1210 OM IPL3 #803881
Mower Rotary 42in SD 1974 5-1010 OM #803859
598 downloads
Updated
-
Free
Mower Rotary 48in SD 1989 15-48SC01 3-4-500 TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
6 pages 420.43KB
Fits 300, 400 and 500-Series tractors
Drive belt 102742 replaced by 94-2501 (1/2" x 103")
Spindle belt 1594 (1/2" x 107.21")
Uses Z spindle assembly
106078 blade replaced by 106637 3-blade set (3/4" round hole)
Mower Rotary 1989 48in SD model 15-48SC01
1989 serial numbers that have shown up for the 15-48SC01
0009117
0011039 - Build date 1988 8251 September 07 Wednesday
0011741
0012242
0012363 - Build date 1988 83xx
0012795
0014693
0014952 - Build date 1989 9100 April 10 Monday
0015643
347 downloads
Updated
-
Free
Mower Rotary 48in SD 1986-1988 05-48MS05 3-4-500 OM IPL SN.pdf
By gwest_ca-(File Mod)
Operator manual #810403R1 or 810403 R1
8 pages 1.35MB
Operator manual #810518R1 or 810518 R1
8 pages 1.79MB
IPL #810407R1 or 810407 R1
7 pages 2.57MB
Fits 300, 400 and 500-Series tractors
Drive belt 102742 replaced by 94-2501 (1/2" x 103") [Napa 6378 (1/2" x 103.25")]
Spindle belt 1594 (1/2" x 107.21") [Napa 6781BR (1/2" x 107.24")]
Uses Z spindle assembly
Item #3 spacer 111044 reported to be 5/8" OD, 3/8" ID and 5/16" long
106078 blade replaced by 106637 3-blade set (3/4" round hole)
Mower Rotary 1986 48in SD model 05-48MS05
1986 serial numbers that have shown up for the 05-48MS05
08032
80639
81777 - Could be a 1987 or 1988 model
Mower Rotary 1987 48in SD model 05-48MS05
1987 serial numbers that have shown up for the 05-48MS05
61646
62163
71470 - Build date 1987 7301 October 28 Wednesday
82163
83222 - Model year unknown
84129
Mower Rotary 1988 48in SD model 05-48MS05
1988 serial numbers that have shown up for the 05-48MS05
8392 - Build date 1988 8088 March 28 Monday - Serial may be missing a digit 8392x
709 downloads
Updated
-
Free
Mower Rotary 44in SD 1995-2007 79102 XL Vacuum bagger OM IPL sn.pdf
By gwest_ca-(File Mod)
Operator manual #3317-272 for 1995-1996 & 1999
23 pages 660KB
Operator manual #3323-320RevA for 2000-2007
24 pages 900KB
IPL #3317-310RevA for 1995
8 pages 156KB
IPL #3318-160 for 1996 & 1999
8 pages 157KB
IPL #3323-797 for 2000-2007
12 pages 202KB
Fits XL-Series tractors with 44in side discharge deck - 11 cubic feet
Mower blades 3 of 55-4940-03
1995 Vacuum bagger model 79102 Serial 5900001-5999999
1996 Vacuum bagger model 79102 Serial 6900001-6999999
1999 Vacuum bagger model 79102 Serial 9900001-9999999
2000 Vacuum bagger model 79102 Serial 200000001-200000000
2001 Vacuum bagger model 79102 Serial 210000001-210000000
2002 Vacuum bagger model 79102 Serial 220000001-220000000
2003 Vacuum bagger model 79102 Serial 230000001-230000000
2004 Vacuum bagger model 79102 Serial 240000001-240000000
2005 Vacuum bagger model 79102 Serial 250000001-250000000
2006 Vacuum bagger model 79102 Serial 260000001-260000000
2007 Vacuum bagger model 79102 Serial 270000001-270000000
187 downloads
Updated
Sign in to follow this
Followers
0
