660 files
-
Free
Mower Rotary 36in SD 1972 5-0701 CCW OM IPL sn.pdf
By admin-(Admin)
Operator manual #A-5284
IPL
4 pages 964.47KB
Dated 1/22/71
CCW spindle rotation with left side discharge
Fits CG-7, CG-8 tractors
Drive belt 8412 (1/2" x 86")
Spindle belt 8411 (1/2" x 76.94")
100460 center blade and 100459 left and right blades replaced by 101093 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Mower Rotary 1972 36in SD model 5-0701
1972 serial numbers that have shown up for the 5-0701
806358 - Model 5-0701-6 indicating it is a 1971 model
61 downloads
Updated
-
Free
Mower Rotary 36in RD 1971 5-0610 CCW OM IPL sn.pdf
By admin-(Admin)
Operator manual #A-5284
IPL
4 pages 964.47KB
CCW spindle rotation
Fits CG-7 and CG-8 tractors
This application in the 1955-2000 Attachment interchange is wrong
Drive belt 8412 (1/2" x 86")
Spindle belt 8411 (1/2" x 76.94")
8393 center blade and 8394 left and right blades replaced by 9819 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Mower Rotary 1971 36in RD model 5-0610
94 downloads
Updated
-
Free
Mower Rotary 36in SD 1973 5-0702 CCW OM IPL sn.pdf
By admin-(Admin)
Operator manual #A-5337
IPL
6 pages 1.04MB
Dated 8/72
CCW spindle rotation with left side discharge
Fits 8hp 4-speed with vertical shaft engine
Drive belt 8412 (1/2" x 86")
Spindle belt 8411 (1/2" x 76.94")
Mower spindle assemblies could be B, A1, G1 or Z
For A1 see service bulletin 292B
For G1 see service bulletin 292B
100460 center blade and 100459 left and right blades replaced by 101093 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Mower Rotary 1973 36in SD model 5-0702 CCW
Was still available in 1974 according to the price list
60 downloads
Updated
-
Free
Mower Rotary 37in SD 1991 07-08BK01 Bagger Easy Twin OM IPL sn.pdf
By gwest_ca-(File Mod)
Operator manual #810736R1 listed @ Toro is not correct.
IPL #3314-895
3 pages 817KB
Fits 250-Series tractors
Mower Rotary 1991 37in SD model 07-08BK01 Bagger
54 downloads
Updated
-
Free
Mower Rotary 30in SD 1991-1992 07-08BL02 Bagger Easy Twin OM IPL sn.pdf
By gwest_ca-(File Mod)
Operator manual #810770R1 or 810770 R1
8 pages 1.6MB
IPL #3314-895
3 pages 851KB
Fits 200-Series tractors
Mower Rotary 1991 30in SD model 07-08BL02 Bagger - Serial 1000001-1099999
Mower Rotary 1992 30in SD model 07-08BL02 Bagger - Serial 2000001-2099999
55 downloads
Updated
-
Free
Mower Rotary 42in SD 1991-1992 D5-42MS01 OM IPL sn.pdf
By gwest_ca-(File Mod)
Operator manual #810518R1 or 810518 R1
8 pages 1.79MB
Dated 03/87
IPL #3314-891
8 pages 966.07KB
Fits export 300, 400 and 500-Series models?
Mower Rotary 1991 42in SD model D5-42MS01 Serial 1000001-1999999
Mower Rotary 1992 42in SD model D5-42MS01 Serial 2000001-2999999
62 downloads
Updated
-
Free
Mower Rotary 42in RD 1992 D5-42MR01 OM IPL sn.pdf
By gwest_ca-(File Mod)
Operator manual #810518R1 or 810518 R1
8 pages 1.79MB
Dated 03/87
IPL #3315-302
8 pages 1.07MB
Uses 106635 106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Export model may fit 300, 400 and 500-Series tractors
Mower Rotary 1992 42in RD model D5-42MR01
63 downloads
Updated
-
Free
Mower Rotary 36in RD 1991-1992 D5-36MR01 OM IPL sn.pdf
By gwest_ca-(File Mod)
Operator manual #810518R1 or 810518 R1
8 pages 1.79MB
Dated 03/87
IPL #3314-912
8 pages 1.79MB
Application unknown
Operator manual listed in IPL is #810733
Mower Rotary 1991 36in RD model D5-36MR01 Serial 1000001-1099999
Mower Rotary 1992 36in RD model D5-36MR01 Serial 2000001-2099999
51 downloads
Updated
-
Free
Mower Rotary 42in SD 1989-1990 05-42SY01 OM TIPL SN.pdf
By gwest_ca-(File Mod)
Operator manual #810598R1
8 pages 2.06MB
IPL from Toro Master Parts Viewer
7 pages 507.13KB
Fits 612-Z, 616-Z and 620-Z
Drive belt 116160 (Aftermarket replacements are 5/8" x 72") - Not in the belt chart
Spindle belt 116507 (Dimensions unknown) - Not in the belt chart
Mower Rotary 1989 42in SD model 05-42SY01
1989 serial numbers that have shown up for the 05-42SY01
11832 - Model year a guess
Mower Rotary 1990 42in SD model 05-42SY01
128 downloads
Updated
-
Free
Mower Rotary 30in SD 1991-1992 17-06BL01 Bagger OM IPL sn.pdf
By gwest_ca-(File Mod)
Operator manual #810714R1
8 pages 1.34MB
IPL #3314-545RevB
4 pages 798.97KB
Fits 200-Series tractors
1991 30in SD Bagger model 17-06BL01 Serial 1000001-199999
1992 30in SD Bagger model 17-06BL01 Serial 2000001-299999
47 downloads
Updated
-
Free
Mower Rotary 38in SD 1991-1992 27-06BL01 Bagger OM IPL sn.pdf
By gwest_ca-(File Mod)
Operator manual #810714R1 or 810714 R1
8 pages 1.34MB
IPL #3314-545RevB or 3314-545 RevB
4 pages 798.97KB
Fits 200-Series tractors
1991 38in SD Bagger model 27-06BL01 Serial 1000001-1999999
1992 38in SD Bagger model 27-06BL01 Serial 2000001-2999999
27 downloads
Updated
-
Free
Mower Rotary 30in SD 1991 35-30SL02 OM IPL SN.pdf
By gwest_ca-(File Mod)
Operator manual #810732R1
8 pages 2.60MB
Dated 10/91
IPL #3314-812
4 pages 764.29KB
Fits some 200-Series lawn tractors
Drive and spindle belt 114421 (1/2" x 53.50")
110397 and 111144 blade replaced by 112560 (3/4" center hole)
Mower Rotary 1991 30in SD model 35-30SL02 Serial 1000001-1999999
1991 serial numbers that have shown up for the 35-30SL02
1050973
73 downloads
Updated
-
Free
Mower Rotary 30in SD 1990 35-30SL01 OM SN.pdf
By Dresden Guy
Operator manual #810661R1
Part 1 - 3 pages 4.39MB
Part 2 - 4 pages 3.59MB
Dated 06/89
Fits some 200-Series lawn tractors
Power grass collector 07-31PS01 available for this deck.
This is a better copy than the one that can be downloaded from Toro.
See product service bulletin "WH89-90 #T28 216-H 30in Mower Belt"
Mower 35-30SL01 serial # 20987 and lower requires longer belt # 114421 if used on a 216-H tractor
Mower Rotary 1990 30in SD model 35-30SL01
1990 serial numbers that have shown up for the 35-30SL01
0020987 - Shown in PSB #T-28
0022777 - Build date 1990 0005 January 05 Friday
0023367 - Build date 1990 0078 March 19 Monday
0023422 - Build date 1990 0078 March 19 Monday
0023423 - Build date 1990 0078 March 19 Monday
110 downloads
Updated
-
Free
Mower Reel Front 30in 1964 LMR-304 OM IPL sn.pdf
By admin-(Admin)
Operator manual #A-7137
IPL
3 pages 1.19MB
Mower Reel 1964 30in Front model LMR-304
106 downloads
Updated
-
Free
Mower Reel Front 30in 1963 LMR-303 OM IPL sn.pdf
By gwest_ca-(File Mod)
Operator manual #A-7137
IPL
3 pages 1.12MB
Mower Reel 1963 30in Front model LMR-303
85 downloads
Updated
-
Free
Mower Reel Front 30in 1963 Kit 6040.pdf
By admin-(Admin)
Kit #6040
1 page 41.49KB
Converts 1962 LMR-3072 to 1963 LMR-303
Mower Reel 1962 30in Front Kit model 6040
63 downloads
Updated
-
Free
Mower Rotary 42in RD 1986 05-42XR06 OM TIPL sn.pdf
By gwest_ca-(File Mod)
Operator manual #810402R1 or 810402 R1
7 pages 885.24KB
IPL from Toro Master Parts Viewer
7 pages 424.23KB
Fits 211-3 and 211-5 tractors
Drive belt 106523 replaced by 110141 (1/2" x 41")
Spindle belt 106516 (1/2" x 83")
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Mower Rotary 1986 42in RD model 05-42XR06
68 downloads
Updated
-
Free
Mower Rotary 42in RD 1985 05-42XR05 TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
7 pages 429.87KB
Fits 200-Series tractors
Drive belt 106523 replaced by 110141 (1/2" x 41")
Spindle belt 106516 (1/2" x 83")
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Mower Rotary 1985 42in RD model 05-42XR05
1985 serial numbers that have shown up for the 05-42XR05
51391 - Build date 1985 5029 January 29 Tuesday
51442
46 downloads
Updated
-
Free
Mower Rotary 42in RD 1985 05-42XR04 TIPL sn.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
7 pages 541.19KB
Fits 200-Series tractors
Drive belt 106523 replaced by 110141 (1/2" x 41")
Spindle belt 106516 (1/2" x 83")
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole) - Not in the mower blade chart
Mower Rotary 1985 42in RD model 05-42XR04
57 downloads
Updated
-
Free
Mower Rotary 48in SD 1969 5-5481 TIPL sn.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
2 pages 223.16KB
Formerly RM-485
Replacement deck for 953, 1054 and 1054A tractors
Drive belt 1595 (1/2" x 66.95")
Spindle belt 1594 (1/2" x 107.21")
Mower spindle assemblies could be Q, P, V, Y or Z
For P see service bulletin 221B
For V and Y see service bulletin 292B
4380 blade replaced by 6758 and then by 100202 3-blade kit and no longer available (Hole 5/8in.x3/4in. Double-D)
Mower Rotary 1963 48in SD model 5-5481
Mower Rotary 1964 48in SD model 5-5481
Mower Rotary 1965 48in SD model 5-5481
Mower Rotary 1969 48in SD model 5-5481
82 downloads
Updated
-
Free
Mower Rotary 48in SD 1981-1982 05-48XS02 TIPL sn.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
7 pages 370.74KB
Fits D-Series Auto tractors
Drive belt 102868 (1/2" x 105.5")
Spindle belt 1594 (1/2" x 107.21")
Mower spindle assemblies could be L, M, V or Z
For V see service bulletin 292B
106078 blade replaced by 106637 3-blade set (3/4" round hole)
Mower Rotary 1981 48in SD model 05-48XS02
Mower Rotary 1982 48in SD model 05-48XS02
64 downloads
Updated
-
Free
Mower Rotary 42in RD 1984 05-42XR03 TIPL sn.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
9 pages 519.13KB
Fits B-Series and LT-Series tractors
Drive belt 106523 replaced by 110141 (1/2" x 41")
Spindle belt 106516 (1/2" x 83")
Mower spindle assemblies could be L, M, V or Z
For V see service bulletin 207B
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Mower Rotary 1984 42in RD model 05-42XR03
53 downloads
Updated
-
Free
Mower Rotary 42in SD 1979-1983 05-42SB01 TIPL SN.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
7 pages 444.48KB
Shared with rear discharge model so be careful selecting parts
Fits B-Series and LT-Series tractors with vertical shaft engines
Drive belt 106523 replaced by 110141 (1/2" x 41")
Spindle belt 106516 (1/2" x 83")
Mower spindle assemblies could be L, M, V or Z
For V see service bulletin 207B
106077 replaced by 106636 3-blade set (3/4" round hole)
Mower Rotary 1979 42in SD model 05-42SB01 - Fits B-Series
Mower Rotary 1980 42in SD model 05-42SB01 - Fits B-Series
Mower Rotary 1981 42in SD model 05-42SB01 - Fits B-Series
Mower Rotary 1982 42in SD model 05-42SB01 - Fits B-Series and LT-Series
1982 serial numbers that have shown up for the 05-42SB01
37794 - Build date 1981 1328 November 24 Tuesday
Mower Rotary 1983 42in SD model 05-42SB01 - Fits B-Series
90 downloads
Updated
-
Free
Mower Rotary 42in RD 1979 95-42XR02 TIPL sn.pdf
By gwest_ca-(File Mod)
IPL from Toro Master Parts Viewer
6 pages 318.49KB
Fits B-111 tractors
Drive belt 106523 replaced by 110141 (1/2" x 41")
Spindle belt 106516 (1/2" x 83")
Mower spindle assemblies could be L, M, V or Z
For V see service bulletin 207B
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Mower Rotary 1979 42in RD model 95-42XR02
55 downloads
Updated
-
Free
Mower Rotary 42in RD 1979 95-42XR01 TIPL sn.pdf
By gwest_ca-(File Mod)
IPL from Toro master Parts Viewer
8 pages 280.11KB
Fits B-111 tractors
Drive belt 106523 replaced by 110141 (1/2" x 41")
Spindle belt 106516 (1/2" x 83")
Mower spindle assemblies could be L, M, V or Z
For V see service bulletin 207B
106079 and 106108 blades replaced by 106635 3-blade set (3/4" center hole)
Mower Rotary 1979 42in RD model 95-42XR01
57 downloads
Updated
