All years

Not specific to any year, or for all years.

83 files

  1. Free

    Lift Electric 1975-1976 8-4222 TIPL.pdf

    IPL from Toro Master Parts Viewer
    2 pages 131.49KB

    Model 84222 @ Toro
    Replaces 8-4221

    Fits
    1975 B-80 4-speed model 1-0141
    1975 C-100 8-speed model 1-0391
    1975 C-120 8-speed models 1-0357, 1-0375 and 1-0395
    1975 C-160 8-speed model 1-0381
    1976 B-80 8-speed model 61-08K801
    1976 B-100 8-speed model 61-10K801
    1976 C-120 8-speed model 61-12K801
    1976 C-160 8-speed model 61-16K801

    123 downloads

    Updated

  2. Free

    Light kit 1974-1975 8-0820 TIPL.pdf

    IPL from Toro Master Parts Viewer
    2 pages 139.02KB
    Fits D-160
    Standard equipment on D-180 and D-200 in 1974

    54 downloads

    Updated

  3. Free

    Lift Hydraulic 1974 8-4112 TIPL.pdf

    IPL from Toro Master Parts Viewer
    2 pages 164.47KB

    Kit for 1974 B-100 Auto and C-120 Auto
    Notice the spring dimensions added to the illustration. Looks like 13/16 and 7/8.

    108 downloads

    Updated

  4. Free

    Lift Electric 1989-1990 8-4227 TIPL.pdf

    IPL from Toro Master Parts Viewer
    2 pages 163.37KB
    Model number 84227 at Toro

    Fits
    1989 518-H model 31-18OE02

    1990 520-8 model 41-20O801

    108 downloads

    Updated

  5. Free

    Chart Wheel Horse All Years 24 pages.pdf

    24 pages 124.14KB

    707 downloads

    Updated

  6. Free

    Chart Wheel Horse by Year 14 pages.pdf

    14 pages 74.64KB

    409 downloads

    Updated

  7. Free

    Chart Wheel Horse Products Master Model List 12 pages.pdf

    12 pages 234.89KB

    629 downloads

    Updated

  8. Free

    Lift Hydraulic 1970-1973 Rear 8-4121 OM IPL.pdf

    Operator manual #A-5204
    IPL
    84121 at Toro
    Fits rear of GT-14
    Independent Hydraulic Lift for use with 8-5412 3-point hitch

    1970 Lift Hydraulic Rear model 8-4121
    1971 Lift Hydraulic Rear model 8-4121
    1972 Lift Hydraulic Rear model 8-4121
    1973 Lift Hydraulic Rear model 8-4121

    840 downloads

    Updated




×
×
